Technical
Handbook
ContChamp
DRD
S
This Handbook deals with the design
and maintenance of Kalmar machines,
type DRD-S for the handling of contai-
ners.
In addition, it gives details of trouble-
shooting and the most common
corrective maintenance.
Operation and other matters that are
primarily of interest to the operator are
included it the Instruction Manual.
Kalmar Industries AB
This handbook applies to
machines from and including
machine number T34107.0784 as
well as T34107.0621 and
T34107.0769, see next page.
We reserve the right to modify
our design and material specifi-
cations without prior notice.
Publ. Nr 920 937 9407 04-10
AdEra Dokument AB, Växjö 2004
00
General
10
Chassis and cab
20
Electrical system
30
Engine
Transmission,
40
drive axle, brakes
50
60
Steering axle
70
Hydraulic system
80
Boom and attachment
90
Periodic supervision
