- Page 1 VÖLKER Video− und Datentechnik GmbH c Völker Video- und Datentechnik GmbH Völker Video- und Datentechnik GmbH Robert-Bosch-Strasse 9 63477 Maintal-Dörnigheim Tel: (+49) 61 81 / 43 77 -0 Fax: (+49) 61 81 / 43 17 84 http://www.voelker-web.de/ Dieses Dokument unterliegt dem Copyright This manual is copyrighted material of der Firma Völker Video- und Datentechnik Völker Video- und Datentechnik GmbH.
-
Page 2: User Manual
FKG-4 User Manual Revision 1.10 October 23, 2007 Copyright c V lker Video- und Datentechnik GmbH Dipl.-Ing. Jörg Desch / esw Völker Video- und Datentechnik GmbH Robert-Bosch-Strasse 9 63477 Maintal-Dörnigheim Tel: (+49) 61 81 / 43 77 -0 Fax: (+49) 61 81 / 43 17 84... -
Page 3: Table Of Contents
Structure of the keypad ......Controlling the FKG-4 ...... -
Page 4: Usage
See section 4 for an overview of more technical details of the device. 2 Usage All functions of the FKG-4 are controlled by the integrated keypad. Figure 1 shows an image of the layout of the keypad. Note: Don’t use sharp object to press the keys. This could damage the keypad! 2.1 Structure of the keypad... -
Page 5: Controlling The Fkg-4
Tip: The selected haircrosses change there brightness immediately. So the user is able to verify his selection visually. The selection itself causes no action. It is always necessary to “tell” the FKG-4 what it should do with the selected items. In the easiest case, this could be the repositioning. -
Page 6: Special Functions
Note: Nonsensical combinations of the positioning keys will be ignored! Because of the high resolution of the FKG-4, a step-by-step movement would be a very an- noying task. To combine exact positioning with a fast movement, the FKG-4 use a acceleration function. -
Page 7: Locking The Keypad
¦ ¥ ¦ ¥ 3.3 Locking the keypad It is possible to protect a given configuration of the FKG-4 by locking the keypad. This can be done by the following power-up sequence. 1. power off the device. § ¤ §... -
Page 8: Appendix
> 10 MHz (-1 dB) power supply: 115 V / 60 Hz (FKG-4-017) 230 V / 50 Hz – 60 Hz (FKG-4-011) power consumption: 2.5 W dimensions: 158 mm (W) * 200 mm (L) * 100 mm (H) -
Page 9: Declaration Of Conformity
4 Appendix 4.2 Declaration of Conformity Völker Video- und Datentechnik GmbH Robert-Bosch-Str. 9 63477 Maintal-Dörnigheim erklären in alleiniger Verantwortung die Übereinstimmung des Produktes: FKG-4 Fadenkreuzgenerator auf das sich diese Erklärung bezieht, mit folgenden Normen: EN 550081-1 1993 EN 550082-2 1996 EN 550022 K1.B...
