Industrial Electronic Devices
User Manual
Revision 1.100
English
GSM I/O and Alarms Modem
for Website information:
www.adfweb.com?Product=HD67302
for Price information:
www.adfweb.com?Price=HD67302-B2-02
www.adfweb.com?Price=HD67302-B2-20
www.adfweb.com?Price=HD67302-B2-11
Benefits and Main Features:
Very easy to configure
SMS / Call to get/trigger an input/output
Wide power input range
Temperature range: -20°C / +70°C (-4°F / +158°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual GSM I/O and Alarms Modem
Document code: MN67302_ENG
Analyzer / Scanner /Sniffer, M-Bus
www.adfweb.com?Product=HD67031
Multi-Drop Converter RS232/RS485 to Optic Fiber
www.adfweb.com?Product=HD67033M
www.adfweb.com?Product=HD67034M
HD67302-B2-xx
www.adfweb.com?Product=HD67035M
www.adfweb.com?Product=HD67036M
Isolator & Repeater, RS485
www.adfweb.com?Product=HD67149-A1
CAN, CANopen, J1939, DeviceNet, NMEA2000 Analyzer
www.adfweb.com?Product=HD67316
CAN, CANopen, J1939, DeviceNet, NMEA2000 from/to USB
www.adfweb.com?Product=HD67390
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 1.100
Page 1 of 35
(RS232, SL)
(RS232, DL)
(RS485, SL)
(RS485, DL)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Web HD67302-B2 Series
Summary of Contents for ADF Web HD67302-B2 Series
- Page 1 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 1 of 35 Industrial Electronic Devices User Manual Revision 1.100 English GSM I/O and Alarms Modem for Website information: www.adfweb.com?Product=HD67302 for Price information: www.adfweb.com?Price=HD67302-B2-02 www.adfweb.com?Price=HD67302-B2-20 www.adfweb.com?Price=HD67302-B2-11 Analyzer / Scanner /Sniffer, M-Bus www.adfweb.com?Product=HD67031 Benefits and Main Features: Multi-Drop Converter RS232/RS485 to Optic Fiber...
-
Page 2: Updated Documentation
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 2 of 35 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you Page INDEX that you need to check that the following document is: UPDATED DOCUMENTATION Updated REVISION LIST... -
Page 3: Security Alert
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 3 of 35 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 4 of 35 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 5 of 35 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67302-B2-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 6 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 6 of 35 Industrial Electronic Devices CHARACTERISTICS: The GSM I/O and Alarms Modem is a powerful, flexible and economic instrument which is used to control Digital and Analog I/O by SMS or Phone Call.
-
Page 7: Power Supply
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 7 of 35 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. The consumption depends to the code of the device. For more details see the two tables below. -
Page 8: Function Modes
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 8 of 35 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device; The second, with ‘Dip1 of Dip-Switch A’... - Page 9 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 9 of 35 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
- Page 10 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 10 of 35 Industrial Electronic Devices GSM: The HD67302 uses a Quad-band GSM/GPRS module and allows to send/receive SMS and phone call. The Antenna connector is a SMA Female (‘Female Outer Shell’ and ‘Female Receptacle’) so the Antenna must have a SMA Male connector.
-
Page 11: Digital Inputs
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 11 of 35 Industrial Electronic Devices DIGITAL INPUTS: Depending on the product code, you can identify what kind of inputs you have: HD67302-B2-02: 2 Digital Inputs with driving on Positive wire; HD67302-B2-20: 2 Digital Inputs with driving on Negative wire;... - Page 12 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 12 of 35 Industrial Electronic Devices OSITIVE WIRE CONTROL In this case the Input have a fixed signal that is the ground of the signal (Pin 2 / 4) and to the other Pin (1 / 3) there is the positive signal that can be applied or not.
-
Page 13: Digital Output
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 13 of 35 Industrial Electronic Devices DIGITAL OUTPUT: The Digital Output are clean contact relay NO (normally opened). Description Port Relay contact Digital Output 1 (DO1) Relay contact Relay contact Digital Output 2 (DO2) Relay contact... -
Page 14: Analog Input
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 14 of 35 Industrial Electronic Devices ANALOG INPUT: The Analog Input is 0…10V DC type. The conversion is made by a 10-bit ADC. Description Port Negative wire Analog Input (AI) Positive wire (max 10V DC) Warning: Maximum voltage applied: 10V DC... - Page 15 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 15 of 35 Industrial Electronic Devices USB: The USB port is used to program the module. It is necessary to use a Micro USB type B cable. ADFweb.com Srl –...
