CLARITY CL26.SP.1
FREESTANDING DIRECT VENT GAS ROOM HEATER
with 7 Day Shutoff Standing Pilot (SP)
For use with natural gas (NG) or propane (LPG)
WARNING:
If the information in these
OPERATION &
instructions are not followed exactly, a fire
INSTALLATION
or explosion may result causing property
MANUAL
PFS Report #F19-558
damage, personal injury or loss of life.
Date Installed: ____________
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Serial No.: _____________
Homeowner: Please keep these instructions for future reference.
Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com
180-CL26.SP.1 v1.00
July 30, 2020
Advertisement
Table of Contents
Related Manuals for Blaze King CLARITY CL26.SP.1
Summary of Contents for Blaze King CLARITY CL26.SP.1
- Page 1 CLARITY CL26.SP.1 FREESTANDING DIRECT VENT GAS ROOM HEATER with 7 Day Shutoff Standing Pilot (SP) For use with natural gas (NG) or propane (LPG) WARNING: If the information in these OPERATION & instructions are not followed exactly, a fire INSTALLATION...
-
Page 2: Table Of Contents
VALVE REMOVAL AND INSTALLATION _______________________________________________________ 42 PARTS LIST _________________________________________________________________________________ 43 TROUBLESHOOTING ________________________________________________________________________ 44 WARRANTY _________________________________________________________________________________ 45 Manufactured By Valley Comfort Systems Inc. Blaze King Industries 1290 Commercial Way 146 A Street Penticton, BC V2A 3H5 Walla Walla, WA 99362 CANADA U.S.A. -
Page 3: Safety Precautions
CL26.SP.1 SAFETY PRECAUTIONS Page 3 This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home, where not prohibited by local codes. FIRE OR EXPLOSION HAZARD Failure to follow safety warnings This appliance is only for use with the type of gas exactly could result in serious injury, indicated on the rating plate. -
Page 4: Your Safety
SAFETY PRECAUTIONS cont. CL26.SP.1 Page 4 YOUR SAFETY • Have the venting system inspected annually by a qualified installer for blockage and signs of deterioration. • To prevent injury, do not allow anyone who is unfamiliar with the stove to operate it. •... -
Page 5: General Information
CL26.SP.1 GENERAL INFORMATION Page 5 APPLIANCE CERTIFICATION This appliance is tested and certified to the following US and Canadian gas appliance standards: • ANSI Z21.88-2017 / CSA 2.33-2017 - Vented Gas Fireplace Heaters • CSA 2.17-2017 - Gas-Fired Appliance for Use at High Altitudes •... -
Page 6: Certification Label
MANUFACTURED IN: JUL o AUG o SEP o OCT o NOV o DEC o o USA: Blaze King Industries 146A Street, Walla Walla, WA. 99362 2020 o 2021 o 2022 o 2023 o 2024 o 2025 o o CANADA: Valley Comfort Systems 1290 Commercial Way, Penticton, B.C. V2A 3H5 170-0249 [06 20] 180-CL26.SP.1 v1.00... -
Page 7: Dimensions
CL26.SP.1 DIMENSIONS Page 7 " 373mm VERTICAL VENT " " " " 886mm 976mm 962mm 952mm REAR VENT " NOTE: RATING AND LIGHTING INSTRUCTION LABELS ARE LOCATED ON THE LOWER RIGHT AND LEFT 343mm OUTSIDE PANELS. TO REMOVE, LIFT UP AND OFF. "... -
Page 8: Lighting Instructions
CL26.SP.1 LIGHTING INSTRUCTIONS Page 8 FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. This appliance has a pilot which is lit with a push button piezo lighter. When lighting the pilot, follow these instructions exactly. -
Page 9: 820 Nova Valve
CL26.SP.1 820 NOVA VALVE Page 9 15 6 820 NOVA VALVE ON/PILOT/OFF Knob Manual HI-LO adjustment or pressure regulator adjustment Pilot adjustment Thermocouple connection Mounting for piezo & bracket Inlet pressure test point Outlet pressure test point Main operator Pilot outlet Main gas outlet Flange mounting screw holes Additional valve mounting holes... -
