Installation and Maintenance Instructions
CONTENTS
SAFETY CONSIDERATIONS. . . . . . . . . . . . . . . . . . . . .1,2
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2,3
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Step 1 - Unpack and Inspect Units . . . . . . . . . . . . . . 4
Step 2 - Position the Unit . . . . . . . . . . . . . . . . . . . . . . . 4
Step 3 - Install Ductwork . . . . . . . . . . . . . . . . . . . . . . . . 5
Step 4 - Connect Piping. . . . . . . . . . . . . . . . . . . . . . . . . 5
(PROGRAMMABLE)
(NON-PROGRAMMABLE)
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Pre-Start Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
System Operation Check . . . . . . . . . . . . . . . . . . . . . . . . 8
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . .9,10
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
APPENDIX A - CONTROL SETTINGS . . . . . . . . . . . 11

SAFETY CONSIDERATIONS

Improper installation, adjustment, alteration, service, main-
tenance, or use can cause explosion, fire, electrical shock, or
other conditions which may cause death, personal injury or
property damage. The qualified installer or agency must use
factory-authorized kits or accessories when modifying this
product.
Follow all safety codes. Wear safety glasses, protective
clothing, and work gloves. Use quenching cloth for brazing op-
erations. Have fire extinguisher available. Read these instruc-
tions thoroughly and follow all warnings or cautions included
in literature and attached to the unit. Consult local building
codes and the current editions of the National Electrical Code
(NEC) ANSI/NFPA (American National Standards Institute/
National Fire Protection Association) 70. In Canada, refer to
the current editions of the Canadian Electrical Code CSA (Ca-
nadian Standards Association) C22.1.
Understand the signal words - DANGER, WARNING,
and CAUTION. DANGER identifies the most serious hazards
which will result in severe personal injury or death.
WARNING signifies hazards that could result in personal inju-
ry or death. CAUTION is used to identify unsafe practices,
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53400029-01
Vertical Air-Handling Unit Indoor Fan Coil for
Single-Phase Variable Refrigerant Flow (VRF) Systems
Page
Printed in U.S.A.
Form 40WAV-2SI
which would result in minor personal injury or product and
property damage.
Recognize safety information. This is the safety-alert
symbol (
). When this symbol is displayed on the unit and in
instructions or manuals, be alert to the potential for personal
injury. Installing, starting up, and servicing equipment can be
hazardous due to system pressure, electrical components, and
equipment location.
WARNING
Electrical shock can cause personal injury and death. Shut
off all power to this equipment during installation. There
may be more than one disconnect switch. Tag all discon-
nect locations to alert others not to restore power until work
is completed.
WARNING
When installing the equipment in a small space, provide
adequate measures to avoid refrigerant concentration
exceeding safety limits due to refrigerant leak. In case of
refrigerant leak during installation, ventilate the space
immediately. Failure to follow this procedure may lead to
personal injury.
WARNING
DO NOT USE TORCH to remove any component. System
contains oil and refrigerant under pressure.
To remove a component, wear protective gloves and gog-
gles and proceed as follows:
a. Shut off electrical power to unit.
b. Recover refrigerant to relieve all pressure from sys-
tem using both high-pressure and low pressure ports.
c. Traces of vapor should be displaced with nitrogen
and the work area should be well ventilated. Refrig-
erant in contact with an open flame produces toxic
gases.
d. Cut component connection tubing with tubing cutter
and remove component from unit. Use a pan to catch
any oil that may come out of the lines and as a gage
for how much oil to add to the system.
e. Carefully unsweat remaining tubing stubs when nec-
essary. Oil can ignite when exposed to torch flame.
Failure to follow these procedures may result in personal
injury or death.
Pg 1
4-16
40WAV018-048
Replaces: 40WAV-1SI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40WAV Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Carrier 40WAV Series

