- Page 1 Setup Guide 219271 Rev A...
-
Page 2: Kit Contents
Kit Contents Receiver includes D cell battery and ISM radio TL70 Wireless Indicator includes bracket and power supply Direct Select Operator Not shown above: Interface includes C battery Tools Needed Tape measure Phillips screwdriver Hand drill DXM Controller Power Supply Emitter includes D cell battery Not Included... -
Page 3: How It Works
2 AM Central Time. Total Count Emitter-Receiver (TCER) Solution Kits are preconfigured to monitor between one and four doors with the ability to scale up to 10 doors. The sensor pairs monitor people entering and exiting a single area and give a total count of people inside. The Operator Interface displays the number of people in the area and allows for employee adjustments to the occupancy count. - Page 4 Set Up Your Hardware Supply power to all devices The Occupancy Monitoring Kit arrives with all necessary power sources needed to get the system operating quickly. This includes lithium batteries for the Directional Sensors and Direct Select Operator Interface, and a DC power supply for the DXM Controller and TL70 Wireless Indicator Light.
- Page 5 Contact your local distributor or Banner Engineering’s Technical Support team at 1-800-203-5616 for more options or refer to our Troubleshooting section on page When mounting the Directional Sensor Pair, Banner recommends the sensors be mounted indoors when possible.
- Page 6 This mounting option uses the supplied L bracket. Outward Opening Doors For occupancy monitoring in areas with outward opening doors, Banner recommends mounting the devices on the inside of the door as close as possible to the door. The supplied L brackets can be mounted on the walls next to the door. If the door enters into a hallway/corridor, the sensors can be mounted directly to the walls without using the brackets.
- Page 7 Define Your Alert Levels Set Up the Warning and Alarm Settings Using the DXM Controller Display This Occupancy Solution Kit is designed to provide visual indication of capacity levels for monitored areas. The Occupancy Limit indicates that the area has exceeded the capacity for people. The indicator light alerts people attempting to enter that they need to wait until people have left the area before entering.
-
Page 8: Troubleshooting
15 feet). The status LED should flash green when the Operator Interface is communicating to the DXM Controller. If the status LED does not begin to flash green, contact your local distributor or Banner Engineering’s technical support team at 1-800-203-5616. - Page 9 Optional: Cloud Connectivity Banner Engineering’s Occupancy Solution Kit offers a fast and easy way to gain access to the data and history of the occupancy at your facility. The following section will show you how to configure your DXM Controller over Ethernet and quickly create your solution on the Banner CDS platform.
- Page 10 Dashboard layouts and metrics for the solution. Click (Create). The Banner CDS application creates a site for the system and begins searching for a data push from the DXM Controller. The Occupancy Solution Kit is designed to push data once every five minutes to the Cloud.
-
Page 11: Optional Accessories
View Dashboard and Set Parameters Go to Dashboard After Banner CDS has created the site and detected the DXM Controller, click on (Go to Dashboard). The (Dashboard) panel appears and indicates the metrics of the Occupancy Solution Kit. The data on this dashboard will include a historical indication of the Occupancy of the area and a means of updating the Occupancy Limit and Occupancy Warning parameters. - Page 12 Banner Engineering Corp. 9714 Tenth Avenue North • Minneapolis, Minnesota 55441 763-544-3164 • 1-888-373-6767 www.bannerengineering.com 219271 Rev A © 2020 Banner Engineering Corp. Mpls. MN USA...
