- Page 1 DATECS BluePad-55 v2 USER GUIDE BLUEPAD-55 v2 User Guide © 2018 Datecs, Ltd.
- Page 2 Datecs, the Datecs logo, are registered trademarks of Datecs. Other brand names or trademarks associated with Datecs’s products and services are trademarks of Datecs, Ltd. All other brand names and trademarks appearing in this manual are the property of their respective holders.
- Page 3 DATECS Version Data Change description 1.0.0 14.11.2018 Release version 2.0.0 28.05.2020 Added Section “Regulatory” DATECS Page 3 of 23 BLUEPAD-55 V2 USER GUIDE...
-
Page 4: Table Of Contents
HOW TO INSERT/REMOVE SIM AND SAM CARDS ......................SMART CARD READER USE............................... ONDUCT A MART RANSACTION ................................CONTACTLESS CARD READING ............................ONDUCT A ONTACTLESS REDIT EBIT RANSACTION ..........................DISPLAY WITH TOUCHSCREEN ............................ISPLAY NDICATIONS ........................................TROUBLESHOOTING GUIDELINES ............................. DATECS Page 4 of 23 BLUEPAD-55 V2 USER GUIDE... - Page 5 DATECS LANK ISPLAY ............................................EYPAD ESPOND ......................................RANSACTIONS ROCESS ....................................Check Smart Card Reader ............................... AINTENANCE AND LEANING ...................................... AIN BATTERY REPLACEMENT ......................................ERVICE AND UPPORT ........................................ERVICE ETURNS ........................................... DATECS Page 5 of 23 BLUEPAD-55 V2 USER GUIDE...
-
Page 6: Regulatory
Device types: Smartphone has also been tested against this SAR limit. This device was tested for typical body-worn operations with the back of the BluePad-55 v2 kept 5mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain an 0mm separation distance between the user's body and the back of the phone. -
Page 7: Preface
DATECS PREFACE This guide is the primary source of information for setting up and installing BLUEPAD-55 v2. Audience This guide provides simple descriptions of BLUEPAD-55 v2 features, as well as basic information for anyone installing and configuring BLUEPAD-55 v2. Organization... -
Page 8: Related Documentation
DATECS Related Documentation To learn more BLUEPAD-55 v2, refer to the following set of documents: • BLUEPAD-55 v2 Physical Security Features • BLUEPAD-55 v2 Firmware API Specifications • BLUEPAD-55 v2 Software Design Specifications ONVENTIONS Various conventions are used to help you quickly identify special formatting. -
Page 9: Overview
This chapter provides a brief description of Datecs’s BLUEPAD-55 v2 device. BLUEPAD-55 v2 The BLUEPAD-55 v2 unit is a handheld PIN pad with an integrated smart and contactless card reader an optional Bluetooth module designed to be used with a variety of PDA’s, offering advanced security and smart card processing capabilities. -
Page 10: Features And Benefits
Primary smart card reader support for synchronous and asynchronous smart cards. • Support for international character sets and Unicode standard. • BLUEPAD-55 v2 has received EMV Level 1 approval for smart card solutions. • BLUEPAD-55 v2 has received EMV Level 2 approval for smart card solutions. •... -
Page 11: Device Specifications
Drop Test 1.5 m, 6 faces + 4 edges on concrete • 5V through USB-C Power Supply • 5V through charger station • 5V through Docking station Accessories • Docking station DATECS Page 11 of 23 BLUEPAD-55 V2 USER GUIDE... -
Page 12: Device Operation
Figure 1 Contactless LEDs status indications LCD Display with touchscreen Keypad Charging pads for charging station Chip chard reader USB connector SIM/SAM card tray Charging pads and UART communication (for Docking stations) DATECS Page 12 of 23 BLUEPAD-55 V2 USER GUIDE... -
Page 13: Setup
For reading of an ICC, the card has to be inserted manually into the card slot 3. The card slides into the BLUEPAD-55 v2 bottom ICC slot until the end of the slot it reached and slight “click” is felt. -
Page 14: Info Hardware
DATECS DEV SN - BLUEPAD-55 v2 serial number USIP SN - USIP serial number USIP VER - USIP version ISBL VER - USIP Boot loader version HAL VER - USIP Hardware Abstraction Layer (HAL) version LOAD VER - Secure Boot Loader (SBL) version and name... -
Page 15: Keys Download
Exit the service menu forwarding the control to the application. APPLICATION DOWNLOAD MODE To enter application download mode on the BLUEPAD-55 v2, the button UP has to be maintained pressed while switching on the PINPAD. A characteristic sound is played and on the display appears the name and version of the Secure Boot Loader. -
Page 16: Settings In Application(Depends Of The Application)
ADDR: MAC ADDRESS of the Bluetooth NAME: Bluetooth name PASS: Bluetooth password PAIR: DISCOVERABLE/HIDDEN AUTO: ENABLE/DISABLE VER: Bluetooth firmware version MASTER RESET: return to default settings PAIRING FW UPDATE AUTO OFF 60min*/120min/180min/240min/DISABLE/1min//5min/10min/ 15min/30min/45min *Default settings DATECS Page 16 of 23 BLUEPAD-55 V2 USER GUIDE... -
Page 17: How To Insert/Remove Sim And Sam Cards
Figure 2 The BLUEPAD-55 v2 SIM and SAM tray is support only Nano size cards. When tray is opened slide out (Figure 3) and insert cards (Figure 4). Place cards and slide in the tray and close (Figure 5). - Page 18 DATECS Figure 5 SIM and SAM card must be placed on correct positions, they are shown on Figure 4. DATECS Page 18 of 23 BLUEPAD-55 V2 USER GUIDE...
-
Page 19: Smart Card Reader Use
Position a smart card with the gold contacts facing upward. Insert it into the ICC card reader slot in a smooth, continuous motion until it seats firmly. Hand BLUEPAD-55 v2 to customer for PIN entry Remove the card when the display indicates the transaction is completed. -
Page 20: Contactless Card Reading
Contactless Card Reading The contactless card transaction procedure can vary depending on the application loaded on the BLUEPAD-55 v2. Verify the proper procedure with your application provider before performing a contactless card transaction. In order to use the Contactless card reading function, special software must be used. Please contact your distributor in order to get the latest demo application and SDK. -
Page 21: Display With Touchscreen
Battery indication for fully charged battery Outside power from USB cable – “Plug” Battery is charging from UBS cable or Power station – “Flash” "Bluetooth" – active Bluetooth connection "USB" - connection with USB DATECS Page 21 of 23 BLUEPAD-55 V2 USER GUIDE... -
Page 22: Troubleshooting Guidelines
If the problem persists, contact your local Datecs representative. Due to risk of shock or damage, do not use the BLUEPAD-55 v2 unit near water, including a bathtub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool. - Page 23 Do not spray cleaners or other solutions directly onto the keypad or display. Main battery replacement To replace the main battery of BLUEPAD-55 v2 please contact with your your local Datecs representative or service provider. Service and Support For BLUEPAD-55 v2 problems, product service, and repair information, contact your local Datecs representative or service provider.
