Getting Up and Running
In This Chapter
Preparing the camera for its first outing
Getting acquainted with camera features
Viewing and adjusting camera settings
Setting a few basic preferences
Restoring original camera settings
S
hooting for the first time with a camera as sophisticated as the Nikon
D3300 can produce a blend of excitement and anxiety. On one hand, you
can't wait to start using your new equipment, but on the other, you're a little
intimidated by all its buttons, dials, and menu options.
Well, fear not: This chapter provides the information you need to
start getting comfortable with your D3300. The first section
walks you through initial camera setup; following that, you
can get an overview of camera controls, discover how
to view and adjust camera settings, and get my take
on some basic setup options.
Preparing the Camera
for Initial Use
After unpacking your camera, you have to assemble
a few parts. In addition to the camera body and the
supplied battery (be sure to charge it before the first
use), you need a lens and a memory card. Later sections
in this chapter provide details about working with lenses and
memory cards, but here's what you need to know up front:
Lens: You can mount a wide range of lenses on your D3300, but some
aren't compatible with all camera features. For example, to enjoy auto-
focusing, you need an AF-S or AF-I lens. (The 18–55mm lens sold in a kit
with the D3300 body is an AF-S lens.) Your camera manual offers details
about lens compatibility.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the D3300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nikon D3300

  • Page 1 ✓ Lens: You can mount a wide range of lenses on your D3300, but some aren’t compatible with all camera features. For example, to enjoy auto- focusing, you need an AF-S or AF-I lens. (The 18–55mm lens sold in a kit with the D3300 body is an AF-S lens.) Your camera manual offers details...
  • Page 2 Part I: Fast Track to Super Snaps The AF in AF-S stands for autofocus, and the S stands for silent wave, a Nikon autofocus technology. AF-I lenses are older, professional-grade (expensive) lenses that are no longer made but may be available on the secondhand market.
  • Page 3 7 . If using the 18–55mm kit lens, unlock and extend the lens. The kit lens sold with the D3300 is a pancake lens, which means that when you ’ re not shooting, you can retract the lens barrel so that the...
  • Page 4 Part I: Fast Track to Super Snaps a picture, you must unlock and extend the lens. (This applies to any retractable lens, not just the kit lens.) Figure  1-3 shows the lens in its retracted (left image) and extended (right image) positions. To extend the lens, press the lens lock button, highlighted in Figure ...
  • Page 5 To that end, the upcoming pages provide an overview of the D3300’s main features and also offer a primer on working with lenses and memory cards.
  • Page 6 Part I: Fast Track to Super Snaps corner of the camera back). In M (manual exposure) mode, press this button while rotating the Command dial to adjust the aperture setting. ✓ Info button: This button performs two functions depending on whether you’re using the viewfinder to frame shots or taking advantage of Live View, the feature that enables you to see the live scene on the monitor.
  • Page 7 Chapter 1: Getting Up and Running ✓ Movie-Record button: After shifting to Live View mode, press this button to start recording a movie. Press again to stop recording. (You can’t use the viewfinder when recording movies.) ✓ Mode dial: With this dial, you choose the exposure mode, which determines how much control you have over camera settings.
  • Page 8 Part I: Fast Track to Super Snaps Figure 1-6 : Use the Multi Selector to navigate menus and access certain other camera options. ✓ Command dial: After you activate certain camera features, you rotate this dial to select a setting. For example, to choose a shutter speed when shooting in shutter-priority (S) mode, you rotate the Command dial.
  • Page 9 Chapter 1: Getting Up and Running photo or movie at a time, to thumbnails view, which displays mul- tiple images on the screen. Press once to display four thumbnails; press again to display nine thumbnails; and press a third time to see 72 itty-bitty thumbnails.
  • Page 10 Fn button has no result in those modes. ✓ Microphone: The three little holes just above the silver D3300 label lead to the camera’s internal microphone. See Chapter  8 to find out how to disable the microphone if you want to record silent movies.
  • Page 11 USB port on the computer for picture downloading. The same camera port enables you to connect the camera to a television via an A/V cable for picture playback. Nikon supplies the cables you need for both con- nections in the camera box; see Chapter  9 for information on television connections and Chapter ...
  • Page 12 Part I: Fast Track to Super Snaps ✓ HDMI port: You can use this port to connect your camera to a high- definition TV, but you need to buy an HDMI cable to do so. Look for a Type C mini-pin cable. Chapter  9 offers details on television playback. If you turn the camera over, you find a tripod socket, which enables you to mount the camera on a tripod that uses a 1/4-inch screw, plus the battery chamber.
  • Page 13 Although I appreciate the idea of the guided menus, I have a few quibbles about how they’re implemented on the D3300. First, you can’t access all your camera’s features through the guided menus. Second, some choices Nikon made for the arrangement of the guided menus set you up for confusion down the line.
  • Page 14 In the menu screens, the icon that’s highlighted or appears in color is the active menu; options on that menu automatically appear to the right. In the figure, the Shooting menu is active, for example. Table 1-1 D3300 Menus Symbol Open This Menu . . .   . . . To Access These Functions...
  • Page 15 Chapter 1: Getting Up and Running selected item then appear. For example, if you select the Image Quality item from the Shooting menu, as shown on the left in Figure  1-12 , and press OK, the available Image Quality options appear, as shown on the right in the figure.
  • Page 16 Part I: Fast Track to Super Snaps Switching to Live View mode Like many dSLR cameras, the D3300 offers Live View, a feature that enables you to use the monitor instead of the viewfinder to compose photos. Turning on Live View is also the first step in recording a movie; using the viewfinder isn ’...
  • Page 17 Slide the rubber eyecup that surrounds the viewfinder up and out of the groove that holds it in place; then slide the cover down into the groove. (Orient the cover so that the Nikon label faces the viewfinder.) ✓...
  • Page 18 (In the United States and Canada, the standard frequency is 60 Hz; in Europe, it’s 50 Hz.) Viewing critical picture settings Your D3300 gives you the following ways to monitor the most important picture-taking settings: ✓ Information screen (viewfinder photography): The left screen in Figure  1-15 gives you a look at the Information screen available for viewfinder pho- tography.
  • Page 19 Chapter 1: Getting Up and Running ✓ Live View display: When you press the LV button to switch to Live View mode, the shooting data appears atop the live preview. (Refer to the right side of Figure  1-15 .) You can vary the type of data displayed by pressing the Info button;...
  • Page 20 Part I: Fast Track to Super Snaps Adjusting settings via the control strip Found on the lower-left corner of the camera back, the i button activates a control strip that gives you quick access to some critical shooting settings. Here’s how to use the control strip for viewfinder photography: 1 .
  • Page 21 Because I don’t know which lens you ’ re using, I can’t give you full instruc- tions on its operation. But the following basics apply to most Nikon AF-S lenses as well as to certain other lenses that support autofocusing — you should explore the lens manual for specifics, of course: ✓...
  • Page 22 Part I: Fast Track to Super Snaps ✓ Focusing: First, set the lens to automatic or manual focusing by moving the focus-method switch on the lens. For example, Figure  1-19 shows the switch as it appears on the 18–55mm kit lens. On this lens, move the switch to the A position for autofocusing and to M for manual focusing.
  • Page 23 ✓ Enabling Vibration Reduction: Many Nikon lenses, including the kit lens, offer Vibration Reduction, which compensates for small amounts of camera shake that can occur when you handhold the camera. Camera movement during the exposure can produce blurry images, so turning on Vibration Reduction can help you get sharper handheld shots.
  • Page 24 35mm-equivalent measuring stick of those kinds of cameras are likely to shoot. as a standard. With the D3300, the crop factor is roughly 1.5. In the figure here, the red line indi- A lens with a focal length under 35mm is char- cates the image area that results from the 1.5...
  • Page 25: Working With Memory Cards

