KAM-SD-2AES-MUX

KAMELEON SERIES MODULES

Instruction Manual

SOFTWARE VERSION 4.0.1

071834800

DECEMBER 2004

Table of Contents

Need help?

Do you have a question about the KAMELEON Series and is the answer not in the manual?

Questions and answers

Summary of Contents for GRASS VALLEY KAMELEON Series

Page 1 KAM-SD-2AES-MUX KAMELEON SERIES MODULES Instruction Manual SOFTWARE VERSION 4.0.1 071834800 DECEMBER 2004...
Page 2 Germany, Europe +49 6150 104 782 +49 6150 104 223 Copyright © Thomson Broadcast and Media Solutions All rights reserved. Grass Valley Web Site www.thomsongrassvalley.com web site offers the following: — Current versions of product catalogs, brochures, Online User Documentation data sheets, ordering guides, planning guides, manuals, and release notes in .pdf format can be downloaded.
Page 3: Table Of Contents
About This Manual ........... . . KAM-SD-2AES-MUX Kameleon Series Module Introduction .
Page 4 Contents Clipping Controls ..........Reset To Default .
Page 5: Preface
Preface About This Manual This manual describes the features of the Kameleon multi-function modules that are part of the Kameleon Media Processing System. As part of this module family, it is subject to Safety and Regulatory Compliance described in the Kameleon/2000 Series frame and power supply documen- tation (see the Kameleon 2000 Series Frames Instruction Manual).
Page 6 About This Manual KAM-SD-2AES-MUX Instruction Manual...
Page 7: Kam-Sd-2Aes-Mux Kameleon Series Module
Kameleon Series Module Introduction This manual provides installation, operation and conﬁguration informa- tion for the KAM-SD-2AES-MUX Kameleon Series module. The KAM-SD-2AES-MUX modules provides a serial digital video input and output with embedded audio. Two external AES audio channels can be multiplexed into the SDI output video.
Page 8: Installation
Installation Installation To install the Kameleon modules, perform the following steps: 1. Place the KAM-AES-R passive rear module in a rear frame slot and tighten the screws on each side of the rear module. 2. Cable the signal ports. All Kameleon modules can be inserted and removed from a 2000 Series Kameleon Frame with power on.
Page 9: Module Placement In The 2000T3Ng Kameleon Frame
Module Placement in the 2000T3NG Kameleon Frame There are twelve slot locations in both the front and rear of a 3 RU frame to accommodate 2000 and Kameleon Series media modules (audio/video signal handling modules). The Kameleon media modules consist of a two-module set with a front processing media module and a passive rear module that can be plugged into any of the 12 frame slot pairs.
Page 10 Installation 2. Insert the KAM-AES-R passive rear module into the vacant rear slot of the frame as illustrated in Figure Figure 2. Installing Passive Rear Module 2000 frame (rear view) Board edge guides (both sides) Screw lock Rear alignment (both sides) post and receptacle AES 1 AES 2...
Page 11 Installation 5. Locate the corresponding front media slot (1 -12) in the frame. The 3 RU frame front view is illustrated in Figure Figure 3. 2000T3NG Kameleon Frame, Front Slots Reference Distribution Slot (15) Network Slot (13) Main Power Supply Slot (19) (13) (15) Fan Sled...
Page 12: Cabling
Installation Cabling All cabling to the module is done on the KAM-AES-R passive rear module shown in Figure SDI Video In Connect serial digital video to connector J11, labeled AES Audio Inputs Two unbalanced AES audio inputs are available at connectors J9 and J10 or two balanced AES audio inputs are available at connectors J7 and J8.
Page 13: Power Up
Power Up Power Up The front LED indicators are illustrated in Figure Figure 6. Front and Rear Module Indicator LEDs FAULT – Red diagnostic LED is off during normal operation COMM – Yellow LED on during remote control communication CONF – Yellow LED on when module is initializing or processing control data PWR –...
Page 14: Operation Indicator Leds
Power Up Operation Indicator LEDs Table 2 provides a complete list of possible operating conditions and the resulting indicator status. A red FAULT LED indicates an error situation. Table 2 describes signal output and LED indications for the various input/reference combinations and user settings.
Page 15: Configuration And Adjustments
Conﬁguration and Adjustments Conﬁguration and Adjustments KAM-SD-2AES-MUX conﬁguration and monitoring can be performed using a web browser GUI interface or a networked Newton Control Panel. This section provides an overview of each of these controls along with the conﬁguration parameters available with each type of control device. Conﬁguration Summary The conﬁguration parameters and monitoring functions available with the web browser interface and the Newton Control Panel are summarized in...
