- Page 1 Sensitive safety-edge FA00129-EN DFWN1500 / 1700 / 2000 / 2500 EN English INSTALLATION MANUAL...
- Page 2 The product complies to the reference regulations in effect. DESCRIPTION This product is designed and built by Came S.p.A. in conformity with current safety standards, and is PR&S n.04.363 certified for vertical and horizontal applications. The sensitive safety-edge consists of an aluminum support rail and a rubber edge and two rubber end caps. The rubber edge houses two joined and jointed lever mechanism and one ø...
- Page 3 Main components 1. Rubber caps 2. Rubber edge 3. Steel cable 4. Cable clamping mechanism 5. Aluminum rail 6. Fastening bracket 7. Micro-switch housing mechanism 8. Micro 9. Electrical connection clamp 10. UNI6954 Ø 2.9x13 screws 11. UNI6954 Ø 3.9x13 screws 12.
- Page 4 Warning! With vertical fittings, reduce the LN by 30 to the edge from scraping the ground. Cut the rubber edge LG = LN - 285 mm ⚠ Products DFWN1500/1700/2000/2500 have a narrowing on the aluminum rail Ⓐ. When assembling, mark the aluminum rail 140 mm from the end. Use channellock pliers Ⓑ. ...
- Page 5 Fit the rubber edge into the aluminum rail until it stops against the mechanism Fit the steel cable into the rubber edge's upper hole Release the lever of the micro-switch housing mechanism by gently pressing down , fit the mechanism into the rail ...
- Page 6 If necessary (for example, with metal structures), use washer head self tapping Ø 3.9-mm screws. Drill the back of the aluminum rail and set up the passing of the electrical cable . Items: DFWN1500/1700/2000/2500 already have pre-drilled holes. ...
- Page 7 ELECTRICAL CONNECTIONS ⚠ Lay the corrugated tubes needed for making the connections.
- Page 8 Whereas other components (control boards, batteries, transmitters, and so on) may contain hazardous pollutants. These must therefore be disposed of by authorized, certifi ed professional services. DO NOT DISPOSE OF IN NATURE! CAME S.p.A. Via Martiri Della Libertà, 15 31030 Dosson di Casier - Treviso - Italy...
