  • Page 1 BEL: V1/1 Babymore Ltd INSTRUCTIONS BEL COT/BED Babymore P a g e...

  • Page 2: Instructions For Safe Use

    • WARNING: Do not use the cot/bed if any part is broken, torn or missing and use only spare parts approved by Babymore. • WARNING: Do not leave anything in the cot or place the cot close to another product which could provide a foothold or present a danger of suffocation or strangulation, e.g.

  • Page 3: Before Assembly

    Thank you for purchasing Babymore, if you need assistance, spare parts or you are unhappy with the goods 020 3475 5588 customerservices@babymore.co.uk Call : Or email us Improper assembly can result in damage to your furniture or cause harm to your child. Proper assembly is cri cal to ensure a safe and comfortable end result.
  • Page 4 COMPONENTS Item Descrip on Item Descrip on Cot End Drawer Centre Drop Side Drawer Base Fixed Side Runner Base Slat Bo om Bar Base Side Support Cot End Feet A Drawer Front Cot End Feet B Drawer Back Bed Side Support Drawer Le Bed Convert Bar P a g e...
  • Page 5 ASSEMBLING THE COT A / Pin x 10 B / Cam x 10 Step 1 Assembly of drawer as show, with (A) Pin and (B) Cam provided. C / Bolts 25mm x 6 E /Dowels 30mm x4 D / Bolts 55mm x 8 Step 2 Attach runners onto both ends, as shown,...
  • Page 6 D / Bolts 55mm x 4 Step 3 Choose 1 of 3 base positions, align and connect base side support to the two ends, with (D) Bolts 55mm x 4, as show. The lowest base position is the safest. Once your child is old enough to sit up unaided the base should be used in the...
  • Page 7 C / Bolts 25mm x 2 Step 5 D / Bolts 55mm x 4 Step 6 Connect fixed side to ends by passing (D) bolts 55mm through pre-drilled hole onto side of cot end. P a g e...
  • Page 8 H / 31mm x 2 I / 32mm x 2 Step 7 Refer to the magnified diagram, fully a ach top pin (H) and insert low pin (I) onto the bed ends. PUSH IN Ensure correct way Step (Outside/Inside) of dropside panel.
  • Page 9 Step 9 Always verify that both ends of the dropside are locked in the raised posi on whenever a child is in the cot. Step 10 Slide drawer into drawer runners on side of each end panel of Note that front of drawer may obstruct the opera on of lower dropside, if the drawer...
  • Page 10 CONVERT TO DAY BED / BED F / Allen Key Step 1 Remove the dropside, insert (F) Allen key through the holes of the dropside, push down lower pins of cot ends, to allow remove of dropside everse the assembly step 1 -L G / Bolts 40mm x 12...
  • Page 11 D / Bolts 55mm x4 Step 3 Use bolt D a ach side support onto bed end panel as diagram show. Fully ghten all bolts connec ons. Bed ready for use. 11 | P a g e...

  • Page 12: Care And Maintenance

    Care & Maintenance To preserve the hand cra ed quality of Babymore furniture, we recommend using a co on cloth and a non-toxic cleaner. Periodic use of furniture polish will maintain the good looks of your furniture. Scuff marks may be removed with a damp cloth.
