- Page 1 6-2013 Version 3.0 icreaseAIR Digital Creaser Operators Manual WWW.MBMCORP.COM 800-223-2508...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS…………………………………………………………………………………………….1a SAFETY PROCEDURES/CARE & MAINTENANCE.………………………………………………….1b COMPONENT IDENTIFICATION…………………………………………………………………………2 NOTES……………………………………………………………………………………………………..3 SETTING UP YOUR icreaseAIR………………………………………………………………………..4 Delivery Tray Assembly…………………………………………………………………………….4 Paper Stop Assemblies………………………………………………………………………….….5 MACHINE CONTROLS ………………………………………………………………………………………….6 PUMP CONTROLS……....................6 PULSED FEED CONTROLS……………...…………………………………………………………………….7 TOUCH SCREEN CONTROLLER......………………………………………………….8 Perf Mode......……………………………………………….………9 Feeder Mode........…………………………….……...10 Crease Mode....………………………………………….…….………10 Transport and Vacuum Operation Controls……………………………………………….………11 Programming for Crease Mode..………..……..….......……12... - Page 3 It is possible to feed quite a variety of jobs, from 30” sheets to die cut stocks. However, the performance of the icreaseAIR on these special applications is directly related to the experience of the operator.
-
Page 4: Safety Procedures/Care & Maintenance
BE ALERT! BE CAREFUL! CARE AND MAINTENANCE The icreaseAIR is a precision machine. It is very important to keep it free of excessive covered dust, dirt and foreign matter. We recommend that you keep the machine when not in use. -
Page 5: Component Identification
COMPONENT IDENTIFICATION Power Switch Air Feed Table Assembly Touch Screen Feed Rail Assembly Perf and Score Assemblies Crease Bar Paper Stop Delivery Tray Pump with Vacuum Valve REFERENCES Touch Screen Pg. 8 Feed Table Assembly Pg. 17 Delivery Tray Pg. 4 Pump with Vacuum Valve Pg. -
Page 6: Notes
NOTES:... -
Page 7: Setting Up Your Icreaseair
SETTING UP YOUR icreaseAIR This machine is 99% ready to go when it arrives on your dock. There are only a few items that need to be put into position before it is ready to use. Those 2 items are... -
Page 8: Paper Stop Assemblies
PAPER STOP ASSEMBLIES INSTALLING THE PAPER STOPS There are 3 different paper stops. 2 will have bends and 1 will be straight. The straight paper stop is the rear or back paper stop. The other 2 are the right and left paper stop and should be positioned as shown below. -
Page 9: Machine Controls
MACHINE CONTROLS There is one switch on the icreaseAIR the main power. Everything else is controlled by the Touch Screen. MAIN POWER On the operator side cover at the top on the right side is the main power button . This is the on and off power for the machine. -
Page 10: Pulsed Feed Controls
PULSED FEED CONTROLS The feed button is the control of a pulsed suction valve that allows the machine to fully control the feed of the paper. This mode of operations is a much more consistent way to run the machine. While the output speed is slower the end result is much more user friendly feed. -
Page 11: Touch Screen Controller
TOUCH SCREEN CONTROLLER icreaseAIR MBM Corporation 800-223-2508 THE TOUCH SCREEN CONSISTS OF FOUR SECTIONS: 1. MBM Logo and Service Access 2. Perf Mode 3. Feeder Mode 4. Crease mode Touch Screen Operation When the machine is turned on the display may take up to 7 seconds for the home screen to display. -
Page 12: Perf Mode
Perf Mode From the home screen press the perf mode button the perf mode screen will be displayed. Home: Takes you back to the home screen. Counter Reset: Resets the displayed counter to 0. Jog Left and Right: Slowly advances the rollers left or right. Batch Counter: Allows for stopping the machine after a batch number is reached. -
Page 13: Feeder Mode
Feeder Mode Feed mode is the mode to run your IcreaseAIR as a feeder into our CountCoat UV Coater. It runs much slower than the other modes giving the sheets enough spacing to move through the UV coater. Home: Takes you back to the home screen. -
Page 14: Transport And Vacuum Operation Controls
TRANSPORT AND VACUUM OPERATION • The Run Button will start the Transport in any given mode. When pressed it will also turn the air portion of the pressure pump on. Press it again to stop the transport and turn of the pump. Each Mode has a timeout feature to preserve the life of the machine. -
Page 15: Programming For Crease Mode
PROGRAMMING FOR CREASE MODE Half Fold: Press the Crease Mode Button > Half > Start Measuring > Physically Run a sheet through the machine for the sensor to measure > Accept > Run > Feed. EXAMPLE: Tri-Fold: Press the Crease Mode Button > Tri-Fold > Start Measuring > Physically Run a sheet through the machine for the sensor to measure >... -
Page 16: Gate Fold
Gate Fold: Press the Crease Mode Button > More > Gate > Start Measuring > Physically Run a sheet through the machine for the sensor to measure > Accept > Run > Feed. EXAMPLE: Double Gate Fold: Press the Crease Mode Button > More > Double Gate > Start Measuring >... -
Page 17: Perfect Bind Single Hinge
Perfect Bind Single Hinge: Press the Crease Mode Button > More > Perfect Binding Score > Enter The Book Thickness > Single Hinge > Start Measuring > Physically Run a sheet through the machine for the sensor to measure > Accept > Run > Feed. EXAMPLE: Perfect Bind No Hinge: Press the Crease Mode Button >... -
Page 18: Saving/Recalling Custom Jobs
