BN68-01968C-00
LED TV
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model
Serial No.
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Samsung UE46B6000VW
Summary of Contents for Samsung UE46B6000VW
-
Page 1: User Manual
Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Web Site Customer Care Centre EIRE 0818 717 100 www.samsung.com/ie 0845 SAMSUNG (7267864) www.samsung.com/uk BN68-01968C-00 LED TV user manual imagine the possibilities Thank you for purchasing this Samsung product. - Page 2 Accessories ¦ Remote Control & Batteries (AAA x 2) Holder-Wire (3ea) connecter connecter Component Cable ● Owner's Instructions Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. The items colour and shape may vary depending on the model. Stand Screw (M4 X L10) Cover-Bottom Holder-Wire Stand...
- Page 3 3. Some Digital TV functions may not be available or operate correctly in some countries or regions. 4. For more information, please contact your local SAMSUNG customer care centre. Precautions When Displaying a Still Image ❑...
-
Page 4: Table Of Contents
CONTENTS Setting up Your TV ■ Viewing the Control Panel ... 2 ■ Accessories ... 3 ■ Viewing the Connection Panel ... 4 ■ Viewing the Remote Control ... 7 ■ Installing Batteries in the Remote Control ... 8 ■ Viewing the menus ... -
Page 5: Setting Up Your Tv
SETTING UP YOUR TV Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. Product design and specifications may be changed without notice in order to enhance product performance. Viewing the Control Panel ¦... -
Page 6: Viewing The Connection Panel
Viewing the Connection Panel ¦ Power Input The product colour and shape may vary depending on the model. 1 KENSINGTON LOCK The Kensington Lock (optional) is a device used to physically fix the system when used in a public place. If you want to use a locking device, contact the dealer where you purchased the TV. - Page 7 3 EXT (RGB) Inputs or outputs for external devices, such as VCR, DVD, video game device or video disc players. When connecting, use the appropriate connector. In EXT Mode, DTV Out supports MPEG SD Video and Audio only. • Input/Output Specification Input Connector Video...
- Page 8 0 COMMON INTERFACE Slot Insert CI (Common Interface) card into the slot. • When not inserting ‘CI CARD’ in some channels, ‘Scrambled Signal’ is displayed on the screen. • The pairing information containing a telephone number, CI CARD ID, Host ID and other information will be displayed in about 2~3 minutes.
-
Page 9: Viewing The Remote Control
@ DUAL : Sound effect selection. # Use these buttons in the Media Play and Anynet + modes. (∏: This remote can be used to control recording on Samsung recorders with the Anynet + feature) $ ON/OFF @: Pressing the ON/OFF @ light button toggles between on and off. -
Page 10: Installing Batteries In The Remote Control
Installing Batteries in the Remote Control ¦ Normal Remote Control 1. Lift the cover at the back of the remote control upward as shown in the figure. 2. Install two AAA size batteries. Make sure to match the ‘+’ and ‘–’ ends of the batteries with the diagram inside the compartment. -
Page 11: Viewing The Menus
Viewing the menus ¦ Before using the TV, follow the steps below to learn how to navigate the menu in order to select and adjust different functions. MENU Button Display the main on-screen menu. ENTERE / DIRECTION Button Move the cursor and select an item. -
Page 12: Plug & Play Feature
Plug & Play Feature ¦ When the TV is initially powered on, basic settings proceed automatically and subsequently. 1. Press the POWER button on the remote control. You can also use the POWERP button on the TV. The message Select the OSD Language. is displayed. 2. -
Page 13: Channel
CHANNEL Channel Menu ¦ Country ❑ Analogue Channel ■ You can change the country for analogue channels. Digital Channel ■ You can change the country for digital channels. The PIN number input screen appears. Enter your 4 digit PIN number. Auto Store ❑... - Page 14 ● Channel (When you know the number of the channel to be stored): Press the ▲ or ▼ button to select C (Air channel) or S (Cable channel). Press the ► button, then press the ▲, ▼ or number (0~9) buttons to select the required number. You can also select the channel number directly by pressing the number (0~9) buttons.
- Page 15 Fine Tune ❑ If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store operation. If the signal is weak or distorted, you may have to fine tune the channel manually. Fine tuned channels that have been saved are marked with an asterisk “*”...
-
Page 16: Managing Channels
Managing Channels ¦ Using this menu, you can add / delete or set favourites channels and use the programme guide for digital broadcasts. All Channels ■ Shows all currently available channels. Added Channels ■ Shows all added channels. Favourites ■ Shows all favourite channels. - Page 17 Timer Viewing ■ If you reserve a programme you want to watch, the channel is automatically switched to the reserved channel in the Channel List; even when you are watching another channel. To reserve a programme, set the current time first. Only memorized channels can be reserved.
