READ AND FOLLOW ALL INSTRUCTIONS BEFORE OPERATING YOUR SOLAR LIGHT.

1. Description

The SolarGoesGreen solar LED Flood Light is a premier choice for indoor or outdoor lighting.
Widely used for gardens, parks, warehouses, garages, driveways, signs, yards, farms,
horse riding arenas and businesses. The SolarGoesGreen flood light is easly installed.
The battery is protected by an auto-detection circuit in the system to control the brightness
of the lamp, allowing the lamp to operate longer as the battery charge declines.

2. Parts

① Solar Panel
② LED Lamp and Battery
③ Ground Stake for Solar Panel

3. Installation

Please check the below items before installation:
1) Connect the solar panel wire to the LED lamp;
2) Mount the solar panel facing sunlight using the ground mount stake and then switch the
power ON (Fig 1); The lamp will light up and then shut down automatically after 15 seconds;
3) Completly shield the face of the solar panel by laying it face down on a flat surface or cover
the panel with a thick, black cloth. The LED lamp will turn on after 15 seconds.
After checking the items above, turn off the power and install the lamp in the desired
position; place the solar panel with a ground stake where the solar cell will absorb
maximum sunlight. The solar panel receives maximum sunlight only when the
panel is perpendicular to the sunlight.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
③
①
②
