General Installation Guide For Mirror
Tools Required
Wall Anchors,
Screws & Hangers
STEP 1
Note: Mirror Shapes may varies according to purchased.
Temporarily attach the mirror template on the wall in the desired mirror hanging location.
Template
TOP
Hanger Mark
LEVEL
FLOOR
visit us on-line at www.quoizel.com
These instructions are provided for your safety. It is
very important you read them completely before
installing the mirror.
Quoizel recommends 2 people for each step during
assembly.
Tape (not
included)
1of3
Warnings and Cautions
Install Mirror
Clean
OVAL/CIRCLE
Template
TOP
LEVEL
FLOOR
ReleasedDate:2019-06-19
Hanger Mark
Tape (not
included)