-
Page 18: Picture
PICTURE Configuring the Picture Menu ¦ Mode ❑ You can select the type of picture which best corresponds to your viewing requirements. Press the TOOLS button to display the Tools menu. You can also set the picture mode by selecting Tools → Picture Mode. Dynamic ■... - Page 19 Advanced Settings ❑ Samsung’s new TVs allow you to make even more precise picture settings than previous models. Advanced Settings is available in Standard or Movie mode. In PC mode, you can only make changes to Dynamic Contrast, Gamma and White Balance from among the Advanced Settings items.
- Page 20 Picture Options ❑ In PC mode, you can only make changes to the Colour Tone and Size from among the items in Picture Options. Colour Tone → Cool / Normal / Warm1 / Warm2 / Warm3 ■ Warm1, Warm2 or Warm3 is only activated when the picture mode is Movie. Settings can be adjusted and stored for each external device you have connected to an input of the TV.
- Page 21 Film Mode → Off / Auto1 / Auto2 ■ The TV can be set to automatically sense and process film signals from all sources and adjust the picture for optimum quality. Film Mode is supported in TV, AV, COMPONENT(480i / 1080i) and HDMI(480i / 1080i). ● Off: Turn the Film Mode function off. ●...
-
Page 22: Using Your Tv As A Computer (Pc) Display
However, even if your actual screens look different, the same basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) 1. First, click on ‘Control Panel’ on the Windows start menu. -
Page 23: Setting Up The Tv With Your Pc
Setting up the TV with your PC ¦ Preset: Press the SOURCE button to select PC mode. Auto Adjustment ❑ Use the Auto Adjust function to have the TV automatically adjust the video signals it receives. The function also automatically fine-tunes the settings and adjusts the frequency values and positions. -
Page 24: Sound
SOUND Configuring the Sound Menu ¦ Mode → Standard / Music / Movie / Clear Voice / Custom ❑ Press the TOOLS button to display the Tools menu. You can also set the sound mode by selecting Tools → Sound Mode. ● Standard: Selects the normal sound mode. ● Music: Emphasizes music over voices. ●... -
Page 25: Selecting The Sound Mode
Speaker Select ❑ When you watch TV with it connecting to a Home theatre, turn the TV speakers off so you can listen to sound from the Home theatre’s (external) speakers. ● External Speaker: Used to listen to the sound of the External (Home Theatre) Speakers. ●... -
Page 26: Setup
BD Wise → Off / On ❑ Provides the optimal picture quality for SAMSUNG DVD, Blu-ray and Home Theatre products which support BD Wise. You can enjoy a richer picture when using them connected to this Samsung TV. Connect SAMSUNG products that have BD Wise using an HDMI cable. - Page 27 Parental Lock → Parental Rating ❑ This feature allows you to prevent unauthorized users, such as children, from watching unsuitable programme by a 4-digit PIN (Personal Identification Number) code that is defined by the user. The Parental Rating item differs depending on the country. Before the setup screen appears, the PIN number input screen appears.
-
Page 28: Setting The Time
Melody → Off / Low / Medium / High ❑ A melody sound can be set to come on when the TV is powered On or Off. The Melody does not play • When no sound is output from the TV because the MUTE button has been pressed. •... - Page 29 Timer 1 / Timer 2 / Timer 3 ❑ Three different on / off timer settings can be made. You must set the clock first. On Time ■ Set the hour, minute, and activate / inactivate. (To activate timer with the setting you’ve chosen, set to Activate.) Off Time ■...
-
Page 30: Input / Support
● Yes: If the test pattern does not appear or there is noise in the test pattern, select Yes. There may be a problem with the TV. Therefore, contact Samsung’s call centre for assistance. ●... - Page 31 Software Upgrade ❑ Samsung may offer upgrades for the TV’s firmware in the future. These upgrades can be performed via the TV when it is connected to the Internet, or by downloading the new firmware from samsung.com to a USB memory device.
