Summary of Contents for Boyo AVD701
- Page 1 AVD701 OWNER’S MANUAL Mobile Video System DVD Player with Radio 7 Inch Touch Screen Monitor RBDS Function My Music Operation Bluetooth Function USB Interface SD/MMC Card Interface Remote Control...
-
Page 2: Table Of Contents
CONTENTS SAFETY INFORMATION……………………………………………………..3 DISC NOTES………………………………...……………………..5 INSTALLATION……………………………………………...………..7 CONNECTIONS………...………………………………………….………...8 LOCATIONS AND FUNCTION OF THE PLAYER…………………...9 LOCATIONS AND FUNCTION OF THE REMOTE CONTROL…..…...11 BASIC OPERATION…………………………………………...…….…...14 MENU OPERATION…………………………………………………...…...16 RADIO OPERATION…………………………………………………….……….……..16 DISC OPERATION……………………………………………………..…………...….19 BLUETOOTH OPERATION..…………………...……………………..………...…..26 SD/USB OPERATION…………………………………………..……………….……..28 MY MISIC OPERATON ……………………….…….…………………….……….…..29 AV IN OPERATION……………………………………………………………………..30 REARVIEW OPERATION………………………………………………….…………..30 SETUP OPERATION…….……………………………………………….…...………..30 TROUBLE SHOOTING………………………………………...…...….…..33 SPECIFICATIONS……………………………………………………..…….35... -
Page 3: Safety Information
SAFETY INFORMATION Use This Product Safely This unit has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit protect you if you observe the following procedures for installation, use and servicing. - Page 4 SAFETY INFORMATION CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE MOBILE DVD PLAYER CORRECTLY AS INSTRUCTED. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
-
Page 5: Disc Notes
DISC NOTES Disc formats supported by this player 12 cm disc (Single-sided disc only) Video CD 12 cm disc 12 cm disc 12 cm disc Handling and Cleaning Dirt, dust, scratches and warping discs will cause wrong operation. Do not place stickers or make scratches on discs. Do not warp discs. - Page 6 DISC NOTES Preparing New Discs with Rough Spots A new disc may have rough edges on its inside and outside edges. If a disc with rough edges is used, the proper setting will not be performed and the player will not play the disc.
-
Page 7: Installation
INSTALLATION Notes: Choose the mounting location where the unit will not interfere with the normal driving function of the driver. Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. Use only the parts included with the unit to ensure proper installation. -
Page 8: Connections
CONNECTIONS Line No. Line color Black Black Black Grey Green Green Black Function (terminal color) Video input (YELLOW) Audio input right (RED) Audio input left (WHITE) Video output (YELLOW) Rearview input (YELLOW) Subwoofer output (GREEN) Radio antenna connector (BLACK) -
Page 9: Locations And Function Of The Player
LOCATIONS AND FUNCTION OF THE PLAYER KEYS ON THE FRONT PANEL WHEN THE MONITOR TURNING DOWN:... -
Page 10: Locations And Function Of The Player
LOCATIONS AND FUNCTION OF THE PLAYER /SRC: In power off status, press it to turn the unit on. Press it for several seconds to turn off the unit. In normal working status, press it to select the desired source mode, such as DVD, RADIO, AV IN, SD/USB …... -
Page 11: Locations And Function Of The Remote Control
LOCATIONS AND FUNCTION OF THE REMOTE CONTROL... -
Page 12: Locations And Function Of The Remote Control
LOCATIONS AND FUNCTION OF THE REMOTE CONTROL Press it to turn on the unit. When the unit is on, press it to turn the unit off. 2. MODE When the unit is on, press it to select the different mode, such as RADIO, DISC, AV IN, SD/USB mode. - Page 13 LOCATIONS AND FUNCTION OF THE REMOTE CONTROL 23. SEEK- / SEEK+ Press shortly to skip to the previous/next track. Press and hold it to activate fast reverse/forward function. In radio mode, press it shortly to search the frequency backward/forward manually. Press and hold it to seek the frequency automatically.
-
Page 14: Basic Operation
BASIC OPERATION TURNING ON/OFF THE UNIT Press button on the front panel or on the remote control to turn the unit on. When the unit is on, press button on the front panel for several seconds or press the remote control will turn the unit off. PANEL ANGLE ADJUST The front monitor panel can be turn down or turn up to some degree by using buttons on the front panel. -
Page 15: Brake Function
BASIC OPERATION Note: If there isn’t any disc in the disc slot, DISC mode will be skipped. BRAKE FUNCTION If the brake wire (pink wire) isn’t connected to the ground (when driving), the video picture will not be shown on the screen in DISC/AV/USB/SD mode for safety purpose. Only the audio will be heard. -
Page 16: Menu Operation
MENU OPERATION MAIN MENU In the current mode, click Click the different icon on the interface to enter into the desired mode. The following contents will introduce the different functions the unit provides. Click icon to enter into the Setting interface. Click interface and return to the current mode. -
Page 17: Station Storing
MENU OPERATION press AMS icon on the screen, the radio searches from the current frequency and checks the signal strength until one cycle search is finished. And then stations are stored into the preset number button in turn according to the strength of the stations. - Page 18 MENU OPERATION EQUALIZATION ※ EQ--- click to change the equalization mode, such as OFF, ROCK, JAZZ, CLAS. RBDS OPERATION ※ a) Click TA icon on the screen to switch TA on or off. When TA on, the unit will search Traffic Announcement automatically. When received a Traffic Announcement station, the unit will change to the Traffic Announcement station automatically.
