Special Note – Restore CS101 OS to
Factory Default Setting
Version 1.2.1
CSL: The One-Stop-Shop for RFID Solutions

Advertisement

loading
Need help?

Need help?

Do you have a question about the CS101 and is the answer not in the manual?

Questions and answers

Related Manuals for CSL CS101

Summary of Contents for CSL CS101

  • Page 1 Special Note – Restore CS101 OS to Factory Default Setting Version 1.2.1 CSL: The One-Stop-Shop for RFID Solutions...

  • Page 2: Table Of Contents

    Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 Table of Contents Introduction ................................. 3 Restore CS101 OS to Factory Default Setting Overview ..................4 Restore CS101 OS to Factory Default Setting Procedure..................5 Install Basic Components ............................ 9 Install CS101 Demo App ...........................

  • Page 3: Introduction

    1 Introduction This document provides guidelines to the user to restore the software to factory default in the CSL CS101 Reader. The following areas will be covered in this document Restore of the Windows CE OS on CS101 Installation of the CS101 Basic Components Installers Installation of demo application Copyright ©...

  • Page 4: Restore Cs101 Os To Factory Default Setting Overview

    Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 2 Restore CS101 OS to Factory Default Setting Overview The flow diagram below shows the priority of firmware upgrade steps starting from device application and default setting file. User MUST follow the sequence below to restore Win CE OS to Factory Default Setting.

  • Page 5: Restore Cs101 Os To Factory Default Setting Procedure

    Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 3 Restore CS101 OS to Factory Default Setting Procedure 1. Use a fully charged battery to power on CS101 2. Press and keep holding the “Power” key for 1 second...
  • Page 6 Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 WHILE holding the “Power” key, press “Reset” key simultaneously for 5 seconds. 4. After that, ONLY release the “Reset” key, leaving the Power key still pressed by finger. Keep holding the key and wait until warning box is seen (after 5 seconds).
  • Page 7 Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 6. Press [Yes] when reconfirmation box appears. 7. Press [OK] button to confirm the System ROM formatting. 8. Wait until System ROM formatting process is finished. Copyright © Convergence Systems Limited, All Rights Reserved...
  • Page 8 Use the Pen CS101 provided to do the Calibration. 10. Tap the screen to confirm the calibration settings. 11. After the 1st Touch Screen calibration for CS101, wait until CS101 enters Win CE. 12. Please go to Section 4 to Install Basic Components for CS101.

  • Page 9: Install Basic Components

    RFID module inside, Dot Net Framework, Demo App, etc. 1. After the Win CE OS is upgraded, wait until CS101 enter Win CE. 2. Unzip the package CS101 Basic Components Installers.zip (provided by CSL) in PC to a directory.
  • Page 10 Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 4. Open the folder inside CS101 Win CE. 5. Check the files in . They are RfidUsbDriverCE.cab, “CS101 Basic Components Installers” NETCFv2.wce5.armv4i.cab, NETCFv35.wce.armv4.cab, BarcodeSavePowerModeSetup21-Oct-2009.CAB and sqlce30.wce5.armv4i.cab. Copyright © Convergence Systems Limited, All Rights Reserved...
  • Page 11 Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 6. Starting from RfidUsbDriverCE.cab, double click the cab files to install the files. A file location will pop up. Simply press “OK” to install the component to the default directory provided.
  • Page 12 Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 8. After CS101 Basic Components installed, the Barcode Power Save Mode should be set before use. Enter CS101 Program Files. 9. In Program Files, enter BarcodeSavePowerMode Setup. 10. Run the program BarcodeOnOff.exe...
  • Page 13 12. Press OK when “Successful” is prompt. Then exit this program by pressing the “x” button on the upper right corner of the Barcode application window. 13. User can go to Section 5 to install the latest CS101 Demo App. Copyright © Convergence Systems Limited, All Rights Reserved...

  • Page 14: Install Cs101 Demo App

    Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 5 Install CS101 Demo App After installation of Basic Components for CS101, the user can install latest CSL CS101 Demo App from CSL website (http://www.convergence.com.hk/download-support-installer-cs101-demo-app/) to enable the CSL RFID handheld reader features.
  • Page 15 Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 4. Check the files in “CS101 Demo Apps2.1.45_Installer” Choose “ CS101 Demo CE(VS2008)”. 5. Double click the cab file to install the file “ . Press “OK” to CS101 Demo CE(VS2008)”...
  • Page 16 Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 7. Click and hold the shortcut of Demo App. Choose “Rename” to rename the file. 8. Double Click to run the renamed Demo App. Copyright © Convergence Systems Limited, All Rights Reserved...
  • Page 17 Special Note – Restore CS101 OS to Factory Default Setting v1.2.1 9. In the main menu, choose “Inventory” 10. Click “Start” to run Inventory Copyright © Convergence Systems Limited, All Rights Reserved...
