Default Battery Types and Settings

Rated Voltage
Full Charge Voltage
Storage Voltage
Discharge Voltage
Pre-charge Voltage
Balance Charge
Unbalanced Charge
Support Cells
Max Charge Current
Be EXTREMELY careful to choose the correct voltage settings based on the cells
and chemistry of the battery being charged. Failure to do so may result in battery
damage, explosion, or fire!
Pb
NiCd/NiMH
1.20V 2.00V
1.40V 2.40V
Not supported Not supported
0.5-1.10V 1.80-2.00V
/ 2.00V
Not supported Not supported
supported supported
1-16S 1-12S
16.0A 16.0A
LiFe LiIon
3.20V 3.60V
3.60V 4.10V
3.30V 3.70V
2.60-2.90V 2.90-3.20V
2.90V 3.10V
supported supported
supported supported
1-6S 1-6S
16.0A 16.0A
LiPo
LiHV
3.70V 3.80V
4.20V 4.35V
3.80V 3.90V
3.00-3.30V 3.10-3.40V
3.20V 3.20V
supported supported
supported supported
1-6S 1-6S
16.0A
16.0A
