INSTRUCTION MANUAL
DIGIVAC 200 and 801W Series
Wide Range Thermocouple Vacuum Gauges and Controllers
Model 200
(benchtop)
Model 200P and 200P/2c
(panel mounting)
Model 801W and 801W/2c
(Varian pattern panel mounting)
Model DVG-6 and DVG-4
(Hastings pattern panel mounting)
Optional Controls • Analog output • Recorders and Rs232
Ranges
760 torr to .001 torr
1000 mbar to.001 mbar
The Digivac Company
1020 Campus Drive
Morganville NJ 07751
www.digivac.com
(732) 765-0900
(732) 765-1800 FAX
www.digivac.com
Advertisement
Table of Contents
Related Manuals for DigiVac 200 Series
Summary of Contents for DigiVac 200 Series
- Page 1 INSTRUCTION MANUAL DIGIVAC 200 and 801W Series Wide Range Thermocouple Vacuum Gauges and Controllers Model 200 (benchtop) Model 200P and 200P/2c (panel mounting) Model 801W and 801W/2c (Varian pattern panel mounting) Model DVG-6 and DVG-4 (Hastings pattern panel mounting) Optional Controls • Analog output • Recorders and Rs232 Ranges 760 torr to .001 torr...
-
Page 2: Table Of Contents
CONTENTS Description and Principle of Operation Limitations Mounting Instructions for 801(W) and DVG-6 Series Gauges Gauge Tube Installation Troubleshooting Recalibration Control Setpoints Rs-232 Output DigiVac and DigiPlot 10.0 Rear Panel Connections 11.0 DigiVac Recorder 12.0 Custom Features and Programming... - Page 3 DIGIVAC 200 and 801W Series Wide Range Thermocouple Vacuum Gauges and Controllers Model 200 (benchtop) Model 200P and 200P/2c (panel mounting) Model 801W and 801W/2c (Varian or Hastings pattern, panel mounting) Model DVG-6 and DVG-4 (Hastings pattern panel mounting) Optional Controls, Analog Output, Recorders, and Rs232 Ranges 760 torr to .001 torr...
-
Page 4: Description And Principle Of Operation
MOUNTING INSTRUCTIONS FOR 801(W) AND DVG-6 SERIES GAUGES The Digivac 801, 801w, Dvg-4, and Dvg-6 gauges mount in the same panel cutouts as the respective Varian, Hastings, and Televac gauges they are replacing. For new installations, proceed as follows: Remove the front panel of the gauge, leaving the aluminum spacers on the •... -
Page 5: Gauge Tube Installation
After energizing, the unit will initialize and operate. It reaches best thermocouple accuracy after a few minutes of warm-up. For greater accuracy Digivac offers a combination transducer/thermocouple gauge which offers 1% accuracy in Torr ranges. We also offer ¼% accurate capacitance manometer gauges. -
Page 6: Troubleshooting
If the tube is replaced, the unit must be recalibrated. It is best if this is performed at Digivac. If field calibration is done, the zero and span adjustments are available on two potentiometers which are accessible by removing the front panel of the instrument. The zero is on the right and the span is on the left. -
Page 7: Control Setpoints
▪ 50 torr (50,000 microns) or higher for dry mechanical and diaphragm pumps). ▪ Connect Voltmeter leads to "Com" and "Vac" pins. ▪ The voltage should be approximately .161 Volts dc. Make slight adjustments, if necessary, so the low end vacuum reading is correct. If the above readings cannot be attained, either the instrument, the gauge tube, or the cable is defective. -
Page 8: Digivac And Digiplot
Microsoft Excel, or any spreadsheet program can also plot the data. Digivac also offers a monitoring program that shows the data on the screen and opens and names a log file in response to a single click by the user. -
Page 9: 11.0 Digivac Recorder
Because these gauges are microprocessor controlled, it is possible to provide custom control features at surprisingly reasonable prices. The software is “burned” into the microprocessors, which are socketed and easily replaced by a user. Contact the Digivac Company to discuss your needs. - Page 10 E-mail: Direct from our website www.digivac.com The Digivac Company manufactures a complete line of vacuum gauges and computers. Contact us or your distributor if you wish for further information. See www.digivac.com for our latest offerings...
