Summary of Contents for MMC Etlas Mobile
- Page 2 1200nit Support HDMI2.0 real-time output 4K@60f image and USB3.0 high-speed interface ⚫ Parts Figure 1 Front view of the Etlas Mobile [1] Antenna: transmitting data(Radio/Video); [2] 7 inch LCD screen: operation interface display; [3] Antenna: transmitting data(Radio/Video); [4] [6]Flying Joystick: control the attitude and throttle of the drone;...
- Page 3 When the power percentage is less than 10%, low voltage alarm will appear on the interface of the ground station software. At this time, please close the Etlas Mobile I and charge it as soon as possible; Figure 2 Bottom schematic of the Etlas Mobile [11]Fan outlet: heat outlet, do not block;...
- Page 4 [16] Cooling fan air inlet: fan air inlet, do not block; [17] Recording button: short press once to start recording; short press again to end recording; Figure 4 Top Schematic diagram of the Etlas Mobile [19] Gimbal heading dial: adjust the heading angle of the Gimbal;...
-
Page 5: Route Planning
Ground Station Software １.Ground station main interface Open the Etlas Mobile , click on the ground station icon on the menu to start Ground station software, as shown in Figure 5,when open the software for the first time , please connect to WIFI to load the map. - Page 6 Figure 6 Route Planning Interface Edit and view the route 2） ① Select a waypoint and drag the small circle icon to modify the speed, height and delay of the waypoint, as shown in Figure 7: Figure 7 Schematic Diagram of waypoint editing ②...
- Page 7 ③ Delete the route information of the main interface; ④ Click the "Download Task" icon to download the existing mission route task on the drone to the Etlas Mobile I, and check whether the downloaded route task information is the required route, as shown in Figure 8.
- Page 8 Figure 9 route mode drop-down box...
-
Page 9: Software Setting
3.Introduction of the gimbal mode In the main interface of the software, click on the image window in the lower left corner to switch the map/image window and enlarge the image window. As shown in Figure 10, you can switch the gimbal mode by clicking the gimbal mode button in the upper right corner of the image serial port:①Following: In this mode, click anywhere in the image screen, and the platform will automatically follow the target window clicked by the user.②Control: In this mode, the user adjusts the angle of the gimbal... - Page 10 1 In the control settings, you can set the left and right hand throttle, restart the APP after the change to view the modification result; 2 Click “Calibrate Accelerometer” and follow the prompts to calibrate the accelerometer; 3 Click “Calibrate Remote Control”, then move the left and right joysticks and gimbal tilt, gimbal heading, gimbal zoom wheel to get the maximum and minimum values of each channel, and then complete the remote channel calibration according to the prompts；...
- Page 11 Figure 11 Flight Setup Interface Figure 12 Controls Setting Interface...
- Page 12 Status display: The status display interface mainly displays the information of remote-control 3） channel and flight control channel, as shown in Figure 13 below: Figure 13 Status Display Interface Image transmission setting: The image transmission setting interface can query and set the 4）...
-
Page 13: Use Precautions
Android system settings interface; Figure 15 General Setup Interface Use precautions Before turning on the UAV power supply, be sure to turn on the power supply of Etlas Mobile ⚫ first. During the mission, Keep the antenna facing the UAV sideways to ensure signal stability. -
Page 14: Product Parameters
Appendix 1.Product Parameters Items Parameter Model Etlas Mobile Basic Information Dimensions 319x143x52mm Weight 1.5kg Working Temperature -20℃~60℃ Environment Charging ambient -10℃~50℃ temperature Operating System Android7.1（Deep Customization） Dual-core Cortex-A72+quad-core Cortex-A53 architecture with a main frequency up to 2.0GHz Screen size 7 inches... -
Page 15: Troubleshooting
” This means low batter and needs to stop working for Indicating”Severe: charging. Etlas Mobile is in low battery, less than 10%” Indicating”busy 1)Image transmission link communication abnormality operation” 2)Too frequent operations... - Page 16 1414...