Page 10: Operating Instructions
CL26.SP.1 OPERATING INSTRUCTIONS Page 10 PILOT LIGHT Refer to the lighting instruction label on how to light the pilot. Check that the pilot has fully engulfed the thermocouple assembly (Fig.1). LIGHTING THE BURNER Fig.1 Standing Pilot (SP) The CL26 SP controls are located behind the hinged door beneath the firebox.(Fig.2) To light the burner follow the steps below: Make sure the pilot is lit (see “LIGHTING... -
Page 11: Maintenance And Service
CL26.SP.1 MAINTENANCE and SERVICE Page 11 ROUTINE MAINTENANCE Regularly: • Clean and remove any lint accumulations or debris from the grills and combustion or convection air passage ways. • Keep the appliance area free from combustible materials, such as paper, wood, clothing, gasoline, flammable solids, liquids and vapors. -
Page 12: Glass Door Removal
Do not operate this appliance with the glass front removed, cracked, or broken. Removal and replacement of the glass from the door must be done by a qualified service technician. The glass must be purchased from a Blaze King dealer. No substitute materials are allowed. Fig.5 180-CL26.SP.1 v1.00... -
Page 13: Burner Removal
CL26.SP.1 MAINTENANCE and SERVICE cont. Page 13 BURNER REMOVAL 1. Turn off the appliance and allow it to cool down completely. 2. Remove the glass door and safety screen (see “GLASS DOOR REMOVAL” on previoius page and “SAFETY SCREEN REMOVAL” below) 3. -
Page 14: Fuel Conversion
MAINTENANCE and SERVICE cont. CL26.SP.1 Page 14 FUEL CONVERSION THIS CONVERSION KIT SHALL BE INSTALLED BY A QUALIFIED SERVICE AGENCY IN ACCORDANCE WITH THE MANUFACTURER’S INSTRUCTIONS AND ALL APPLICABLE CODES AND REQUIREMENTS OF THE AUTHORITIES HAVING JURISDICTION. IF THE INFORMATION IN THESE INSTRUCTIONS IS NOT FOLLOWED EXACTLY, A FIRE, EXPLOSION OR PRODUCTION OF CARBON MONOXIDE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. - Page 15 CL26.SP.1 MAINTENANCE and SERVICE cont. Page 15 installationi i n n s s t t r r u u c c t t i i o o n n s s 820 NOVA HI/LO Conversion Kit WARNING! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer.
-
Page 16: Installation
INSTALLATION CL26.SP.1 Page 16 This section of the owner’s manual is for the use of qualified service technicians only. Fireplace placement, hearths, and venting terminations will be covered, as well as the gas and electrical systems. Please read “SAFETY PRECAUTIONS” at the front of this manual. - Page 17 CL26.SP.1 INSTALLATION cont. Page 17 7. Loosen the top left tab as shown by arrow, install the left glass up under the tab and onto the support. (Fig.12) NOTE: THE SIDE WITH LABEL SHOULD BE FACING FIREBOX, REMOVE BEFORE FIRING. Retighten the tab. HANDLE GLASS CAREFULLY BY THE EDGES, DO NOT LEAVE FINGERPRINTS, CLEAN IF NECESSARY 8.
-
Page 18: Backing Panel Installation
INSTALLATION cont. CL26.SP.1 Page 18 BACKING PANEL INSTALLATION There is a supplied backing panel that can be used to hide gas lines, power cords etc. • There are four magnets in the manual bag, attach the magnets as shown in (Fig.16) to the back legs of the appliance. -
Page 19: Rear Vent Installation
CL26.SP.1 INSTALLATION cont. Page 19 REAR VENT INSTALLATION Two snorkels are available that can be used in a rear vent application on the CL26. One is the M&G Duravent 46DVA-H2-SNK36 (Fig.18), and the other is the Selkirk 4DT-ST36 (Fig.19). Fig.18 Fig.19 CONVERSION TO REAR VENT 1. - Page 20 INSTALLATION cont. CL26.SP.1 Page 20 2. Remove screws from top rear grill assembly (1 screw each side of leg, two screws each side of flue collar). (Fig.21) Fig.21 3. Remove top rear grill assembly from appliance and set aside. (Fig.22) Fig.22 4.
