9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | +1-406-549-0769
www.aquacreek.com
Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may aff ect the safety of the user.
Copyright © 2020 Aqua Creek Products All Rights Reserved
24V Solar Charger
(For use with Admiral, Ranger 2 & Ambassador)
Lift safety can only be ensured if the lift is installed and
• NEVER permit children to play on or around the lift
• Do not allow children to use the lift without adult
supervision
• NEVER apply direct water pressure to the electronics
• NEVER use the lift with a dry pool
READ CAREFULLY
Instructions
PART #: F-044SCH-04
MANDATORY
LEAVE THIS MANUAL WITH LIFT OWNER
Read and follow all instructions.
operated according to these instructions.
1
Revised 3/18/20
Advertisement
Related Manuals for Aqua Creek F-044SCH-04
Summary of Contents for Aqua Creek F-044SCH-04
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may aff...
- Page 2 STEP 4: The solar charger control box connector plugs directly into the battery and control box on the lift. See page 4 for Admiral lift and page 5 for Ranger 2 lift. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 3/18/20...
- Page 3 STEP 4: Run the BATTERY CABLE along the base frame, back under the main frame, and up the actuator frame as shown. See page 5 for instructions on plugging the system into the control box. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 3/18/20...
- Page 4 CHARGER CABLE to the male end of the CONTROL BOX. See pictures below. NOTE: Make sure all plugs are fully engaged, the lights on the solar charger come on, and that the lift functions correctly. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 3/18/20...
- Page 5 Solar Charger Installation to Linak Controls STEP 5: Run the BATTERY CABLE behind the control box as shown, and plug the BATTERY CONNECTOR into the control box. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 3/18/20...
-
Page 6: Charge Controller
The 24V Solar Charger will continue to charge the battery, even as the lift is being used. So once the 24V Solar Charger has been installed it will function without any need for adjustment. The user should check the indicators periodically to make sure it is working. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 3/18/20... - Page 7 Do NOT expose the battery to long periods of direct sunlight. Heat will shorten your battery life. Optimum operating temperature is below 20 degrees Celsius (68 degrees F.) Aqua Creek recommends a battery cover be used with solar chargers since the battery is left on the lift at all times.
- Page 8 NN 10 NUT, 316 SS, NYLOCK, #10-24 NH 1/2 NUT, 316 SS, HEX, 1/2”-13 P-TPTR12 THREAD PROTECTOR VSCC2 CABLE, SOLAR CHARGER CABLE, VITO 00918174 LINAK DUMMY PLUG FOR DC PORT Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 3/18/20...
- Page 9 Aqua Creek, all warranties are void. To initiate a warranty claim, the owner of an Aqua Creek product must provide the place of purchase, in writing, with a full description of the product, its serial number, the dates of purchase and installation, and the exact nature of the defect. Within thirty (30) days after receipt of a written warranty claim by Aqua Creek, and barring any unforeseen delays, the place of purchase will be notified of Aqua Creek’s decision regarding the claim.
