- Page 1 7500 Series Sliding Patio Door OEM INSTALLATION MANUAL...
- Page 2 Post-Installation Check Introduction The 7500 Series Sliding Patio Door comes fully assembled. There are two versions available, one for curbside installation and one for roadside installation. The fixed panel of the sliding door should be towards the front of the unit.
- Page 3 Preparation Check rough opening. DO NOT install the door unless the rough opening is correct. Call Size Net Frame Size Recommended Rough Opening 6' 0" x 6' 4" 71 1/2" x 75 1/2" 72" x 76" 6' 0" x 6' 8" 71 1/2"...
- Page 4 Installation There are roadside and curbside versions of this door assembly. Make sure that the correct door is being installed in the unit. The fixed panel side of the door assembly should be towards the front of the unit. Do not use a sealant that contains solvents that may chemically attack vinyl. Apply a 1/8"...
- Page 5 The drill should be adjusted so that there is not excessive dimpling or fracturing of the mounting flanges, which could cause distortion of the door frame. Shim around the jambs as necessary and drive rest of the fasteners through all the holes provided around the perimeter (Fig.
- Page 6 Shim between wall studs and the door frame behind the lock keeper (Fig. 4D). Remove the two #8 x 1/2" Phillips pan head (PPH) screws from the lock keeper and discard. Install the four provided #10 x 2 1/2" PPH screws into the striker (Fig. 6A) and lock keeper (Fig. 6B) into the door frame.
- Page 7 After the door has been installed, the perimeter of the mounting flange should be covered with siding material. Leave a gap between the edge of the siding material (Fig. 8A) and the door frame (Fig. 8B) to allow for siding expansion and contraction. Fig.
- Page 8 Fit the screen door (Fig. 10A) into the top sill track (Fig. 10B) of the sliding door frame. Fig. 10 Once the screen in the top sill track, lift the bottom of the screen (Fig. 11A) with a putty knife or similar flat-blade tool (Fig.
- Page 9 If the screen door needs to be adjusted, adjust the height of the rollers by adjusting the screws at the top and bottom of the screen (Fig. 12A). Fig. 12 Attach the bug sweep by pressing it into the bug sweep channel. Trim the excess where the bug sweep is flush with the bottom of the screen.
- Page 10 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
