DATA TABLE

FORMAT
- NO LOCK
- PCM
- DOLBY DIGITAL AC-3 (DD)
- DOLBY E (E)
AUDIO SOURCE TYPE
- ANALOG
- AES 75 (UNBALANCED)
- AES 110 (BALANCED)
- SDI 1 (A) 1/2 (GROUP 1 AND 2)
- SDI 1 (A) 3/4 (GROUP 3 AND 4)
- SDI 2 (B) 5/6 (GROUP 1 AND 2)
- SDI 2 (B) 7/8 (GROUP 3 AND 4)
REFERENCE SOURCE TYPE
- INTERNAL
- AES 75 (UNBALANCED)
- AES 110 (BALANCED)
DOLBY E CONFIGURATION (E)
- 5.1+2
- 5.1+1+1
- 4+4
- 4+2+2
- 4+2+1+1
- 4+4x1
- 4x2
- 3x2+2x1
- 2x2+4x1
- 2+6x1
- 8x1
- 5.1
- 4+2
- 4+1+1
- 3x2
- 2x2+2x1
- 2+4x1
- 6x1
- 4
- 2+2
- 2+2x1
- 4x1
- Non-Dolby E
​ D OLBY DIGITAL CONFIGURATION (DD)
- 1+1
- 1/0
- 2/0
- 3/0
- 2/1
- 3/1
- 2/2
- 3/2
- 3/2L
- 2/2L
- 3/1L
- 2/1L
- 3/0L
- Non Dolby Digital
DIALOGUE NORMALIZATION (DN)
1-31
>31 = NAN (Not a Number)
MIX LEVEL (MX)
81-111
<81 OR >111 = NAN
BIT DEPTH (BD)
- 32 Bit
- 16 Bit
- 24 Bit
- 20 Bit
- NtInd (Not Indicated)
DOLBY BITSTREAM INFORMATION
(BM)
​ - MnCp (Main Complete)
- McEf (Music and Effects)
- ViIp (Visually Impaired)
- HrIp (Hearing Impaired)
- Dlge (Dialogue)
- Cmty (Commentary)
- Ergy (Emergency)
- VCor (Voiceover)
- Krke (Karaoke)
- N/A (Not Applicable)
