HumPRC
Series Master Development System
TM
Handheld Transmitter Quick Start Reference
Remove Contents
1
Remove the boards, antennas, batteries and
connectors.
Set Up Board
2
Install batteries and an antenna on the board.
Activate
4
S0
S1
Push S0 to activate buzzer and push S1 to
turn on the LED.
Power On
3
Turn on the power switch.
Buzzer
LED
Revised 9/25/2017
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Linx Technologies HumPRC Series
Summary of Contents for Linx Technologies HumPRC Series
- Page 1 HumPRC Series Master Development System Handheld Transmitter Quick Start Reference Remove Contents Set Up Board Power On Remove the boards, antennas, batteries and Install batteries and an antenna on the board. Turn on the power switch. connectors. Activate Buzzer Push S0 to activate buzzer and push S1 to turn on the LED.
- Page 2 Pairing the Transmitter and Evaluation Board The Handheld Transmitter and the Evaluation Board come pre-paired in the kit. This procedure can be used to pair additional transmitters. Set the Administrator Pair the Devices MODE_IND Window PAIR Button Press and hold the PAIR button for 30 seconds Press the PAIR button on the evaluation to set the module on the evaluation board as board and on the back of the transmitter...