-
Page 32: Media Play (Usb)
USB compatibility problem. Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss. -
Page 33: Media Play Function
Media Play Function ¦ This function enables you to view and listen to photo and/or music files saved on a USB Mass Storage Class (MSC) device. Entering the Media Play (USB) Menu 1. Press the MENU button. Press the ▲ or ▼ button to select Application, then press the ENTERE button. -
Page 34: Sorting The Photo List
1 Current Sort key: This field shows the current standard for sorting files. Press the ◄ or ► button to change the standard for sorting files. 2 View Groups: Shows the detailed groups of the files sorted according the selected Sort key. The sort group where the currently selected file is contained is highlighted. -
Page 35: Photo List Option Menu
Photo List Option Menu ¦ 1. Press the MEDIA.P button. 2. Press the ◄ or ► button to select Photo, then press the ENTERE button. 3. Press the ▼ button to move to the File List Section. 4. Press the ◄ or ► button to select the desired photo file. Selecting Multiple Photos •... -
Page 36: Viewing A Photo Or Slide Show
Viewing a Photo or Slide Show ¦ Viewing a Slide Show 1. Press the ▼ button to select the File List Section. 2. Press the TOOLS button. 3. Press the ▲ or ▼ button to select Slide Show, then press the ENTERE button. All files in the photo list will be used for the Slide Show. -
Page 37: Slide Show Option Menu
To perform a Slide Show with only the selected files 1. Press the ▼ button to select the File List Section. 2. Press the ◄ or ► button to select the desired photo in the Photo list. 3. Press the Yellow button. 4. Repeat the above operation to select multiple photos. The c mark appears to the left of the selected photo. - Page 38 Background Music ❑ You can select background music when watching a Slide Show. To use this feature, there must be music and photo files stored on the USB device. Loading music files is needed to change BGM mode. Play music files in music category to load. Background Music → Off / On ■...
-
Page 39: Sorting The Music List
Sorting the Music List ¦ You can sort music files in the Music List by a particular standard. 1. Press the MEDIA.P button. 2. Press the ◄ or ► button to select Music, then press the ENTERE button. 3. Press the ▲ button to move to the Sort key Section. 4. -
Page 40: Music List Option Menu
Music List Option Menu ¦ 1. Press the MEDIA.P button. 2. Press the ◄ or ► button to select Music, then press the ENTERE button. 3. Press the ▲ button to move to the File List Section. 4. Press the ◄ or ► button to select the desired Music file. Selecting Multiple Music Files •... -
Page 41: Playing A Music
Playing a Music ¦ Playing a music file 1. Press the ▼ button to select the File List Section. 2. Press the ◄ or ► button to select a music file to be played. 3. Press the ∂ (Play)/ENTERE button. This menu only shows files with the MP3 file extension. Files with other file extensions are not displayed, even if they are saved on the same USB device. -
Page 42: Using The Setup Menu
Music Play option Menu ¦ Music Play Option Menu Repeat Mode → On / Off ❑ You can play music files repeatedly. Picture Setting / Sound Setting ❑ You can configure the picture and sound settings. Information ❑ The music file information is displayed. Remove Safely ❑... -
Page 43: Anynet
Anynet + is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet + system can be used only with Samsung devices that have the Anynet + feature. To be sure your Samsung device has this feature, check if there is an Anynet + logo on it. -
Page 44: Setting Up Anynet
Setting Up Anynet + ¦ Press the TOOLS button to display the Tools menu. You can also display Anynet + menu by selecting Tools → Anynet + (HDMI-CEC). Setup ❑ Anynet + (HDMI-CEC) → Off / On ■ To use the Anynet + Function, Anynet + (HDMI-CEC) must be set to On. When the Anynet + (HDMI-CEC) function is disabled, all the Anynet+ related operations are deactivated. -
Page 45: Recording
Recording ¦ You can make a recording of a TV programme using a Samsung recorder. 1. Press the TOOLS button. Press the ENTERE button to select Anynet + (HDMI-CEC). 2. Press the ▲ or ▼ button to select Recording Immediately and press the ENTERE button. -
Page 46: Troubleshooting For Anynet
Troubleshooting for Anynet + ¦ Problem Possible Solution Anynet + does not work. Check if the device is an Anynet + device. The Anynet + system supports Anynet + devices only. ● ● Connect only one receiver (home theatre). Check if the Anynet + device power cord is properly connected. ●... -
Page 47: Recommendations
RECOMMENDATIONS Teletext Feature ¦ Most television stations provide written information services via Teletext. The index page of the Teletext service gives you information on how to use the service. In addition, you can select various options to suit your requirements by using the remote control buttons. -
Page 48: Installing The Stand
The Teletext pages are organized according to six categories: Part Contents Selected page number. Broadcasting channel identity. Current page number or search indications. Date and time. Text. Status information. FASTEXT information. Teletext information is often divided between several pages displayed in sequence, which can be accessed by: •... -
Page 49: Disconnecting The Stand
Wall Mount items. Contact a technician for assistance when installing the wall mounted bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own. -
Page 50: Preparing Before Installing Wall-Mount
Preparing before installing Wall-Mount ¦ To install a wall-mount from another manufacturer, use the Holder-Ring 1. Securing the TV to the Wall ¦ Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang over or destabilize the TV;... -
Page 51: Troubleshooting: Before Contacting Service Personnel
