Wisi Micro Node Operating Instructions page 2

Blockdarstellung / Block diagram
Fiber In
Bohrlochabstand / Drilling jig spacing
0...20 dB
Optical
power
detection
RF Test Port
LED:
DS level
Optical input probe:
1 V / mW
148 mm
Output
20 dB
jumper:
Low / high
3 dB
level
RF In / Out
LR91 – FttH Node
