- Page 1 ONErack patent pending Installation Guide Chassis MNL-1RK-CHASSIS v1.10...
- Page 2 In the box 2 Side panels (identical) 6 Mounting rails 3 M3 bolt strips 24 M4 screws 1 M6 rack mounting kit 4 x In the unlikely event that a component is missing or damaged, please contact tech.usa@tvone.com or tech.europe@tvone.com ONErack...
- Page 3 To avoid damaging your ONErack, build it in a clean, tidy area. Use two M4 screws to connect each mounting rail to one side panel. Make sure each mounting rail is aligned as shown. 2. Slide an M3 bolt strip into each of three mounting rails, as shown. tvONE...
- Page 4 Copyright 2016 tvONE. All rights reserved.
