Technical Specifications - Aeotec Range Extender 7 Manual

Make sure to only do this if your Z-Wave gateway/controller/hub is non-functioning or missing.
Follow these steps to factory reset:
•
Press and hold the Z-Wave Button for 20 seconds to completely factory reset your Range Extender 7.
•
@1 second, LED will turn off.
•
@2 seconds, LED will breath its LED
•
@5 seconds, LED will flash its LED
•
@10 seconds, LED will speed up its flashing.
•
@20 seconds, LED will become solid for 2 seconds, then start breathing its LED slowly to
indicate it was factory reset.
•
You may now release the button.
•
If successful, the LED should enter a slow breathing state to indicate it is ready to be paired to a new
gateway/controller/hub.

Technical Specifications.

Name: Range Extender 7
Model number: ZW189
US: ZW189-A01
AU: ZW189-B21
EU/UK: ZW189-C15/C07
Product Dimensions:
US: 53.2x46x40mm
EU: 46x46x60.65mm
AU: 46x46x48.6mm
UK: 53.2x46x48.6mm
Product Weight: 38g
Smart Start: Yes
Repeater: Yes
Beaming Capable: Yes
Security Supported:
S2 Unauthenticated
S2 Authenticated
Power Consumption:
EU/AU/UK = 1.2W
US = 0.6W
Operating temperature: 32°F to 104°F/0°C to 40°C.
Relative humidity: 8% to 80%.
Operating distance: Up to 30m Indoor / 150m Outdoor.
Waterproof and dust rating: IP20 under IEC 60529
AC input:
Version Input (standby power)
100 - 240VAC, 50/60Hz
EU/UK
Max: 150mA
100 - 240V 50/60Hz, Max:
AU
150mA
US 120V 60Hz, Max: 100mA 908.42MHz
Working
Band
868.42MHz
921.42MHz
