Complimenti per la sua ottima scelta. Ci complimentiamo vivamente per la Sua scelta, il prodotto Karma da Lei acquistato è frutto di un’accurata progettazione da parte di ingenieri specializzati. Per la sua realizzazione sono stati impiegati materiali di ottima qualità per garantirne il funzionamento nel tempo.
Page 3
Per prima cosa posizionate la staffa principale a parete assicurandovi, tramite la bolla di livello, che sia perfettamente orizzontale. Marcate i fori con una matita, praticate i fori con trapano e fissate la staffa a parete. Se la parete è in muratura(fig.1) applicate dei tasselli. fig.
Page 4
Applicate l’altra parte della staffa al retro dello schermo TV utilizzando i fori filettati presenti sullo schermo e facendoli combaciare con la staffa stessa. fig. 3 L’ultima fase dell’operazione consiste nell’agganciare la staffa agganciata al retro dello schermo TV alla staffa fissata a muro (fig.4) serrando poi la vite di sicurezza. fig.
Congratulation for your choice! Congratulations for your choice! The Karma product you have purchased is the result of careful planning by specialized engineers . High quality materials have been used for its construction, to ensure its functioning over time. The product is manufactured in compliance with strict regulations imposed by the European Union, a guarantee of reliability and safety.
Page 6
First place the main bracket on the wall, making sure, through the level , that it is perfectly horizontal . Mark the holes with a pencil , make the holes with a drill and fix the bracket on the wall. If it is a brick wall(fig.1) use the plugs.
Page 7
Apply the other part of the bracket to the back of the TV screen, by using the threaded holes on the screen and making them coincide with the bracket itself. fig. 3 The last step of the mounting consists in fastening the two brackets on the TV back to the bracket you have fixed on the wall (fig.4) and tightening then the safety screw.
Page 8
Il prodotto è coperto da garanzia in COME PROCEDERE ALL’INVIO base alle vigenti normative. DEL MODULO DI REGISTRAZIONE Vi suggeriamo di consultare sul sito PRODOTTO: internet: www.karmaitaliana.it le “Condizioni Generali di Garanzia” 1) Nel caso in cui non abbiate effettuato riportate nella sezione “FAQ”.
Page 9
Ulteriori informazioni su: www.karmaitaliana.it...
Page 11
EU Directives and environment and ‘ closely connected to the WEEE Directive ( Waste Electrical and Electronic Equipment). La Karma Italiana srl, allo scopo di migliorare i propri prodotti, si riserva il diritto di modifi care le caratteristiche siano esse tecniche o estetiche, in qualsiasi momento e senza alcun preavviso.
Page 12
Via Gozzano 38 bis 21052, Busto Arsizio (VA) - Italy Telefono +39 0331.628.244 Fax +39 0331.622.470 www.karmaitaliana.it made in China...
