- Page 1 1SFC132104M0201 EN, Rev A Softstarters Type PSTX30...PSTX370 Application manual: Waste water pump...
-
Page 2: Original Instruction
Original instruction This is the Application manual: Waste water pump for Softstarters Type PSTX30…PSTX370. Document number: 1SFC132104M0201 Revision: A Issue date: 2015-03-01 Data can be changed without notice. We reserve all rights to this document, even in the event that a patent is issued and a different commercial proprietary right is registered. -
Page 3: Read This First
Read this first Warning and saftey Thank you for selecting this ABB PSTX softstarter. Read carefully and make sure that you you understand all Saftey notes instructions before you mount, connect and configure the softstarter. In this user manual, these symbols are used:... - Page 5 Softstarters Type PSTX30...PSTX370 Application manual: Waste water pump 1 Introducton 2 Circuit diagram 3 Connection 4 Set-up 5 User guide...
- Page 6 This is the list of recommended pilot devices that is needed to perform the instructions and operations in this manual. NOTE Please note that equivalent pilot devices can be used as well. Contact you local ABB representative for more information. Table 1 Needed components Quantity...
-
Page 7: Circuit Diagram
2 Circuit diagram Circuit diagram for control with push buttons EMERGENCY STOP +24V DGND REVERSE FORWARD RESET Stop STOP Start START Com 3 +24V GND 24 25 FAULT Extension I/O (Optional) Circuit diagram for control with EMERGENCY STOP +24V DGND REVERSE FORWARD RESET... -
Page 8: Main Circuit
In Line, see Figure 1, and Inside Delta, see Figure 1. Figure 3: Terminal connection bars Use wire connection for PSTX30...PSTX105 see Figure 2 and terminal connection for PSTX142...PSTX170 see chapter 3.1.1 Tightening torques and cable see Figure 3. dimensions. •... - Page 9 3.1.1 Tightening torques and cable dimensions PSTX30...PSTX105 8 Nm - 71 Ib.in AWG6 .. 2/0 Cu 75°C only Rigid: 10 ... 95 mm² Flexible: 10 ... 70 mm² Rigid/flexible: 2x6 ... 2x35 mm² 4T2 6T3 PSTX142...PSTX170 Using connection bars Using connection module...
- Page 10 Control supply and control circuit Wires in industrial control applications are divided into three groups: main power supply, control supply and control circuit. Main power supply (1L1, 3L2, 5L3, 2T1, 4T2, 6T3) Control supply voltage (terminals 1 and 2) Control circuit (terminals 13 - 21). 3.2.1 Control supply voltage - terminals 1 and 2...
- Page 11 3.2.3 Connecting Start and Stop terminals to push buttons and PLC Internal control voltage - Push buttons The PSTX Softstarter has a built-in holding circuit and does not require sustained signals on start input. Use internal control supply voltage from terminals 20 or 21. Connect start and stop terminals using conventional circuit with push buttons.
- Page 12 3.2.4 Connecting Reset, Pump cleaning forward and Pump cleaning reverse terminals to push buttons or PLC The softstarter has three programmable inputs. See Figure 9. • In0, has reset event as default • In1, should be changed to Pump cleaning forward, see chapter 4.4.1 05 Slow speed (pump cleaning reverse) •...
- Page 13 +(B) -(A) T1 T2 T3 +24V + GND If more inputs and outputs are needed, connect 23 24 25 26 27 28 29 30 accessory DX111-FBP.0 (1SAJ611000R0101) from ABB. This will give additional: • 8 digital input • 4 ouput relay •...
- Page 14 For a complete list of settings and more details about how to set up the softstarter, please see The Installation and commissioning manual (1SFC132081M0201) available on http://new.abb.com/low-voltage/ products/softstarters. All parameters are available under Complete list in the Parameters menu.
-
Page 15: Application Setup
For more details on how to set Basic set-up, Application Event log set-up or more information about Assistants and Backup handling Application list, see 1SFC132081M0201 - Softstarters Type PSTX30...PSTX370, Installation and Commissioning System info Manual available on: http://new.abb.com/low-voltage/ Settings products/softstarters Figure 16: Assistants navigation The Assistants menu contains predefined settings and parameters. - Page 16 Recommended change of parameter values This chapter describes the recommended parameter values. For more information about the parameters for the PSTX softstarter see: 1SFC132081M0201 - Softstarters Type PSTX30...PSTX370, Installation and Commissioning Manual. 4.4.1 05 Slow speed (pump cleaning reverse) Menu...
- Page 17 Indication Instead of current underload protection it is possible to set power factor underload protection, parameters 14.06 - 14.10. See 1SFC132081M0201 - Softstarters Type PSTX30...PSTX370, Installation and Commissioning Manual. | Application manual: Waste water pump | Set-up 1SFC132104M0201...
- Page 18 5 User guide This chapter describes the basic operation of the waste water pump if the control products have been connected START STOP RESET and set-up according to this manual. EMERGENCY STOP Normal operation 50/60 Hz 50/60 Hz Start Stop Reset In1 In2 DGND DND +24V GND Star r t Stop Reset In1 In2 DGND DND 24V GND TOGGLE BUTTON...
- Page 19 When a fault or protection has tripped (Yellow pilot light is on) When a protection has tripped the softstarter e.g. when the pump is clogged or jammed, the yellow pilot light will turn on and the PSTX HMI display will flash and indicate that a protection is active.
- Page 20 Control Products modify the contents of this document without prior Low Voltage Products notice. With regard to purchase orders, the agreed particulars shall prevail. ABB does not accept any responsibility whatsoever for potential errors or pos- SE-721 61 VÄSTERÅS, Sweden sible lack of information in this document.