-
Page 19: Disc Operation
MENU OPERATION 2. DISC OPERATION If there is no disc in the disc slot, in any mode press slide down the monitor panel then insert a disc into the disc slot, the unit will switch to the Disc mode and play the disc automatically. If there is a disc in the disc slot, press button on the remote control or tap [DISC] icon on the MENU interface to change the mode to DISC mode, then the unit will play the disc automatically. -
Page 20: Pausing Play
MENU OPERATION the remote control during playback will skip to the previous/next track. Note: For some VCD2.0 discs (PBC-playback control), icons may be unavailable. Note you can use the numeric buttons (0-9) and 10+ button on the remote control to select the track directly. ※... -
Page 21: Repeat Play
MENU OPERATION 1) Item: TT Function: Display the current title number and total title number. 2) Item: CH Function: Display the current chapter number and total chapter number. 3) Item: (This icon only displayed for several seconds, after several seconds it will disappeared.) Function: Display the played time of the current chapter. -
Page 22: Zoom Function
MENU OPERATION ※ GOTO FUNCTION FOR DVD: Press GOTO button on the remote control, the screen will display the information as followed: Use the numeric buttons and input the desired Title, Chapter or Time, then press ENTER button on the remote control to confirm. - Page 23 MENU OPERATION Multi-angle Function Press Angle button on the remote control during playback. The corresponding information will be shown on the screen. Each time the button is pressed, the angle changes in sequential order. Notes: The angle number is different according to the disc. The function only works for discs having scenes recorded at different angles.
-
Page 24: Dvd Setup
MENU OPERATION EQ--- Click to change the equalization mode, such as OFF, ROCK, JAZZ, ※ CLAS. --- Click to mute the sound, click it again to resume the sound. ※ ※ DVD SETUP In DISC mode, when the disc is playing or in stop mode, press Setup on the remote control to enter setup menu. -
Page 25: Language Setup
MENU OPERATION 5PG-R, 6R, 7NC-17, 8ADULT. * DEFAULT: Restore the system setup to the default setup. 2) LANGUAGE SETUP When you open the language setup menu, you will see the language setup page: You can change the OSD LANGUAGE among: English, German, Spanish, French, Portuguese, and Russian. -
Page 26: Digital Setup
MENU OPERATION You can adjust the value of the brightness, contrast, hue, saturation and sharpness. 5) DIGITAL SETUP When you open the DIGITAL menu, you will see the following picture: * OP MODE: to set the operating modes for Dolby Digital decoder, there are LINE OUT and RF REMOD to be selected. - Page 27 MENU OPERATION Before you read this Bluetooth instruction please note the following points: a) The Bluetooth function is optional, you just can use this function which you bought the products including Bluetooth function. b) This function needs your mobile phone support Bluetooth. c) The initial secret code is “0000”.
-
Page 28: Sd/Usb Operation
MENU OPERATION During playing, click remote control during playback will skip to the previous/next track. Click on the screen or press normal playback. Click to stop normal playback. Note: when playing music, you can not make any phone call. When there is an incoming call, you can choose to answer it or not. -
Page 29: My Misic Operaton
MENU OPERATION Note the SD/MMC interface on the right is for SD operation. When you insert the SD card, it will enter into the SD play interface. In the main menu click [SD/USB] icon to enter into the SD play interface. You can select the audio, photo, video files to play. -
Page 30: Av In Operation
MENU OPERATION 6. AV IN OPERATION On the front panel of the unit, there is an auxiliary input jack AV IN. On the back of the unit, there is also a group auxiliary input jacks. You can connect the auxiliary device from these jacks. - Page 31 MENU OPERATION ※ System TIME ZONE --- Click the hour or minute that you want to change, then click the ‘-’ and ‘+’ to adjust the value. Click 12 or 24 to select 12 hour time format or 24 hour time format.
-
Page 32: Touch Calibration
MENU OPERATION --- RGB (Chroma) adjustment Click ‘+’ and ‘-’ to adjust the value of brightness, contrast and RGB. --- click to back to main menu interface. ※ DSP PRESET EQ Click the different icon on the picture to select the corresponding equalization mode: Rock, Jazz, Standards and Classical. -
Page 33: Troubleshooting Guide
TROUBLESHOOTING GUIDE What might appear to be a malfunction in your unit may just be the result of slight misoperation or miswiring. Before calling service, first check the following table for possible problems. Under no circumstances should you try to repair the player yourself, as this will invalidate the warranty. -
Page 34: Troubleshooting Guide
TROUBLESHOOTING GUIDE No video image appears. The unit is not connected to the parking brake detection switch. Make proper connections. The parking brake is not engaged. For safety reasons no television/video images are displayed while the vehicle is moving. Engaging the parking brake will cause images to be displayed. The sound quality is poor or distorted. -
Page 35: Specifications
SPECIFICATIONS GENERAL Power Supply Requirements Maximum Output Power Current Drain RADIO Frequency Coverage Sensitivity (S/N=30dB) Image Rejection Stereo Separation Frequency Coverage Sensitivity (S/N=20dB) Image Rejection Signal system: Discs played: Monitor Screen Size: Solution: Note: Specifications and design are subject to modification, without notice, due to improvements in technology.