    Chapter 1: Getting Up and Running Working with Memory Cards As the medium that stores your picture files, the memory card is a critical component of your camera. See the steps at the start of this chapter for help installing a card; follow these tips for buying and maintaining cards: ✓...
  • Page 26 Part I: Fast Track to Super Snaps ✓ Locking cards: The tiny switch on the side of the card, labeled Lock switch in Figure  1-20 , enables you to lock your card, which prevents any data from being erased or recorded to the card.
  • Page 27 SLR camera to avoid camera shake when shooting long-exposure images, note that as the menu name implies, this camera ’ s mirror lock-up is pro- vided for cleaning purposes only. You can’t take pictures on the D3300 while mirror lock-up is enabled.
  • Page 28 Part I: Fast Track to Super Snaps This setup can create a scenario where you wind up with multiple images that have the same file- name — not on the current memory card, but when you download images to your com- puter. So set the option to On. (Refer to Figure ...
  • Page 29: Restoring Default Settings

    C and L. At the time this book was written, C was version 1.00; L was 2.002. Keeping your camera firmware up to date is important, so visit the Nikon website ( www.nikon.com ) regularly to find out whether your camera sports the latest version.
  • Page 30 Part I: Fast Track to Super Snaps Additionally, a Shooting menu reset restores the default settings of a couple options not on the menu, including the Release mode, Exposure Compensation, Flash Compensation, Flash mode, Focus mode, and selected focus point. Finally, the AE-L/AF-L button returns to its normal operation as well.