Page 16 Conﬁguration and Adjustments Table 3. Summary of KAM-SD-2AES-MUX Conﬁguration Controls Range/Choices Web Page/ Newton Function Default Resolution Function Name Panel Video Proc/ Video gain lock On or Off Video Gain Lock radio buttons 50 to 149.6% Video Proc/Standard View Main video contrast/Y gain 100% YGain (0.4% steps)
Page 17 Conﬁguration and Adjustments Table 3. Summary of KAM-SD-2AES-MUX Conﬁguration Controls Range/Choices Web Page/ Newton Function Default Resolution Function Name Panel AES Inputs/ AES input loss of signal report Enable Enable or Disable Loss of Signal Report checkbox AES Inputs/ AES input AES error warning Enable Enable or Disable AES Error Warn checkbox...
Page 18: Newton Control Panel Configuration
Conﬁguration and Adjustments Newton Control Panel Conﬁguration A Newton Control Panel (hard or soft version) can be interfaced to the Kameleon 2000 Series frame over the local network. Control panel access offers the following considerations for module conﬁguration and moni- toring: •...
Page 19: Web Browser Interface
Conﬁguration and Adjustments Web Browser Interface The web browser interface provides a graphical representation of module conﬁguration and monitoring. Use of the web interface offers the following considerations: • Provides complete access to all module status and conﬁguration func- tions, including naming of inputs and outputs, factory parameter and name default recalls, E-MEM functions, slot conﬁguration, and SNMP monitoring controls.
Page 20 Conﬁguration and Adjustments Figure 8. 2000NET GUI The Links section lists the frame and its current modules. The selected link's Status page is first displayed and the sub-list of links for the selection is opened. The sub-list allows you to select a particular information page for the selected device. Content display section displays the information page for the selected frame or module (frame slot icons are also active links).
Page 21: Web Page Operations And Functional Elements
Conﬁguration and Adjustments Web Page Operations and Functional Elements The following conventions and functional elements (shown at left) are used in Kameleon web page operations. (The examples shown throughout this manual represent 2000NET software version 3.2.2 or later): Pulldown Menus •...
Page 22 Conﬁguration and Adjustments Status LED icon The Status LED icon reports communication status for the frame slot and is a link to the module Status web page where Warnings and Faults are dis- played. LED colors indicate: • Green = Pass – no problems detected •...
Page 23: Initial Configuration Process Overview
Initial Conﬁguration Process Overview Initial Conﬁguration Process Overview To conﬁgure the Kameleon module proceed as follows: 1. Go to the I/O Conﬁg web page to setup and name inputs and outputs. 2. If not already connected, connect all input and output signals. Go to the module web page to verify component and signal presence and Status...
Page 24: Kam-Sd-2Aes-Mux Links And Web Pages
KAM-SD-2AES-MUX Links and Web Pages KAM-SD-2AES-MUX Links and Web Pages The 2000 GUI provides the following links and web pages for the module (Figure 10): • Status – reports input and reference signal status and module informa- tion (page 25), •...
Page 25: Status Web Page
KAM-SD-2AES-MUX Links and Web Pages Status Web Page The Status web page for the KAM-SD-2AES-MUX module (Figure 11 on page 26) provides an overall indication of the health of the system and links this to web pages for the active components: link •...
Page 26 KAM-SD-2AES-MUX Links and Web Pages Figure 11. Module and Signal Status Warning and Fault summary section KAM-SD-2AES-MUX Instruction Manual...
Page 27: Warning/Fault Summary
KAM-SD-2AES-MUX Links and Web Pages Warning/Fault Summary The warnings and faults shown below are reported in the summary section of the Status web page (Figure 11 on page 26). A indicates a serious Fault condition that prohibits proper operation. A indicates a condition Warning which may or may not adversely affect operating conditions, but should be...
Page 28: Input/Output Configuration Web Page
KAM-SD-2AES-MUX Links and Web Pages Input/Output Conﬁguration Web Page Use the I/O Conﬁg web page to: • View a graphical overview of the currently installed rear module con- this nectors, link • See signal status of inputs, • Assign easily recognized signal names that will help later in the conﬁg- uration process.
