Find where the cable fault is

Disconnect booth loop cable and guide cable (if any)
from the robot mower station. Don't forget this – your robot
mower station and/or the MS6812 may get damaged.
1
Connect the black cable to a metal piece that are
put down in the lawn/soil (i.e. a screwdriver like on the
picture) to make a ground connection.
Connect the red cable to the robot mower loop
cable while the loop cable.
2
Put the SENDER on "TONE" mode.
3
Start and turn up the volume on the RECEIVER. Push
the button and start to follow the loop wire with the
nose tip of RECEIVER. Your start point is were you did
connect the red cable to the loop cable. A beep will
indicate that the loop cable is OK.
When you carefully follow the loop wire on close distance
and the receiver does stop beeping
cable fault!
When you pass the cable
break point the receiver
will stop beeping.
you have found the
Make sure no cables are
conected to charging station
before you connect the cable
tracker!
