- Page 1 Service Replacing Battery (Version 1.0e) BAUM Retec AG In der Au 22 69257 Wiesenbach Germany © 08/2012...
- Page 2 VisioBook – Service – Replacing Battery Replacing the Battery Pack: Tools: Hexagon screwdriver: Wrench size 2mm Parts: 1x Battery pack 1x Foam rubber strip 1x Insulating foil 7x Screws DIN 7984 M3x6 Start with VisioBook being collapsed! 1.1. To remove base plate remove 7 screws (DIN 6912 M3x6).
- Page 3 VisioBook – Service – Replacing Battery Version 1.0e Seite 3 von 3...
