VÖLKER
c Völker Video- und Datentechnik GmbH
Dieses Dokument unterliegt dem Copyright
der Firma Völker Video- und Datentechnik
GmbH.
Es ist erlaubt, wörtliche Kopien dieses Do-
kuments zu verteilen, solange der Copyright-
vermerk und diese Erlaubnis in allen Kopien
enthalten sind.
Es ist ausdrücklich untersagt, dieses Doku-
ment zu modifizieren oder Teile dieses Do-
kuments anderweitig zu nutzen!
Video− und Datentechnik GmbH
Völker Video- und Datentechnik GmbH
Robert-Bosch-Strasse 9
63477 Maintal-Dörnigheim
Tel: (+49) 61 81 / 43 77 -0
Fax: (+49) 61 81 / 43 17 84
http://www.voelker-web.de/
This manual is copyrighted material of
Völker Video- und Datentechnik GmbH.
Permission is granted to make and distribute
verbatim copies of this manual provided the
copyright notice and this permission notice
are preserved on all copies.
There is no permission granted to modify this
manual, or to include parts of the document
into other manuals!
Advertisement
Table of Contents
Related Manuals for Volker FKG-1
Summary of Contents for Volker FKG-1
- Page 1 VÖLKER Video− und Datentechnik GmbH c Völker Video- und Datentechnik GmbH Völker Video- und Datentechnik GmbH Robert-Bosch-Strasse 9 63477 Maintal-Dörnigheim Tel: (+49) 61 81 / 43 77 -0 Fax: (+49) 61 81 / 43 17 84 http://www.voelker-web.de/ Dieses Dokument unterliegt dem Copyright This manual is copyrighted material of der Firma Völker Video- und Datentechnik Völker Video- und Datentechnik GmbH.
- Page 2 FKG-1 User Manual Revision 1.5 April 11, 2006 Copyright c V lker Video- und Datentechnik GmbH Dipl.-Ing. Joerg Desch / esw Völker Video- und Datentechnik GmbH Robert-Bosch-Strasse 9 63477 Maintal-Dörnigheim Tel: (+49) 61 81 / 43 77 -0 Fax: (+49) 61 81 / 43 17 84...
-
Page 3: Table Of Contents
Technical Data ........1 In General The FKG-1 is a compact crosshair generator. It is available as a printed circuit board designed for O.E.M. costumers, or inside a small case. It generates a single crosshair and insert it into a video signal. -
Page 4: Features
Figure 1: Outline of a possible application. 1.1 Features The following enumeration gives you an short overview of the available features of the FKG-1. • insertion of a crosshair into an external video signal. • processing of BAS, FBAS or Y/C possible. - Page 5 User Manual FKG-1 2 Connecting The FKG-1 P3 (5) P2 (6) P1 (7) Figure 2: Overview of the connectors and control elements of the FKG-1 for BAS/FBAS. 4 / 16 Revision 1.5, Dipl.-Ing. Joerg Desch / esw...
-
Page 6: The Back Side Of The Case
3 Connecting The Printed Circuit Board The printed circuit board of the FKG-1 is a member of the FKG product family too. For this variant, all the signals must be plugged into on-board connectors. Figure 3 shows the position and the orientation of these connectors. -
Page 7: The Potentiometers
User Manual FKG-1 3 Connecting The Printed Circuit Board solder jumper 1 2 3 4 5 6 7 8 Memory board revision V1.1 Figure 3: Position and the orientation of all connectors and solder jumpers. 3.1 The Potentiometers The default operation mode is the usage of potentiometers. It is important to use higher quality potentiometers, because the cheaper ones could lead to a jittering crosshair! The dimension of these devices must be between 4.7 kΩ... -
Page 8: The Serial Communication Port
3.4 The Supply Voltage The supply voltage has to be connected to ST2. The FKG-1 needs a DC voltage between 8 V and 12 V. The maximum current consumption is less then 80 mA. ST2 pin-1 is positive and pin-2 is ground. -
Page 9: Operation Modes
User Manual FKG-1 4 Operation Modes Table 4: Usage of the solder jumpers. jumper default function Off,On width of the vertical line as binary value. toggle height between one (off) and two (on) pixels. toggle baud rate between 9600bps (off) and 19200bps (on). -
Page 10: Controlling The Fkg-1 Running Windows
After program start, the configuration dialog box as shown in figure 5 appears. Figure 5: The configuration dialog. Here you can select the serial port used for the FKG-1 connection. It is important, that the device has been switched on. - Page 11 If the same error message appears again, you should select another interface. The last step is used to query the device ID of the FKG-1. Apart from the device name, a dialog box as in figure 8 reports the version of the firmware and the maximum number of supported crosshairs.
- Page 12 User Manual FKG-1 5 Controlling the FKG-1 running Windows Figure 8: Informations queried from connected device. Figure 9: A sample main window. In the case shown, the crosshair 2 is selected for modification. Crosshair number 4 is disabled. 11 / 16...
-
Page 13: Mode Of Operation
“Select:”. The active selection is indicated by an red rhombus. Inside the FKG-1, the se- lection is represented by changing the shading of the crosshair. To deselect the crosshair, simply click the radio button again. -
Page 14: The Area "'Persistent Camera Settings
The buttons “Save”, “Recall” and “Reset” are of particular importance. With the “Save” button you can save the current settings in the EEPROM of the FKG-1. These settings will then be available next time, when the FKG-1 is powered on. No PC must be connected then. - Page 15 User Manual FKG-1 5 Controlling the FKG-1 running Windows picture. If you select “No”, the reset process will be cancelled without causing any data loss. 14 / 16 Revision 1.5, Dipl.-Ing. Joerg Desch / esw...
-
Page 16: Appendix
User Manual FKG-1 6 Appendix 6 Appendix 6.1 Technical Data video signal: CCIR/PAL: BAS, FBAS or Y/C possible horizontal frequency: 15,652 kHz vertical frequency: 50 Hz interlaced 2:1 signal bandwidth: > 10 MHz (-1 dB) supply power: 8 V to 12 V current consumption: ca. - Page 17 User Manual FKG-1 6 Appendix Figure 12: Dimensioning of the printed circuit board. All values are mm! 16 / 16 Revision 1.5, Dipl.-Ing. Joerg Desch / esw...
