MODEL 3
MINNEAPOLIS BLOWER DOOR™
USING THE DG-1000 WITH THE
MINNEAPOLIS BLOWER DOOR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MINNEAPOLIS BLOWER DOOR 3 and is the answer not in the manual?

Questions and answers

Summary of Contents for TEC MINNEAPOLIS BLOWER DOOR 3

  • Page 1 MODEL 3 MINNEAPOLIS BLOWER DOOR™ USING THE DG-1000 WITH THE MINNEAPOLIS BLOWER DOOR...
  • Page 2 USING THE DG-1000 WITH THE MINNEAPOLIS BLOWER DOOR CONDUCTING A ONE-POINT DEPRESSURIZATION TEST Before the Test • Install the blower door frame, panel and fan into an exterior doorway. For instructions about how to do this, please see Chapter 2 of the Minneapolis Blower Door User Manual. •...
  • Page 3 USING THE DG-1000 WITH THE MINNEAPOLIS BLOWER DOOR 4. With the fan inlet still covered, touch Set Baseline to initiate the building baseline measurement procedure on Channel A. Set baseline 5. During a baseline measurement, Channel A will display a long-term average baseline pressure reading while Channel B is used as a timer in seconds to show the elapsed measurement time.
  • Page 4 USING THE DG-1000 WITH THE MINNEAPOLIS BLOWER DOOR 3. Touch the green play icon to start cruise. Once cruise is started, the fan speed slider will move on it’s own. The green play icon will change to an X, and a red stop icon will appear in the lower right of the screen. A pop-up will appear at the bottom of the screen to indicate that cruise has started.
  • Page 5 USING THE DG-1000 WITH THE MINNEAPOLIS BLOWER DOOR 5.2 Manually Controlling the Fan Gradually increase the fan speed by slowly turning the fan controller clockwise. As the fan speed increases, the building depressurization displayed on Channel A should also increase. Continue to increase the fan speed until the building depressurization shown on Channel A is between –45 and –55 Pa.
  • Page 6 USING THE DG-1000 WITH THE MINNEAPOLIS BLOWER DOOR CONDUCTING A ONE-POINT PRESSURIZATION TEST Before the Test • Install the blower door frame, panel and fan into an exterior doorway. For instructions about how to do this, please see Chapter 2 of the Minneapolis Blower Door User Manual. •...
  • Page 7 The drivers are available through Windows Update, and the DG-500 and DG-700 drivers can be downloaded from TEC at software.energyconservatory.com. TEC also offers mobile apps for Apple and Android devices that can be found in the Apple App Store or the Google Play Store. Instructional Videos The Energy Conservatory (TEC) offers a variety of online instructional videos, including •...