- Page 21 CL26.SP.1 INSTALLATION cont. Page 21 5. Rotate outer rear shield and place below such that the connected wires are not compromised. (Fig.24) Fig.24 6. Remove screws from flue collar (6 screws). (Fig.25) Fig.25 7. Rotate flue collar as shown and re- install to appliance (6 screws).
-
Page 22: Clearance To Combustibles
INSTALLATION cont. CL26.SP.1 Page 22 CLEARANCE TO COMBUSTIBLES Side of unit to sidewall 2” (51 mm) Back of unit to back wall 2.5” (64 mm) Corner of unit to sidewall 2” (51 mm) Top of unit to alcove ceiling 33” (838 mm) Alcove width 27.875”... -
Page 23: Gas Connections
CL26.SP.1 INSTALLATION cont. Page 23 GAS CONNECTIONS Have your gas supplier or a qualified gas fitter run a gas supply line to the gas fireplace. The line must be properly sized and fitted according to the installation codes. This unit is equipped with a manual shutoff ball valve (Fig.27). - Page 24 INSTALLATION cont. CL26.SP.1 Page 24 A MINIMUM VENT CLEARANCE OF 1” (26mm) TO COMBUSTIBLES MUST BE MAINTAINED ON VERTICAL PIPE RUNS AND 13” (330 mm) FOR HORIZONTAL PIPE RUNS (SIDES AND BOTTOM 1” (26 mm)) The rigid vent systems use twist lock connections. The flue collar attached to the unit connects to the approved venting system.
-
Page 25: Vertical Vent Installation
CL26.SP.1 INSTALLATION cont. Page 25 VERTICAL VENT INSTALLATION Always maintain the 1” (26 mm) clearance around the vent pipe (vertical), when passing through ceilings, walls, roofs, enclosures, attic rafters or any combustible surfaces. DO NOT PACK AIR SPACES WITH INSULATION. Refer to the vent chart for maximum allowable vertical and horizontal installations. -
Page 26: Venting
INSTALLATION INSTRUCTIONS cont. CL26.SP.1 Page 26 VENTING This appliance will not function without being connected to a proper venting system. This unit is certified for use with M&G Duravent, BDM, American Metal, Selkirk (Direct-Temp), Olympia, and ICC venting. Read the manufacturer’s installation instructions before installing the venting system. - Page 27 CL26.SP.1 INSTALLATION INSTRUCTIONS cont. Page 27 VERTICAL VENTING Example 1 V Value = 3A (12’) + 1C (3’) = 15’ H Value = 2B (4’) =4’ V Value = Total length of all vertical sections in feet. H Value = Total length of all horizontal sections in feet. Note: •...
-
Page 28: Vent Termination Restrictions
INSTALLATION INSTRUCTIONS cont. CL26.SP.1 Page 28 VENT TERMINATION RESTRICTIONS Fig.13 VENT TERMINATION RESTRICTIONS, REFER TO Table 1 Table 1 VENT TERMINATION CLEARANCES 12 in (30.5 cm) to 24” (61 cm) 180-CL26.SP.1 v1.00 July 30, 2020... - Page 29 CL26.SP.1 INSTALLATION INSTRUCTIONS cont. Page 29 NOTE: • If an offset is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3’0” (914 mm), to avoid excessive stress on the elbows, and possible separation. Use wall straps as needed.
