- Page 1 ALD30: Operation Manual Handheld Laser Distance Meter WARNING: Read and become familiar with this manual BEFORE operating unit. WARNING: To reduce the risk of injury, user must read and understand operation manual.
-
Page 2: Table Of Contents
Safety Regulations Overview Start-Up Operation Measuring Function Technical Specifications Warranty 11-12 Intex Truline™ intexinternational.com... -
Page 3: Safety Regulations
SAFETY REGULATIONS Before using this product, please carefully read and understand all the terms and operational guidelines in this manual. Hazardous laser radiation damage, electric shock or personal injury may occur if operations are not implemented under those safety regulations in this operation manual. Do not change the performance of the laser in any way, otherwise it may cause dangers due to laser exposure. - Page 4 Picture A Picture B intexinternational.com Intex Truline™...
-
Page 5: Overview
OVERVIEW Keyboard (See Picture A) 1 ON/Single measure /Continuous measure 2 Function Key--Area/Volume measure/Pythagorean measure 3 Clear/OFF Display (See Picture B) 1 Laser ON 2 Reference (front/rear) 3 Area/Volume/ Pythagorean 4 Battery display 5 Units with exponents 6 Auxiliary display 7 Main display WARNING: To reduce the risk of injury, user must read and understand operation manual. -
Page 6: Start-Up
Reference Setting Default measuring reference setting is the rear of the device. FUNC Press this key to change the reference. The reference returns automatically to the default setting (rear reference) after power off. Intex Truline™ intexinternational.com... -
Page 7: Measuring
MEASURING Press this key to activate the laser. Press again to implement the distance measurement. Continuous Measurement Press the key briefly to activate the laser, press and hold key for about 2 seconds to start continuous measuring. Press again shortly: continuous measurement is stopped. During continuous measuring, the latest measured value is displayed on the main display area, auxiliary display area shows the minimum and maximum measured value. - Page 8 - Under the Pythagorean measurement mode, ensure you start the measurement from the same starting point. In hypotenuse - right angle edge model, it is also necessary to ensure that right- angle side is perpendicular to the measured surface. Intex Truline™ intexinternational.com...
- Page 9 APPENDIX Display Notices In the course of using the instrument, error information as below may be displayed on the screen InFo Cause Correction Data overflow Repeat steps Measurement range transfinite Use the meter in distance allowed Temperature too high Let device cool down Temperature too low Warm device up Received signal too weak...
-
Page 10: Technical Specifications
110 × 38 × 23mm Weight 100g Temperature range -25°C to +70°C Storage -10°C to +50°C Operation In unfavourable conditions, such as intensive sunshine, very weakly reflecting target surface or large temperature fluctuations, measuring accuracy may deteriorate. Intex Truline™ intexinternational.com... -
Page 11: Warranty
(the laser emission window and receiving lens). WARRANTY Warranty Regulations 1. Intex offers two-year warranty since the purchase date of the instrument. 2. Warranty is void if any of the following exist: * Instrument of which the instrument number is deleted or modified. - Page 12 WARRANTY CARD Instrument Model Serial Number Date of Sales Sale Company Sale Address CONTENTS Name Quantity Unit Remarks ALD30 Unit AAA Battery User Manual Lanyard Strap Intex Truline™ intexinternational.com...
- Page 13 CERTIFICATE Name: Handheld Laser Distance Meter Model: ALD30 Testing: Date: WARNING: To reduce the risk of injury, user must read and understand operation manual.
- Page 14 Truline is a registered Trademark of Intex International ® The information contained in this brochure was correct at the time of printing. E&OE MANALD30 Version:01/20...
