parameter settings
Measuring range
Dynamic response speed

2. Installation instructions

2.1 Equipment installation check
Equipment List:
■ transmitter equipment 1
■ four mounting screws
■ certificate, warranty card, service card, etc.
■ 12V / 2A 1 water supply station (optional)
■ USB to 485 (optional)
■ 485 terminating resistor (optional)
2.2 Interface Description
Wide voltage power input 10 ~ 30 V can. Note that the signal line 485 when the terminal A
\ B two lines can not be reversed, the address bus between multiple devices must not conflict.
2 .3 electrical wiring
Electricity
source
through
letter
2.4 Description field wiring
When a plurality of types of devices 485 connected to the same bus, the field wiring have
certain requirements, refer to the specific data packet "485 field wiring device manual."
Shandong RenKe Control Technology Co.,Ltd.
Be configured with software provided by the
Line color Description
A positive power supply (10 ~ 30 V DC)
brown
black Negative power supply
485 -A
yellow
blue 485 -B
5
Manual wind transmitter (485 type)
configuration 485
8 indicate the direction of
≤ 0.5s