Page 29: Web Page Elements
KAM-SD-2AES-MUX Links and Web Pages Figure 12 illustrates the I/O Conﬁg web page for the KAM-AES-R passive rear module required for the KAM-SD-2AES-MUX front module with bal- anced audio inputs selected ( radio button selected). Balanced Figure 13. KAM-AES-R Rear Module Conﬁguration Web Page (Balanced AES In Select AES input type Web Page Elements Each element of I/O Conﬁg web page is summarized below.
Page 30 KAM-SD-2AES-MUX Links and Web Pages Signal Name Enter a signal name (up to 15 characters) for each operational input/output. The name will be used to identify the signal in other conﬁg- uration web pages. Factory default names are shown in Figure 13 on page Status...
Page 31: Functional View Web Page
KAM-SD-2AES-MUX Links and Web Pages Functional View Web Page Use the Functional View web page (Figure 14) to: • Monitor module functions and signal paths, and • Navigate to web pages for conﬁguring active functions. this link The Functional View web page is a block diagram of the installed Kame- leon module that reports the module functions and signal paths that are active or inactive in the current conﬁguration.
Page 32: Sdi In Web Page
KAM-SD-2AES-MUX Links and Web Pages SDI In Web Page Use the SDI In web page to view the status of the SDI input signal in Summary view (Figure 15) or Detail view (Figure 16 on page 33): • Select the radio button to bring up the summary view shown Summary Figure...
Page 33 KAM-SD-2AES-MUX Links and Web Pages Figure 16. SDI In Web Page (Detail View) KAM-SD-2AES-MUX Instruction Manual...
Page 34: Video Input Select Web Page
KAM-SD-2AES-MUX Links and Web Pages Video Input Select Web Page Use the Video Input Select web page (Figure 17 on page 35) to: • Conﬁgure input video line rate, this • Enable or disable Loss of Signal reporting to the Status web page and link SNMP monitoring (refer to 2000NET manual for SNMP information), •...
Page 35: Output Timing Selection
KAM-SD-2AES-MUX Links and Web Pages • Frame Sync/Delay – (read-only) Frame Sync mode is reported when Output Timing Selection is and timing is pro- Internal Frame Reference vided from the 2000GEN module. Frame Delay mode is reported when the input signal ( ) is used for timing reference.
Page 36: Advanced Vbi Configuration
KAM-SD-2AES-MUX Links and Web Pages Advanced VBI Conﬁguration Advanced VBI conﬁguration allows you extend VBI into the active picture range for special data insertion requirements. Active video lines that are used to carry data are referred to as Data Lines. To add Data Lines to VBI: 1.
Page 37 KAM-SD-2AES-MUX Links and Web Pages Figure 19. Advanced VBI Conﬁguration – 525 Line Rate Figure 20. Advanced VBI Conﬁguration – 625 Line Rate KAM-SD-2AES-MUX Instruction Manual...
Page 38: Frame Sync Web Page
KAM-SD-2AES-MUX Links and Web Pages Frame Sync Web Page Use the Frame Sync web page (Figure 21 on page 39 Figure 22 on page 39) to: • Adjust horizontal and vertical timing, and this • Freeze the current output or, if using a 2000GEN reference signal, select link an automatic freeze mode for output when the signal is lost.
Page 39 KAM-SD-2AES-MUX Links and Web Pages Figure 21. Frame Synchronizer Web Page – Video In Reference Figure 22. Frame Synchronizer Web Page – Internal Frame Reference KAM-SD-2AES-MUX Instruction Manual...
Page 40: Video Processing Web Page
KAM-SD-2AES-MUX Links and Web Pages Video Processing Web Page Use the Video Proc web page to: • Enable/disable Standard or Advanced video processing, • Turn on Color Bars test signal, this • Enable/disable video gain lock, link • Adjust component video gain (Y, B-Y, R-Y), •...
Page 41 KAM-SD-2AES-MUX Links and Web Pages Figure 23. Video Processing Web Page – Standard View KAM-SD-2AES-MUX Instruction Manual...
Page 42: Clipping Controls
KAM-SD-2AES-MUX Links and Web Pages Advanced View In Advanced View (Figure 24 on page 43), adjust the following for the B-Y and R-Y Channels: Note To adjust gain for all channels simultaneously, set Video Gain Lock to On. This locks Y, B-Y, and R-Y adjustments together. Adjustment of one gain setting changes all gain values (Y, B-Y, R-Y) the same amount.
Page 43 KAM-SD-2AES-MUX Links and Web Pages Figure 24. Video Processing Web Page – Advanced View KAM-SD-2AES-MUX Instruction Manual...
Page 44: Mux Web Page