- Page 16 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 16 of 35 Industrial Electronic Devices USE OF COMPOSITOR SW67302: To configure the Alarm Modem use the available software that runs with Windows called SW67302. It is downloadable on the site www.adfweb.com and its operation is described in this document.
-
Page 17: New Configuration
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 17 of 35 Industrial Electronic Devices NEW CONFIGURATION: By pressing the “New Configuration” button it is possible to create a new project. It is possible to define the name and the device type. Press “OK”... -
Page 18: Load Configuration
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 18 of 35 Industrial Electronic Devices LOAD CONFIGURATION: By pressing the “Load Configuration” button it is possible to load an existing project by selecting one of the list that appears. A device configuration can also be imported or exported: To clone the configurations of a GSM I/O... -
Page 19: Device Setting
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 19 of 35 Industrial Electronic Devices DEVICE SETTING: By pressing the “Phone Setting” button, it is possible to select the device type and the general setting for the management of the SIM card. -
Page 20: Input Setting
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 20 of 35 Industrial Electronic Devices INPUT SETTING: IGITAL ETTING The Alarm Modem has two Digital Input. For both of them it is possible to define the alert by SMS. There are two possibilities: Sending a SMS when the Input changing from 0 to 1 by checking the field... - Page 21 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 21 of 35 Industrial Electronic Devices NALOG ETTING The Alarm Modem has an Analog Input. It is possible to define the alert by SMS. There are two possibilities: Sending a SMS when the Input goes above a certain threshold voltage by checking the field...
-
Page 22: Output Setting
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 22 of 35 Industrial Electronic Devices OUTPUT SETTING: The device has two Digital Output. For both of them it is possible to define the modality of setting (SMS or phone call). By pressing the field “SMS”... - Page 23 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 23 of 35 Industrial Electronic Devices If the field “Enabled on Phone Number” is checked, only the phone number written in the table is able to do the operation to the Digital Output;...
- Page 24 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 24 of 35 Industrial Electronic Devices By pressing the field “CALL” it is possible to enable the function of change the state of output using a phone call. There are three types of operations: “Automatic hang Up after Hang Up Risings...
- Page 25 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 25 of 35 Industrial Electronic Devices For all operations, there are the three possibilities: “Set output”, used for closing the relay contact; “Reset output”, used for opening the relay contact; “Impulse output”, used for making an impulse with a defined duration.
- Page 26 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 26 of 35 Industrial Electronic Devices PROFILES: By pressing the “Prfoiles” button it is possible to set the Profiles inside the Alarm Modem. The Profiles are used to define which phone numbers can control the Digital Outputs in which day/time.
- Page 27 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 27 of 35 Industrial Electronic Devices AILY There is the possibility to define up to three Daily Profile “Daily”. For enabling the Profile, the field “Enable Profile Daily X”...
-
Page 28: Date And Time Setting
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 28 of 35 Industrial Electronic Devices DATE & TIME SETTING: By pressing the “Date Time Setting” button it is possible to change the Date & Time of the device. &... -
Page 29: Update Device
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 29 of 35 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button it is possible to load the created Configuration into the device; and also the Firmware, if it is necessary. In order to load the parameters or update the firmware in the device, follow these instructions: Connect the USB cable from your PC to the... - Page 30 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 30 of 35 Industrial Electronic Devices Note: When you install a new version of the software it is better if the first time you do the update of the Firmware in the HD67302 device. Note: When you receive the device, for the first time, you have to update also the Firmware in the HD67302 device.
-
Page 31: Software Preferences
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 31 of 35 Industrial Electronic Devices SOFTWARE PREFERENCES: By pressing the “Software preferences” button it is possible to define the preferences of the software. Figure 15: “Software preferences” window ADFweb.com Srl –... -
Page 32: Mechanical Dimensions
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 32 of 35 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 16: Mechanical dimensions scheme for HD67302-B2-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 33: Ordering Informations
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 33 of 35 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67302 – B 2 – xx Digital Input Type 02 = two Digital Input with Positive wire control 20 = two Digital Input with Negative wire control... - Page 34 User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 34 of 35 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
-
Page 35: Warranties And Technical Support
User Manual GSM I/O and Alarms Modem Document code: MN67302_ENG Revision 1.100 Page 35 of 35 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
