BPS-120
Stand-Alone Backup Power System
User's Guide
1.0
Version
October 2004

Advertisement

Table of Contents
loading

Related Manuals for ZyXEL Communications BPS-120

Summary of Contents for ZyXEL Communications BPS-120

  • Page 1 BPS-120 Stand-Alone Backup Power System User’s Guide Version October 2004...
  • Page 2 ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein.

  • Page 3: Information For Canadian Users

    BPS-120 User’s Guide radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. CE Mark Warning: This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

  • Page 4: Zyxel Limited Warranty

    BPS-120 User’s Guide Users should not attempt to make such connections themselves, but should contact the appropriate electrical inspection authority, or electrician, as appropriate. Note This digital apparatus does not exceed the class A limits for radio noise emissions from digital apparatus set out in the radio interference regulations of Industry Canada.

  • Page 5: Customer Support

    +33 (0)4 72 52 www.zyxel.fr 97 97 +33 (0)4 72 52 19 20 +34 902 195 www.zyxel.es +34 913 005 REGULAR MAIL ZyXEL Communications Corp. 6 Innovation Road II Science Park Hsinchu 300 Taiwan ZyXEL Communications Inc. 1130 N. Miller St.
  • Page 6 +47 22 80 61 +46 31 744 www.zyxel.se 7700 +46 31 744 7701 +358-9-4780- www.zyxel.fi 8411 +358-9-4780 8448 REGULAR MAIL ZyXEL Communications Columbusvej 5 2860 Soeborg Denmark ZyXEL Communications Nils Hansens vei 13 0667 Oslo Norway ZyXEL Communications Sjöporten 4, 41764 Göteborg Sweden...

  • Page 7: Table Of Contents

    1 Introducing the BPS-120 ... 9 2 Hardware Installation and Connections ... 9 2.1 Desktop Installation... 10 2.2 Rack-mounted Installation ... 10 2.3 Attaching Power Cables and Connector Definition... 12 2.4 Front Panel and LED Displays... 14 3 Troubleshooting... 18...

  • Page 9: Introducing The Bps-120

    1 Introducing the BPS-120 The BPS-120 is a backup power system to which you can connect up to six of ZyXEL’s devices that have a 12VDC external backup power supply connector. The BPS-120 monitors the power status of the connected devices and immediately provides backup power to a device that loses power or has a hardware power failure.

  • Page 10: Desktop Installation

    Figure 2: Attaching the Rubber Feet 2.2 Rack-mounted Installation The BPS-120 can be mounted on an EIA standard size, 19-inch rack or in a wiring closet with other equipment. Follow the steps below to mount your BPS-120 on a standard EIA rack using the included rack-mounting hardware.
  • Page 11 BPS-120 User’s Guide Figure 2 Attaching the Rack Mounting Brackets After attaching both mounting brackets, position the BPS-120 in the rack by lining up the holes in the brackets with the appropriate holes on the rack. Secure the BPS-120 to the rack with the rack’s mounting screws.

  • Page 12: Attaching Power Cables And Connector Definition

    OUTPUTs 2-6. OUTPUT 2 has backup power priority over devices connected to OUTPUTs 3-6, etc. To turn the BPS-120 on, connect the power line cord to a 100/240 VAC power outlet and move the rocker switch on the rear panel from the “0” to “1” position. The STANDBY, PWR, TEMP, and FAN LEDs will then light on the front panel.
  • Page 13 BPS-120 User’s Guide Figure 5 BPS-120 OUTPUT Port Connector Pin Diagram, and Cable...

  • Page 14: Front Panel And Led Displays

    Enabling backup power to any of six external devices is as simple as connecting the (supplied) system power cables from each OUTPUT 1-6 on the back panel of the BPS- 120 to external devices. Be sure the BPS-120 is in standby mode (the STANDBY LED) DESIGNATION...
  • Page 15 OUTPUTs 1-6. Figure 6 BPS-120 Front Panel STANDBY/ACTIVE In general the BPS-120 may be in one of the following states: ACTIVE, STANDBY, or FAULT, as indicated by their corresponding front panel LEDs shown in Figure 6. The BPS-120 also includes advanced self-diagnostic monitoring features to ensure that its own circuitry is functioning normally;...
  • Page 16 Each rear panel OUTPUT port has a corresponding (GREEN, RED, AMBER) LED to indicate its own state as shown in Figure 7 and Table 3 and Table 4. Typically the system operator need only monitor the LED indicators on the BPS-120 front panel to ensure externally connected systems are operating normally.
  • Page 17 Table 4 BPS-120 Front Panel DC Output LEDs State Definitions PORT LED COLOR INDICATIONS OUTPUT STATUS Green CONNECTION Amber CONNECTION CONNECTION ACTIVE Green ACTIVE Amber ACTIVE INACTIVE Green INACTIVE Amber INACTIVE POWER Green FEEDING POWER Amber FEEDING POWER FEEDING STANDBY...

  • Page 18: Troubleshooting

    STATUS DEVICE Amber FAULT DEVICE FAULT 3 Troubleshooting Make sure that the BPS-120 is plugged into an appropriate AC power supply. Table 5 BPS-120 Troubleshooting Tips PROBLEM The STANBY Faulty or not connected AC power supply. LED is off. The STANDBY The BPS-120 is in standby mode.
  • Page 19 The FAN LED is Fan speed is wrong (too fast, red. too slow) or one of the four fans has stopped operating. Table 6 Technical Specifications for the BPS-120 AC Input Voltage Power Operating Temperature Storage Temperature Operational Humidity...
  • Page 20 Table 6 Technical Specifications for the BPS-120 Safety UL 60950-1 CSA 60950-1 EN60950-1 IEC-60950-1 FCC Part15 (Class A) CE EMC (Class A)
