Team C MINION Manual page 34

9
Steering Servo
Lenk Servo
10
Buffer
Servo Saver
TR4049
Servo Saver Body
Servo Saver Gehäuse
TR4012
Servo Saver-Top
Servo Saver oben
T02059
T02059 Ball stud-Long
Kugelkopf lang
............3
TR4060 M3 Screw
Schraube
............2
T02059
TR4012
Servo Saver-Bottom
Servo Saver unten
TR4049
Servo Saver Spring
Servo Saver Feder
TR4049
Servo Saver Nut
Servo Saver Mutter
TR4058 M3x8
TR4060 M3
Approx.5mm
circa.5mm
5
TR4058 M3x8 Screw
Schraube
..................2
TR4012
Servo Saver-Left
Servo Saver links
TR4013
Steering Rack
Lenkplatte
TR4060 M3
T02059
