16" SAND FILTER & 3100 GPH 3/4 HP POOL PUMP
ITEM: 75131
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 0880 MON-FRI 9AM TO 3PM PST
Advertisement
Table of Contents
Related Manuals for Xtreme Power 75131
Summary of Contents for Xtreme Power 75131
- Page 1 16” SAND FILTER & 3100 GPH 3/4 HP POOL PUMP ITEM: 75131 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION GENERAL SAFETY WARNINGS SERIOUS BODILY INJURY OR DEATH CAN RESULT IF THIS PUMP AND SAND FILTER IS NOT INSTALLED AND USED CORRECTLY. INSTALLERS, POOL OPERATORS AND POOL OWNERS MUST READ THESE WARNINGS AND ALL INSTRUCTIONS BEFORE USING THIS PUMP AND SAND FILTER. - Page 3 IMPORTANT SAFETY INFORMATION HIGH PRESSURE FROM THE SAND FILTER CAN CAUSE SEVERE INJURY OR MAJOR PROPERTY DAMAGE DUE TO TANK SEPARATION. RELEASE ALL PRESSURE AND READ INSTRUCTIONS BEFORE WORKING ON THE SAND FILTER. IF THE FILTER CLAMP IS ADJUSTED UNDER PRESSURE, THE TANK CAN SEPARATE, CAUSING SERIOUS INJURY OR MAJOR PROPERTY DAMAGE.
- Page 4 IMPORTANT SAFETY INFORMATION This filter operates under high pressure. When any part of the circulating system (e.g., clamp, pump, filter, valves, etc.) is serviced, air can enter the system and become pressurized. Pressurized air can cause the lid or control valve to separate which may result in serious injury, death, or property damage. To avoid this potential hazard, follow these instructions.
-
Page 5: Features And Specifications
FEATURES AND SPECIFICATIONS MULTI-PORT VALVE BACKWASH & RINSING VALVE PRESSURE GAUGE CONNECTING HOSE STAND PIPE PUMP & STRAINER BASKET LATERAL ASSEMBLY DRAIN CAP BACKWASH AND RINSING PORT: Waste port for backwashing and rinsing. MULTIPORT VALVE: Controls flow in and around the tank. PRESSURE GAUGE: Indicates PSI of the pump. -
Page 6: Preparation Before Installation
INSTALLATION SAND FILTRATION WORKING PRINCIPLE Incoming water from the piping system is automatically directed by the multi-port valve to the top of the filter bed. As the water is pumped through the filter sand, dirt and debris are trapped by the filter bed, and filtered out. - Page 7 INSTALLATION INSTALLATION NOTES 1. Make sure the filter is operating under the working pressure and using a pressure control valve when the system is using a booster pump. 2. To aid in winterization and maintenance it is recommended that a separate gate valve be installed. 3.
- Page 8 INSTALLATION INITIAL STARTUP OF FILTER Be sure correct amount of filter media is in tank and that all connections have been made and are secure. 1. Depress Multiport Valve handle and rotate to the BACKWASH position. NOTE: To prevent damage to control valve seal, always depress handle before turning.
- Page 9 INSTALLATION IMPORTANCE OF BACKWASHING The importance of backwashing cannot be overstated. Dense filter media can become “packed” without proper and frequent enough backwashing. Debris will remain trapped and create channelling within the filter bed. This will result in the filter bed exhausting early. Moreover, if debris is not flushed from the media grains, the filter bed will become dirtier and dirtier as time goes on until the filter operation fails.
-
Page 10: Please Read The Following Carefully
PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