Troubleshooting: Before Contacting Service Personnel ¦ No sound or picture Check that the mains lead has been connected to a wall socket. Check that you have pressed the button on your set. Check the picture contrast and brightness settings. Check the volume. Normal picture but no sound Check the volume. -
Page 52: Specifications
Specifications ¦ Model Name Screen Size (Diagonal) Power Consumption Standby PC Resolution (Optimum) Sound (Output) Dimensions (WxDxH) Body With stand Weight With Stand Environmental Considerations Operating Temperature Operating Humidity Storage Temperature Storage Humidity Stand Swivel (Left / Right) Design and specifications are subject to change without prior notice. This device is a Class B digital apparatus. - Page 53 Warning! Important Safety Instructions Please read the appropriate section that corresponds to the marking on your Samsung product before attempting to install the product. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
-
Page 54: Warranty Card
3. Warranty repairs must be carried out by Authorised Samsung Dealers or Authorised Service Centres. No re-imbursement will be made for repairs carried out by non Samsung Dealers and, any such repair work and damage to the products caused by such repair work will not be covered by this warranty. -
Page 55: Gnu General Public License
This product uses some software programs which are distributed under the GPL/LGPL license. Accordingly, the following GPL and LGPL software source codes that have been used in this product can be provided after asking to vdswmanager@ samsung.com. GPL software: Linux Kernel, Busybox, Binutils... - Page 56 To “propagate” a work means to do anything with it that, without permission, would make you directly or secondarily liable for infringement under applicable copyright law, except executing it on a computer or modifying a private copy. Propagation includes copying, distribution (with or without modification), making available to the public, and in some countries other activities as well.
- Page 57 You may convey a work based on the Program, or the modifications to produce it from the Program, in the form of source code under the terms of section 4, provided that you also meet all of these conditions: • a) The work must carry prominent notices stating that you modified it, and giving a relevant date.
- Page 58 warranty, or updates for a work that has been modified or installed by the recipient, or for the User Product in which it has been modified or installed. Access to a network may be denied when the modification itself materially and adversely affects the operation of the network or violates the rules and protocols for communication across the network.
- Page 59 Each time you convey a covered work, the recipient automatically receives a license from the original licensors, to run, modify and propagate that work, subject to this License. You are not responsible for enforcing compliance by third parties with this License.
- Page 60 The Free Software Foundation may publish revised and/or new versions of the GNU General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns. Each version is given a distinguishing version number.
- Page 61 GNU Lesser General Public License (LGPL) ¦ Version 3, 2 June 200 Copyright (C) 2007 Free Software Foundation, Inc. <http://fsf.org/> Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble The GNU General Public License is a free, copyleft license for software and other kinds of works.
- Page 62 The “source code” for a work means the preferred form of the work for making modifications to it. “Object code” means any non-source form of a work. A “Standard Interface” means an interface that either is an official standard defined by a recognized standards body, or, in the case of interfaces specified for a particular programming language, one that is widely used among developers working in that language.
- Page 63 the covered work, and which are not combined with it such as to form a larger program, in or on a volume of a storage or distribution medium, is called an “aggregate” if the compilation and its resulting copyright are not used to limit the access or legal rights of the compilation’s users beyond what the individual works permit.
- Page 64 from any part of it. (Additional permissions may be written to require their own removal in certain cases when you modify the work.) You may place additional permissions on material, added by you to a covered work, for which you have or can give appropriate copyright permission.
- Page 65 A “contributor” is a copyright holder who authorizes use under this License of the Program or a work on which the Program is based. The work thus licensed is called the contributor’s “contributor version”. A contributor’s “essential patent claims” are all patent claims owned or controlled by the contributor, whether already acquired or hereafter acquired, that would be infringed by some manner, permitted by this License, of making, using, or selling its contributor version, but do not include claims that would be infringed only as a consequence of further modification of the contributor version.
- Page 66 THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
-
Page 67: License Issues
LICENSE ISSUES ¦ The OpenSSL toolkit stays under a dual license, i.e. both the conditions of the OpenSSL License and the original SSLeay license apply to the toolkit. See below for the actual license texts. Actually both licenses are BSD-style Open Source licenses. In case of any license issues related to OpenSSL please contact openssl-core@openssl.org. - Page 68 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
- Page 69 Korrekt avfallshantering av produkten (elektriska och elektroniska produkter) Denna markering på produkten, tillbehören och i manualen anger att produkten och de elektroniska tillbehören (t.ex. laddare, headset, USB-kabel) inte bör sorteras tillsammans med annat hushållsavfall när de kasseras. Till förebyggande av skada på miljö och hälsa bör dessa föremål hanteras separat för ändamålsenlig återvinning av beståndsdelarna.