-
Page 30: Vent Restrictor
INSTALLATION INSTRUCTIONS cont. CL26.SP.1 Page 30 VENT RESTRICTOR Due to the high draft produced by certain venting configurations the vent restrictor may be adjusted to maintain performance. If vent restriction is necessary it can be adjusted as follows: 1. Turn off the appliance and allow it to cool down completely. 2. -
Page 31: Air Shutter Adjustment
CL26.SP.1 INSTALLATION INSTRUCTIONS cont. Page 31 AIR SHUTTER ADJUSTMENT The air shutter allows the amount of air coming into the burner to be adjusted in order to accommodate different climates and venting arrangements. 1. To access the air shutter adjustment lever, open the hinged door beneath the firebox, it is in the upper left-hand side. -
Page 32: Mobile Home Installation
INSTALLATION INSTRUCTIONS cont. CL26.SP.1 Page 32 MOBILE HOME INSTALLATION The CL26 can be installed in a mobile home but must be securely fastened to the floor. Use the provided mounting brackets to secure the appliance to the hearth or mobile home floor.(Fig.33) Ensure the unit is electrically grounded permanently to the chassis of the home. -
Page 33: Electrical Requirements
CL26.SP.1 INSTALLATION INSTRUCTIONS cont. Page 33 ELECTRICAL REQUIREMENTS: For CL26.SP and Z5177.SP FAN KIT ELECTRICAL GROUNDING INSTRUCTIONS WHEN Z5177.SP FAN KIT IS INSTALLED THIS APPLIANCE IS EQUIPPED WITH A THREE PRONG (GROUNDING) PLUG FOR YOUR PROTECTION AGAINST SHOCK HAZARD AND SHOULD BE PLUGGED DIRECTLY INTO A PROPERLY GROUNDED THREE PRONG RECEPTACLE . - Page 34 INSTALLATION INSTRUCTIONS cont. CL26.SP.1 Page 34 WIRING DIAGRAM OF OPTIONAL THERMOSTAT OR WALL SWITCH connect to rear of valve 70 ° F DOWN COOL / HEAT PROGRAM WIRING DIAGRAM FOR CL26 SP BLOWER 6" blk rheostat 8" blk thermal sensor 12"...
-
Page 35: Rigid Venting Parts List
CL26.SP.1 RIGID VENTING PARTS LIST Page 35 M&G DURAVENT DIRECTVENT PRO / GS SYSTEM PARTS LIST DESCRIPTION PART OLD PART 6” Pipe Length -Black 46DVA-06B 908B 6” Pipe Length –Galvanized 46DVA-06 8,5” Black Extension (3”-7”) 46DVA-08AB 8,5” Galvanized Extension (3”-7”) 46DVA-08A 9”... - Page 36 CL26.SP.1 Page 36 BDM PARTS LIST PART DESCRIPTION 4" x 6 5/8" DIRECT VENT PIPE: 94610606 6'' GALVANIZED PRO FORM DV PIPE 94610606B 6'' GALVANIZED PRO FORM DV PIPE BLACK 94610609 9'' GALVANIZED PRO FORM DV PIPE 94610609B 9'' GALVANIZED PRO FORM DV PIPE BLACK 94610612 12'' GALVANIZED PRO FORM DV PIPE 94610612B...
- Page 37 CL26.SP.1 Page 37 BDM PARTS LIST cont. TYPE PART DESCRIPTION OTHER COMPONENTS Vertical Round Co-Axial Caps: 940264 4'' INSIDE 6 5/8'' ROUND VCA PRO FORM DV TERM CAP Ceiling Firestop: 94980612 4'' INSIDE 6 5/8'' PRO FORM DV CEILING FIRESTOP Attic Insulation Shield: 94930620A 4'' INSIDE 6 5/8''PRO FORM DV ATTIC INSULATION SHIELD (Adjustable)
- Page 38 CL26.SP.1 Page 38 SELKIRK PARTS LIST PRODUCT NUMBER PART DESCRIPTION 4" x 6 5/8" LENGTHS 1604006 4DT- 6 DIRECT-TEMP 6" PIPE LENGTH 1604006B 4DT- 6B DIRECT-TEMP 6" PIPE LENGTH BLACK 1604009 4DT- 9 DIRECT-TEMP 9" PIPE LENGTH 1604009B 4DT- 9B DIRECT-TEMP 9"...
