Infinity Ezzy Sails Tuning Manual

1997 Transformer
Slalom
Rigging &
Fine Tuning Guide
1)
Slide the mast through the luff sleeve. Note: When rigging
with the cam, slide the mast above the cam (do not attach the
cam yet) (see diagram 1).
2)
Attach the mast extension and thread the line through the
cleat. Do not tension the downhaul yet, just cleat the line off.
3)
Attach the boom and outhaul the sail to the boom length
(printed on sail). The sail should be outhauled flat in the
bottom area.
Quick Tip: Attach your boom at, or below the center of the boom
cut-out to prevent the top of the boom cut-out from getting caught
on the boom while downhauling.
4)
Attach the cams to the mast by pushing down on the batten
with the palm of your hand, approximately 12" (30cm) from
the luff sleeve, and snap the cam onto the mast with your
other hand (see diagram 2).
Quick Tip: If the cam is difficult to put on the mast, check that the
batten tension webbing is loosened until the Velcro touches the
buckle. This will allow the cam to slide further into the sail and will

Rigging a 1997 Ezzy Transformer Slalom Sail

Page 1