Saving Custom Crease Jobs: Press the Crease Mode Button > Custom > Enter In Distance For each Crease in mm > Save > Select Position to save in 1, 2, 3, or 4. Recalling Custom Crease Jobs: Press the Crease Mode Button > Custom > Recall > Accept >... -
Page 19: Batch Counter
Batch Counter: Press the Batch Counter button from the run screen in any mode and it will take you to the Batch Count Screen. Press the Enter Batch Amount Button to enter in the number you want to run per batch. Press the Reset Batch Button to start from 0. -
Page 20: Feed Table Assembly
FEED TABLE COMPONENT IDENTIFICATION 1. Height Adjustment Caliper 2. Feed Rail Lock Knob Front 3. Paper Back Stop 4. Feed Rails 5. O-ring Caliper Assembly 6. Vacuum Pickup Point Adjustment Knob 7. Micro Skew Adjustment Knob 8. Feed Rail Lock Knob Rear 9. -
Page 21: Adjusting Feed Rails
ADJUSTING THE FEED RAILS The feed rails on your icreaseAIR are designed to adjust easily in case of a problem with crooked feeding. By loosening the feed rail alignment lock knobs you can move each rail independently to square them to your stock. To maintain an accurate perf or score, it is important to get the rails as aligned and snug to the sheet as possible without “squeezing”... -
Page 22: Setting The Automatic Feeder
SQUARING THE FEED RAILS The constant fine tuning of the rails will make it necessary to bring the rails back to true “square”. To do this, take a sheet of 8 1/2 x 11” cover stock and place it in the feed table against the operator side guide. -
Page 23: Height Adjustment Caliper
HEIGHT ADJUSTMENT CALIPER The caliper setting is what ensures the feeding of one sheet and prevents the feeding of double sheets. It is very important that this caliper be set correctly. To set the caliper take one sheet of the stock you are running and slide it between the caliper and vacuum wheel. -
Page 24: Loading The Feeder
• The icreaseAIR is capable of running 20lb. single sheets, 4-part forms and 100 lb cover. It is also very capable of handling gloss, coated, and even laminated stocks. Its flexibility is directly related to the operator’s experience. -
Page 25: Checking The Sensor
4. If all above steps work correctly, the sensor is working properly, if not, contact the MBM Corporation service department. DRIVE CHAIN TENSION The chain that drives the upper crease die in time will stretch. This is a common occurrence in chains. -
Page 26: Removing The Perf Shaft To Change Configurations
REMOVING THE PERF SHAFT (Changing the position of the lower assemblies) Turn the power off and unplug the machine. You may want to remove the upper assemblies before you begin to get them out of the way as the rollers are spring loaded and will give pressure on the lower rollers. -
Page 27: Rotary Perf & Score Assembly
PERFORATING AND SCORING Your icreaseAIR will come equipped with 1 Perf and 1 Score assembly standard. Up to 4 perf or score assemblies can be used at the same time. Perf and Score assemblies require the corresponding Perf or Score lower hub assembly in order to function properly. - Page 28 Setting the Perf Blade When locating the perf blade to where you would like to perf you must make sure that you can move the lower assembly and upper assembly to the location you want to perf. This may require moving the rubber gripper wheels or other upper and lower assemblies.
- Page 29 SCORING Just as in setting the perforation on your machine setting the score may require you to move around gripper wheels and other assemblies in order to set up your score in the proper location. The score upper assembly will look similar to the perf upper assembly without a safety guard covering the blade.
-
Page 30: Component Identification
PERFORATING AND SCORING ASSEMBLIES For removing and old blade and attaching a new blade to the pressure adjust mounting bracket, remove the (1) button head cap screw. BE SURE TO TIGHTEN THE SET SCREW SECURELY TO THE BAR. Once you have the upper and lower perf assemblies in place, you can tighten the half dog screw. -
Page 31: Gripper Wheel Perf Score Mounting
Position your score blade as desired. Scores should be made so that the blade runs on the side of the sheet that will be on the inside of the finished fold. Scores may be made on the icreaseAIR in three different ways using the different grooves on the lower score assembly. -
Page 32: Rac System (Rotary Actuated Creasing) Assembly
RAC System (Rotary Actuated Creasing) Assembly Component ID A. RAC drive motor B. Eccentric Drive Shaft C. Upper crease die D. Pressure Adjust bearing blocks (RAC Rollers) E. Lower crease die F. Drive chain & tensioner SEE DRIVE CHAIN TENSIONER ON PAGE 13 G. -
Page 33: Adjusting Rac Rollers (Depth Of Crease)
ADJUSTING THE RAC ROLLERS The RAC rollers are set from the factory and it is NOT recommended to make any adjustments to this without consulting with MBM’s tech-support department. Should an adjustment be necessary, please follow the steps below. Loosen the small bearing block lock screws. This allows very slight adjustments of the bearing block to be made by loosening the thumb lock and turning the height adjustment screw in the middle of the bearing block. -
Page 34: Troubleshooting
TROUBLE SHOOTING POWER DOES NOT TURN ON • 1. Check circuit breaker on rear panel. 2. Check outlet for power. TRANSPORT “LOCKS UP” AFTER CREASING • 1. Turn the crease bar over to wide groove. 2. Increase pressure of forwarding rollers by turn the shaft clockwise to increase the pressure.
