- Page 1 CARPET SHAMPOOER Simple and easy to use for removing dirt & stains from carpeted surfaces.
- Page 3 O2600 Shampooer Congratulations on the purchase of your new Optim Carpet Shampooer. There are many useful features built into your carpet shampooer. We recommend that you carefully read this instruction manual to take the best advantage of these features. Features: 1. Trigger 6. Dirty Water Tank Release Latch 2. Cord Storage Hook 7. Dirty Water Tank 3. Rod 8. On/Off Button 4. Clean Water Tank Release Button 9. Foot Release Pedal 5. Clean Water Tank Specifications: Wattage: 500W Cord Length: 5.5m Capacity: 1.7L Please contact Godfreys Customer Care 1800 815 270 (AUS) or...
-
Page 4: Before You Begin
Before You Begin PLEASE READ THIS MANUAL BEFORE OPERATING CLEANER Congratulations on the purchase of your new Optim Carpet Shampooer. There are many useful features built into your shampooer. We recommend that you carefully read this instruction manual for the best results. BEFORE YOU BEGIN This product must be operated in accordance with these instructions and used only for domestic cleaning indoors to remove dirt and dust from carpeted surfaces. PLEASE READ THESE INSTRUCTIONS THOROUGHLY. This will ensure you obtain full benefit from your new carpet washer. Keep this Instruction Manual in a handy place for future reference. IMPORTANT Always switch the appliance off and remove the power plug from the power supply before cleaning your appliance, when not in use, or attempting any maintenance task. The cleaner must only be connected to an AC power supply at the voltage shown on the rating plate. This cleaner should only be used for its intended purpose as described in these instructions. 1 This appliance is not intended for 3 If the power cord is damaged it use by persons (including children) must be replaced by an authorised with reduced physical, sensory service agent or similarly qualified or mental capabilities, or lack of persons. - Page 5 the power socket. Use only on any glowing, burning or Australian and New Zealand smoking particles. electrical safety approved 12 Do not use the shampooer extension cords. without the solution tank 6 Do not run the appliance over and dirty water tank installed the power cable. correctly. 7 Do not use the shampooer on 13 Ensure the shampooer is stairs or furniture, as it may switched off before unplugging result in injury or damage. Do the power plug from the power not handle the power plug or socket. shampooer with wet hands. 14 Do not store the shampooer 8 Do not put any objects into with solution in the tanks. the openings or operate with 15 Do not use to pick up the openings blocked. Keep flammable or combustible them free of anything that may liquids such as petrol or use reduce air flow.
- Page 6 Assembling IMPORTANT! The appliance should be switched off and disconnected from the power supply before you start to assemble. I nsert the body of the shampooer into the base and secure into place with the screws provided. I nsert the handle into body of the shampooer ensuring that the handle is pointing backwards. Secure into place with the screw provided. 3. I nsert the Clean Water Tank into the body of the shampooer ensuring it clicks into place. Your shampooer is now fully assembled.
-
Page 7: Preparing The Carpet
Preparing the Carpet IMPORTANT: Do not use the CHECK FOR COLOUR shampooer as a dry vacuum. FASTNESS V acuum carpeted surfaces Before you begin cleaning the carpet, thoroughly. Use a vacuum cleaner test for colour fastness. Dampen a with a powerbrush for best results. white cloth with solution. Test a small carpeted area in a closet. Gently rub the R emove as much furniture from cloth over the area. the room as possible. For furniture that cannot be removed place Check for colour bleeding. If the cloth plastic or foil under and around remains clean, it should be safe to clean the legs of the furniture and only the carpet. remove when the carpet has dried AFTER CLEANING completely. A llow carpet to dry completely. HELPFUL HINTS FOR Try not to walk on the carpet until CLEANING CARPET... - Page 8 Instruction for Use IMPORTANT! The appliance should be switched off and disconnected from the power supply. Never operate without filters as this can cause damage to the shampooer. T o remove the Clean Water Tank, hold the handle and press the Clean Water Tank Release Button. U nscrew the measuring cap from the reverse side of the clean water tank. Fill measuring cap with solution (one full cap of solution per full tank of water) and pour into the tank. 3. F ill the remainder of the Clean Water Tank with warm (max 40ºC) tap water. Screw back the measuring cap.
- Page 9 IMPORTANT! Never leave the appliance unattended with the power switched on. Turn off the appliance and disconnect the power cord from the power supply before emptying and filling the tanks. Do not oversaturate the carpet. 5. P lug the power socket into the power supply. Turn on the appliance by using the On/Off Button located on the side of the shampooer.
-
Page 10: Maintenance
Maintenance When you have finished cleaning remove the Dirty Water Tank and rinse with warm water, then allow it to dry before storage. Also remove the filter (as shown) rinse with warm water and allow it to dry thoroughly before storing. R emove the Dirty Water Tank from the shampooer. R emove the filter from the water tank and rinse with warm water and allow it to dry thoroughly before reinstalling. IMPORTANT! Do not use any chemicals when cleaning the filter. Note: Do not store the shampooer with solution in the Clean Water Tank or dirty water in the Dirty Water Tank. Mineral deposits and mildew can form and will affect the performance of the shampooer. -
Page 11: Troubleshooting
Troubleshooting Problems and Solutions If you come across a problem, please use this checklist before contacting Godfreys Customer Care 1800 815 270 Fault Solutions Reduced spray R efill tank with water and solution. or no spray Not picking C heck alignment of the tanks. up cleaning E mpty the Dirty Water Tank. solution Water spills E mpty the Dirty Water Tank. from the dirty A void using excessive force when pulling or water exhaust... - Page 12 CARPET SHAMPOOER Conditions of warranty Your OPTIM carpet shampooer, in the case of toria 3150, or on 1300 360 845, Monday-Friday domestic use, has a 3 month parts and labour 9am-5pm EST. The decision to repair or replace warranty against product defects and failures the cleaner is at the sole discretion of Godfreys when the product is used in accordance with Customer Care. If Godfreys Customer Care the terms and conditions of this warranty decide to repair or replace the cleaner, it will do statement. so at its own cost. This warranty commences from the original Optim Floorcare is unable to accept responsi- date of purchase and is not transferable; please bility under this warranty for any repair work retain your original proof of purchase for any not carried out by an authorised Optim Service warranty claims. This warranty is valid only in Agent or from the use of non-genuine parts. If the country where the cleaner is purchased. any part is no longer available or manufactured, The cleaner must be operated in accordance Godfreys Customer Care will replace it with a with these instructions and used only for do- genuine functional replacement part. This war- mestic household cleaning to remove DRY dirt ranty does not apply to the cost of replacing and dust from household carpets, flooring and any parts of the product due to normal wear fabrics. This cleaner is not fit to be used as an and tear, alterations, improper installation, industrial cleaner, and is not designed for the physical abuse, misuse or accidental dam- collection of vitreous building material includ- age. Any transportation costs involved in the...