KAM-SD-2AES-MUX Links and Web Pages MUX Web Page Use the MUX (multiplex) web page (Figure 28 on page 47) to: • Delete unwanted embedded audio groups from the SDI input signal or delete all horizontal ancillary data (HANC) in all audio groups, and •...
Page 45: Group Deletion
KAM-SD-2AES-MUX Links and Web Pages Group Deletion The Group Deletion area of the Mux web page reports if audio is present in any of the four audio groups in the incoming SDI video signal and the output status of each group. It can be used to delete unwanted embedded audio groups and clear all HANC (horizontal ancillary data) with the fol- lowing controls: •...
Page 46: Audio Multiplexing
KAM-SD-2AES-MUX Links and Web Pages Audio Multiplexing There are four possible conditions for multiplexing as described next. No Embedded Audio If no audio groups are present in the incoming SDI video signal, the Group Deletion input status section will appear as shown in Figure 26.
Page 47 KAM-SD-2AES-MUX Links and Web Pages Replace Embedded Audio An external AES audio group can be selected to replace an existing audio group in the incoming SDI stream with the Group replacement function as shown in Figure 28. In this case, the present audio, Group 1, has been replaced with Group 1 from the external AES audio input.
Page 48 KAM-SD-2AES-MUX Links and Web Pages Insert Embedded Audio An external audio group can be selected to replace an empty audio group in the SDI input stream with the Group replacement function as shown in Figure 29. In this case, an external AES audio has been processed in the Audio processor, and selected to replace an empty audio Group.
Page 49: Vbi Sdi Web Page
KAM-SD-2AES-MUX Links and Web Pages VBI SDI Web Page Use the VBI SDI web page (Figure 30 for 525, Figure 31 on page 50 for 625 line rate) to conﬁgure blanking for the VBI and Data Lines. this • The currently detected line rate will be reported. Use the View Selection link to view the web page at the correct line rate with the radio...
Page 50 KAM-SD-2AES-MUX Links and Web Pages Figure 31. VBI SDI Web Page – 625 Line Rate KAM-SD-2AES-MUX Instruction Manual...
Page 51: Aes Inputs Web Page
KAM-SD-2AES-MUX Links and Web Pages AES Inputs Web Page Use the AES Inputs web page (Figure 32) to check the status of the AES audio inputs. The following information is reported for each input: • – reports the audio characteristics for input J9 and AES Input characteristics J10 as shown in the table.
Page 52: Audio Channel Pairing Web Page
KAM-SD-2AES-MUX Links and Web Pages Audio Channel Pairing Web Page The Audio Channel Pairing web page (Figure 33) allows the input audio channels to be arbitrarily recombined into new pairs and swapped or set to . The rows represent the audio input channels and the columns rep- Silence resent the audio output channels.
Page 53: Audio Sync Web Page
KAM-SD-2AES-MUX Links and Web Pages Audio Sync Web Page Use the Audio Sync web page (Figure 34 on page 54) to: • Synchronize the two audio channel pairs to video Frame Sync, and/or this • Add audio delay using the delay adjust controls to add delay to each link channel or lock the channels together as a pair and adjust delay.
Page 54 KAM-SD-2AES-MUX Links and Web Pages Figure 34. Audio Synchronizer Web Page KAM-SD-2AES-MUX Instruction Manual...
Page 55: Audio Processing Web Page
KAM-SD-2AES-MUX Links and Web Pages Audio Processing Web Page Use the Audio Processing web page (Figure 35 on page 56) to adjust the fol- lowing for each audio pair: • Adjust audio signal gain for each individual channel or the two audio pairs, this link...
Page 56 KAM-SD-2AES-MUX Links and Web Pages Figure 35. Audio Processing Web Page KAM-SD-2AES-MUX Instruction Manual...
Page 57: E-Mem Configuration Web Page
KAM-SD-2AES-MUX Links and Web Pages E-MEM Conﬁguration Web Page The E-MEM page provides local operations for learning and recalling con- ﬁgurations into ﬁve E-MEM registers. File operations are also available for saving or loading the learned E-MEM ﬁles to and from a hard disk or other accessible media.
Page 58 KAM-SD-2AES-MUX Links and Web Pages The Advanced View (Figure 37) includes a File Operations section to learn a conﬁguration into E-MEM ( ), save a ﬁle to a disk location ( Learn Save to... or load a ﬁle from a disk location ( Load from...
Page 59: File Operations
KAM-SD-2AES-MUX Links and Web Pages File Operations Save File File operations allow you to save learned conﬁgurations to a computer hard drive or other accessible media for later recall to the onboard E-MEM registers of any Kameleon module in your system. To save to a ﬁle, ﬁrst make sure you have learned the conﬁguration, then press the button.