  • Page 1: Table Of Contents

    40WAV018-048 Vertical Air-Handling Unit Indoor Fan Coil for Single-Phase Variable Refrigerant Flow (VRF) Systems Installation and Maintenance Instructions CONTENTS which would result in minor personal injury or product and property damage. Page Recognize safety information. This is the safety-alert SAFETY CONSIDERATIONS.....1,2 symbol ( ).
  • Page 2: General

    GENERAL CAUTION The 40WAV vertical AHU (air-handling unit) is equipped with a DC motor which provides excellent efficiency. The unit DO NOT re-use compressor oil or any oil that has been features dual drain spouts so it can be mounted vertically or exposed to the atmosphere.
  • Page 3 WA V 018 --- Voltage (V-Ph-Hz) 3 — 208/230-1-60 Equipment Type 40 — Indoor Unit Blank Product Type WA — Single-Phase VRF Capacity (Btuh) 018 — 18,000 Model Type 024 — 24,000 030 — 30,000 V — Vertical Indoor Fan Coil 036 —...
  • Page 4: Installation

    INSTALLATION Step 2 — Position the Unit Step 1 — Unpack and Inspect Units — Units are DANGER packaged for shipment to avoid damage during normal transit and handling. It is the receiving party’s responsibility to inspect Units must not be installed where they may be exposed to the equipment upon arrival.
  • Page 5: Step 3 - Install Ductwork

    • The unit should not be positioned directly above any • The differential height between inlet and outlet should be obstruction. at least 3 inches. The differential height between the bot- tom of the trap and oulet should also be 3 inches. See •...
  • Page 6: Step 5 - Complete Electrical Connections

    • Before insulating the suction and liquid refrigeration This equipment in its standard form is designed for an elec- pipes, perform pressure and leak tests. For details, see trical supply of 208/230-1-60. Any damage to or failure of the outdoor unit installation manual. Insulating both suc- units caused by incorrect wiring or voltage is not covered by tion and liquid refrigerant pipes is required.
  • Page 7: Step 6 - Position And Connect Controller

    ALARM Y (E) Q (E) a40-1752 LEGEND — Water Level Switch — Electronic Expansion Valve — Indoor Fan PUMP — Pump Motor — Inlet Air Temperature — Coil Temperature — Evap. Outlet Temperature in Cooling Mode — Transformer XP1-10 — Plug XS1-10 —...
  • Page 8: Remote Wired Controller

    System Operation Check — Once the installation INDOOR UNIT and pre-start checks are completed, follow these steps: ELECTRIC CONTROL BOX 1. Using remote controller, select cooling or heating mode INDOOR UNIT to check the operation of the system. DISPLAY PANEL 2.
  • Page 9: Troubleshooting

    TROUBLESHOOTING Figure 9 shows shows the LED display panel. See Table 3 for a summary of display indicators. Table 4 lists problems, possible causes, and possible solutions. MANUAL A40-1716 OPERATION TIMER DEF./FAN ALARM Fig. 9 — LED Display Panel Table 3 — LED Display Indicators ERROR CODE LED DISPLAY MODE/STATUS...
  • Page 10: Replacement Parts

    Quote the unit type and unit seri- 40WAV030---3 al number when ordering replacement parts or contacting the 2115V80001 factory about the unit. This information can be found on the se- Carrier Corporation Carrier Corporation 7310 West Morris Street 7310 West Morris Street Indianapolis, IN 46231 USA Indianapolis, IN 46231 USA rial plate attached to the unit.
  • Page 11: Appendix A - Control Settings

    APPENDIX A — CONTROL SETTINGS There are 4 DIP switches on the main board. Figures A-D show the settings for each parameter controlled by a switch. Switches are shown in the default settings. a40-1925 POSITION 1, 2 — HEATING TEMPERATURE OFFSET OFF, OFF —...
  • Page 12 © Carrier Corporation 2016 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Catalog No. 04-53400029-01 Printed in U.S.A. Form 40WAV-2SI Pg 12 4-16 Replaces: 40WAV-1SI...
