Summary of Contents for Iconix FX15+
-
Page 3: Table Of Contents
CONTENTS ........................3 SYSTEM CARE Essential Care .......................... 3 Battery Care..........................3 Site Preparation ........................3 OPERATING INSTRUCTIONS ......................4 Getting Started ......................... 4 Mode Key ..........................5 Weigh Key ..........................5 Delete Key ..........................5 Draft Key ..........................5 Stats Key ..........................6 Clearing Statistics........................ - Page 4 The information in this manual is subject to change without notice and should not be construed as a commitment by Iconix New Zealand Ltd. Great care has been taken to verify the accuracy of this manual, however Iconix New Zealand Ltd assumes no responsibility for any technical inaccuracies...
-
Page 5: System Care
BATTERY LIFE WILL BE CONSIDERABLY SHORTENED IF IT IS NOT PROPERLY CARED FOR Always recharge the battery with the Iconix AC Adaptor provided for 8 - 12 hours AFTER USE with the loadbars disconnected from the indicator. For long term storage, recharge ONCE PER MONTH with the loadbars disconnected. -
Page 6: Operating Instructions
Connect the two loadbar cables to the loadbar sockets marked on the rear of the indicator. Either: Use the internal rechargeable battery Use the Iconix AC adaptor Attach the optional battery cable to the FX15+ and clip onto a 12V DC battery (car, ―... -
Page 7: Mode Key
MODE KEY The MODE key allows the operator to change the weighing mode to FREE mode or one of three variations on HOLD mode, as indicated by the HOLD pointer on the display. ‘HOLD’ HOLD Mode Pressing WEIGH starts an averaging process, which then displays the accurate weight of the moving animal. -
Page 8: Stats Key
STATS KEY Statistics are stored in a single file in permanent memory. Normally statistics would be cleared at the start of a new weighing session. Alternatively the operator may wish to add new weighings to a previous weighing session. Scroll through the statistics with the STATS key. Flashing digits indicate that statistics are being displayed. -
Page 9: User Set-Up
3. USER SET-UP NOTE: Most FX15+ settings apply only to the currently connected scale eg. standard loadbars on Scale 1. Changing these settings has no effect on the other two scales. Some settings apply to all possible scales (1: standard loadbars, 2: vet or other scale base, 3: heavy-duty loadbars). - Page 10 2Er0.1 4. ZERO-TRACKING On (default) 2Er0.0 Zero-tracking is a feature which automatically restores the scale to zero, by “tracking out” small amounts of dung and dirt left on the scale. It should be enabled for most weighing applications. Use ZERO ( ) to change the setting.
-
Page 11: Specifications
4. SPECIFICATIONS FX15+ Version 6.01 onwards (P6.01 is shown at switch-on), 2019 onwards Supply Voltage: Nominal ..12V DC Maximum ..19V DC Reverse polarity protection diode fitted. Low Battery Indication: Below approximately 11.6V the LOW BAT pointer will be on. The FX15+ switches off at approximately 10V. - Page 12 STEEL LOADBAR SET 2000kg HEAVY DUTY LOADBAR SET 3000kg Page 10 FX15+ Manual 06Nov19...
- Page 13 23 Matipo Street, Palmerston North, New Zealand Ph 64-6-3501528 www.iconix.co.nz...