Page 60 KAM-SD-2AES-MUX Links and Web Pages This will bring up the Save As screen as shown in Figure 39. Locate or create a directory for storing the E-MEMs and select . This E-MEM reg- Save ister is now saved to the selected location and may be recalled as described below.
Page 61 KAM-SD-2AES-MUX Links and Web Pages Enter a path and ﬁlename or use the button to locate your saved Browse E-MEM ﬁles. Browse to the Choose File screen (Figure 41), select the E-MEM ﬁle to download and select Open Figure 41. Choose File Screen This will place the path and ﬁlename in the Load E-MEM screen (Figure 40 on page...
Page 62: Slot Configuration
KAM-SD-2AES-MUX Links and Web Pages Slot Conﬁguration Use the Slot Conﬁg web page (Figure 42 on page 63) to: • Assign an appropriate name to the module slot, • Assign an Asset Tag identiﬁcation, • Enable/disable the function, Locate Module this link •...
Page 63 KAM-SD-2AES-MUX Links and Web Pages Figure 42. Slot Conﬁguration Web Page KAM-SD-2AES-MUX Instruction Manual...
Page 64: Frame Heath Reporting
KAM-SD-2AES-MUX Links and Web Pages Frame Heath Reporting The reporting of Slot Fault, Signal Loss, and Reference Loss can be enabled or disabled to the Frame Health connector on the rear of the Kameleon frame by selecting or deselecting the corresponding checkbox. Hardware Switch Controls This section is a read-only status report of 2000NET module switch settings for Module Status Reporting and Asynchronous Status Reporting.
Page 65: Software Update Web Page
FTP server method described in the 2000NET Instruction Manual available on-line. Software may also be updated using the NetConﬁg Networking Applica- tion PC option available with Modular and other Grass Valley products as this described in the documentation that accompanies the option.
Page 66: Specifications
Speciﬁcations Speciﬁcations Note Speciﬁcations are subject to change without notice Table 6. SDI Input/Output Speciﬁcations Parameter Value SDI Input Signal type Serial digital video conforming to SMPTE259M 10-bit 4:2:2component digital signal Input impedance 75 Ω Connector type 75 Ω BNC on rear module Input return loss >15 dB to 270 MHz Common mode rejection ratio...
Page 67 Speciﬁcations Table 8. Main Video Processing Speciﬁcations Parameter Value Main Video Frame Processing Control Parameters Y gain ±50% in 0.4% steps, 100% default Y offset ±3.5% of 100% white in 0.11% steps, 0% default B-Y gain ±50% in 0.4% steps, 100% default B-Y offset ±3.5% of 100% white in 0.11% steps, 0% default R-Y gain...
Page 68 Speciﬁcations Table 11. Audio Processing Speciﬁcations Parameter Value Audio Processing Number of channels supported Fixed Delay 0 – 5.2 sec in 20 ms steps, individual setting for each channel Delay Tracking Delay can be set to automatically track delay through video frame sync with ﬁxed offset Gain +6 to -40dB in 0.1dB steps, individual setting for each channel.
Page 69: Service
LED indications. If the module is still not operating correctly, replace it with a known good spare and return the faulty module to a designated Grass Valley repair depot. Call your Grass Valley representative for depot location. Refer to the...
Page 70 Service KAM-SD-2AES-MUX Instruction Manual...
Page 71 Index Numerics summary table group replacement 2000GEN module web page control for output timing multiplexing requirement multipliplexing 2000NET module conditions hardware requirements processing hardware switches summary table software requirement web page controls silence sync Audio Channel Pairing web page AES audio inputs Audio Proc web page AES errors Audio Sync web page...
Page 72 EDH error reporting graphical user interface (GUI) E-MEM Grass Valley web site Advanced view group replacement description load file save file standard view web page HANC (horizontal ancillary data) clearing...
Page 73 Index web page control outputs KAM-AES-R rear module analog cabling D1 serial digital installation KAM-SD-2AES-MUX module features power requirements PWR LED LEDs front edge operational modes locate module Refresh button loss of signal reporting removing modules audio input repair depot composite video in R-Y gain frame reference...
Page 74 Status LEDs web browser Status web page overview synchronizing audio web site system requirements documentation FAQ database Grass Valley software download test signals audio video troubleshooting Y Gain (contrast) summary table web page control Y Offset (brightness) VBI configuration...
