peplink PEPWAVE HD2 IP67 Installation Recommendations

Pole mount

For more information, please visit peplink.com

Hide thumbs Also See for PEPWAVE HD2 IP67:

Pole Mount

www.peplink.com

Steps:

1. Align the mounting unit to the

pole. Place the two

semicircular connectors

through the corresponding

holes in the mounting unit.

2. Attach a washer and nut to

each end of the semicircular

connectors to secure it to the

mounting unit.

3. Place the device on the

mounting unit, aligning the

holes on the lips of the

mounting unit to the holes in

the device.

4. Use washers and screws to

secure the device to the

mounting unit.

Table of Contents

Do you have a question about the PEPWAVE HD2 IP67 and is the answer not in the manual?

Page 1 3. Place the device on the mounting unit, aligning the holes on the lips of the mounting unit to the holes in the device. 4. Use washers and screws to secure the device to the mounting unit. www.peplink.com ©Peplink. All rights reserved.
Page 2 Place the device on the mounting unit, aligning the holes on the lips of the mounting unit to the holes in the device. Use washers and screws to secure the device to the mounting unit. www.peplink.com ©Peplink. All rights reserved.
Page 3 Secure the mounting unit to the wall with screws. 4. Screw four screws half-way into the holes in the back of your device. 5. Hang the device onto the mounting unit. www.peplink.com ©Peplink. All rights reserved.