- Page 39 CL26.SP.1 Page 39 SELKIRK PARTS LIST cont. PRODUCT NUMBER PART DESCRIPTION 4" x 6 5/8" SUPPORTS 1604400 4DT-CS CEILING SUPPORT 1604424 4DT-CCS CATHEDRAL SUPPORT BOX 1604430 4DT-WS/B WALL SUPPORT/BAND 1604435 4DT-OS OFFSET SUPPORT 4" x 6 5/8" TERMINATIONS AND FLASHINGS 1604620 4DT-VKC VERTICAL TERMINATION KIT...
- Page 40 CL26.SP.1 Page 40 OLYMPIA PARTS LIST PART DESCRIPTION PART DESCRIPTION VDV-0406 4" x 6" L Direct Vent Pipe VDVB-0424 4"x24"L Direct Vent Black Pipe VDV-0406-6 4" x 6" DV Pipe 6 Pack VDVB-0436 4"x36"L Direct Vent Black Pipe VDV-0406SL 4" x 6" Direct Vent Slip Sec. VDVB-0448 4"x48"L Direct Vent Black Pipe VDV-0409...
- Page 41 CL26.SP.1 Page 41 ICC PARTS LIST 4" x 6 5/8" LENGTHS DESCRIPTION PART 6” Length - Galvalume TC-4DL6 6" Length - Black TC-4DL6B 9" Length - Galvalume TC-4DL9 9" Length - Black TC-4DL9B 12" Length - Galvalume TC-4DL1 12" Length - Black TC-4DL1B 12"...
-
Page 42: Valve Removal And Installation
VALVE REMOVAL AND INSTALLATION CL26.SP.1 Page 42 TO BE DONE BY QUALIFIED PERSONNEL ONLY 1. Disconnect the gas, see gas valve shutoff, and electricity to the appliance. 2. Remove fan if installed. 3. Remove the bottom and rear wire shields (7 screws, 1 ground). (Fig.34) 4. -
Page 43: Parts List
CL26.SP.1 PARTS LIST Page 43 ITEM PART ITEM PART DESCRIPTION DESCRIPTION NUMBER NUMBER Z5151 WINDOW LATCH ASSEMBLY 610.0712 PILOT ASM ADJ NG/LPG PSE 5103 FIREBOX BAFFLE 600.SIT.011 PIEZO IGNITER 130.0501.L GLASS CERAM MIRROR LEFT 600.SIT.013 EXTENSION KNOB HI/LO 1.5” 620.5101 CERAMIC PANEL REAR CLARITY 600.SIT.012 EXTENSION KNOB ON/OFF 1.5”... -
Page 44: Troubleshooting
TROUBLESHOOTING CL26.SP.1 Page 44 Please check to make sure the instructions are followed exactly before attempting trouble shooting of the appliance. TROUBLESHOOTING AND SERVICING OF GAS AND ELECTRICAL DEVICES OF THE APPLIANCE SHOULD ONLY BE CONDUCTED BY A QUALIFIED SERVICE TECHNICIAN PROBLEM POSSIBLE CAUSE ACTION... -
Page 45: Warranty
Blaze King and its respective brands extend the following warranty for gas appliances purchased from an authorized Blaze King dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts. - Page 46 Blaze King is the manufacturer of the Blaze King line of heating products. At Blaze King, our commitment to the highest level of quality and customer service is the most important thing we do. Each Blaze King stove is built on a tradition of using only the finest materials and is backed by our limited lifetime warranty to the original purchaser.
- Page 47 Page 47 If you are not satisfied with the service provided by the Blaze King dealer, write to Blaze King at the address listed on the last page of the Owner’s Manual. Include a copy of the original purchase invoice and a description of the problem.
- Page 48 Labor rates are set per component and as such total labor costs may not be covered. 26. If a defect or problem is determined by Blaze King to be non warrantable, Blaze King will not be liable for travel costs for service work.
