P-202H Plus v2
ISDN Internet Access Router

Quick Start Guide

Version 3.40
6/2006
Edition 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P-202H Plus v2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZyXEL Communications P-202H Plus v2

Summary of Contents for ZyXEL Communications P-202H Plus v2

  • Page 1: Quick Start Guide

    P-202H Plus v2 ISDN Internet Access Router Quick Start Guide Version 3.40 6/2006 Edition 1...

  • Page 2: Hardware Connections

    Overview The P-202H Plus v2 is an ISDN router with a four-port built-in switch. It is equipped with two integrated phone ports for connecting analog phones and/or fax devices. It also provides advanced calling features, such as call waiting, three-way calling, call transferring and forwarding.

  • Page 3: Initial Configuration

    5 Push in the POWER button. Look at the LEDs on the front panel. • The POWER LED blinks while your P-202H Plus v2 starts up and stays on once the system is ready. • The ISDN and ETHERNET LEDs stay on if the corresponding port is properly connected and blinks when there is traffic.
  • Page 4 5 Click Wizard Setup in the main menu to display the first wizard screen. 6 Use this screen to configure your ISDN line and how the P-202H Plus v2 handles incoming calls. Select from the B Channel Usage dropdown box. If you are using both B channes, select Switch/Switch (default).
  • Page 5 If you select Don't Care, then all data calls are routed to the P-202H Plus v2 itself. Analog calls, however, are routed to either A/B adapter 1 or 2, or simply ignored, depending on the Analog Call Routing field. If Incoming Phone Number Matching is Don't Care and Analog Call Routing is either A/B Adapter 1, A/B Adapter 2 or Both, then the P-202H Plus v2 uses Global Analog Call to decide how to handle global calls.
  • Page 6 192.168.1.1 (factory default). Enter a subnet mask in dotted decimal notation in the LAN Subnet Mask field. Note: If you change the P-202H Plus v2's LAN IP address, you must use the new IP address if you want to access the web configurator again.

  • Page 7: Troubleshooting

    This section shows you how to set your Windows NT/2000/XP computer to automatically get an IP address. This ensures that your computer can communicate with your P-202H Plus v2. Refer to your User’s Guide for detailed IP address configuration for other Windows and Macintosh computer operating systems.
  • Page 8 1 Go to http://www.zyxel.com. 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page. P-202H Plus v2 Quick Start Guide...
