TECHNICAL DATA
GIOE-90
All dimensions shown are in millimetres
All stainless steel construction:
Connections:
Immersion heater rating:
Model
GIOE-90-55/F
GIOE-120-55/F
© Bisque, a division of Zehnder Group UK Ltd
15
GIOE-120
30x30x1.5mm square headers
20x20x1.5mm square tubes
1.2m long flying lead (3 core)
IPX4 or better
Output
Watts
100
200
Electric Gio Towel Radiator
length
fixing centres
Weight
Height
kg
± 2mm
6.6
900
8.6
1200
15
75-105
Length
± 2mm
530
530
Fixing
Centres
± 5mm
500
500
Issue 5.2
