Summary of Contents for Intex Truline ALCSG
- Page 1 ALCSG: Operation Manual Self-Levelling Cross-Liner Laser WARNING: Read and become familiar with this manual BEFORE operating unit. WARNING: To reduce the risk of injury, user must read and understand operation manual.
-
Page 2: Table Of Contents
Safety Regulations Overview Functional Highlights Tech Data Maintenance & Service Warranty Intex Truline™ Cross-liner equipped with 515nm diode are Class II laser products according to IEC/EN60825-1:2014 and complied with 21 CFR 1040.l0and 1040.11. Intex Truline™ intexinternational.com... -
Page 3: Safety Regulations
SAFETY REGULATIONS Before using this product, please carefully read and understand all the terms and operational guidelines in this manual. Hazardous laser radiation damage, electric shock or personal injury may occur if operations are not implemented under those safety regulations in this operation manual. Do not direct the laser beam at persons or animals and do not stare into the laser beam yourself (not even from distance). -
Page 4: Overview
OVERVIEW Vertical Beam Horizontal Beam ON/OFF/LOCK Switch Water/Dust Resistant Battery Cover intexinternational.com Intex Truline™... - Page 5 1/4" Tripod Screw 5/8" Tripod Screw WARNING: To reduce the risk of injury, user must read and understand operation manual.
-
Page 6: Functional Highlights
For red laser model, ideal working range is within 20m indoor. For green laser model, ideal working range is within 25m indoor and also outdoor friendly. (Depends on working environment‘s illumination.) Check Accuracy data on Technical LASER LINE INDICATION One vertical and one horizontal line Intex Truline™ intexinternational.com... -
Page 7: Tech Data
TECHNICAL DATA Laser beam: 1V lH laser lines (Red/ Green). **Light source: (laser lines) 635nm for red beam 515nm for green beam **Laser Classification: Class 2 ** Accuracy: ±2mm/ Sm **Compensator Self-leveling range: ±3 ° **Power Supply: 3 x 1.5V AA batteries **Mounting Threads: 1/4”... -
Page 8: Maintenance & Service
2. Do not drop, knock, or shake the instrument to avoid affecting precision. 3. Remove batteries when instrument is not in use. 4. Keep the instrument clean at all times. Use a soft cloth with mild soap for body, and lens tissue for glass windows. Intex Truline™ intexinternational.com... -
Page 9: Warranty
WARRANTY WARRANTY CARD NO.: Date of Purchase: Model No.: Serial No.: Owner’s Name: Contact Number: Dealer Name: Remarks (For Service Center Use Only): WARNING: To reduce the risk of injury, user must read and understand operation manual. - Page 10 Truline is a registered Trademark of Intex International. ® The information contained in this brochure was correct at the time of printing. E&OE MANALCSG Version:01/20...
