Bradford White 500-B Specification Sheet

Solar Saver Product
Solar Water Heater Model
Features:
1
9001 Bradford White is ISO registered to the
9001- standard.
S T A N D A R D
I 2" Non-CFC foam insulation—completely covers the side and
top of tank, saving energy by retarding loss of heat.
I Vitraglas ® lining—Bradford White water heater tanks are
protected from the corrosive effects of hot water by an
exclusive ceramic porcelain-like coating. The Bradford White
high silica Vitraglas ®
our water heater tanks.
I Protective magnesium anode rod—provides added protection
against corrosion for long trouble-free service.
I Factory installed dielectric waterway fittings—all heaters
equipped with special water heater nipples for longer heater life.
I Factory installed Hydrojet
inlet sediment reducing device. Helps prevent sediment build up
in tank. Increases first hour delivery of hot water while
minimizing temperature build up at top of tank.
I T&P relief valve opening—all models have special tapping on
side of tank.
I Brass drain valve.
I Collector Supply and Return—alternate locations are standard
and available on the 80 and 119 gallon (303 and 450 liter)
models only.
I Thermal Feet—unique design provides complete tank isolation.
Prevents thermal conduction through bottom of tank.
I Pre-wired sensor lead—from storage sensor mounting stud to
top of tank.
I Equipped with a 4500 watt heating element and automatic
thermostat—where a back-up system is desired.
I Six year limited warranty on steel tank—heavy gauge steel
automatically formed, rolled and welded to assure a continuous
seam for glass lining.
I Six year limited warranty on parts.
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS:
5,954,492; 5,761,379; 5,943,984; 5,081,696; 5,988,117; 6,142,216; 5,199,385;
6,684,821; 5,574,822; 5,372,185; 5,485,879; 5,277,171; (B1)5,341,770; 5,660,165;
5,596,952; 5,682,666; 4,904,428; 5,023,031; 5,000,893; 4,669,448; 4,829,983;
4,808,356; 5,115,767; 5,092,519; 5,052,346; 4,416,222; 4,628,184; 4,861,968;
4,672,919; Re. 34,534. OTHER U.S. AND FOREIGN PATENT APPLICATIONS
PENDING. CURRENT CANADIAN PATENTS: 1,272,914; 1,280,043; 1,289,832;
2,045,862; 2,112,515; 2,108,186; 2,107,012.
lining provides a tough interior surface for
® Total Performance System—cold
EFFICIENCY
U L
RATING
CERTIFIED
®
