- Page 1 MANUAL © Fly & more Handels GmbH, ICARO Paragliders E C H N I C A L V O L U T I O N Version: 1.6– E, 01.10.2012...
- Page 2 Page 2 Congratulations on buying your and welcome to the family - pilots! Your CYBER TE • is made with great care and state of the art, • tested according o European Standards EN 926-1:2006 , EN 926-2:2005 o Notification of the Federal Aviation Administration of Germany •...
-
Page 3: Table Of Contents
Page 3 LIST OF CONTENTS YOUR CYBER TE...................6 CYBER TE ..............6 HARACTERISTICS OF ....................6 ECHNICAL ......................6 ANOPY .......................7 INES ......................8 ISERS ........8 OW TO MOUNT THE ACCELERATION YSTEM AT THE HARNESS FLIGHT TIPS ....................9 ....................9 ROUND RAINING & F ............9... - Page 4 • This manual give you informations on the entire specific and general flying characteristics of the CYBER TE and does not replace attending a paragliding school • All technical data and instructions in this manual were drawn up with great care.
- Page 5 (can be found in this manual or on our website www.icaro-paragliders.com) o and sent to Fly & more Handels GmbH ICARO Paragliders within 6 weeks after purchasing the glider at an official dealer/school of...
-
Page 6: Your Cyber Te
“GH”. To find out which class of harness your harness belongs to, check the certification sticker or ask the manufacturer. CYBER TE has an accelleration system which will be activated with a footbar, no trimmer and not any other removable devices for change of trim and speed. -
Page 7: Lines
All mainlines have the same lenghts so you can check the trimm of your glider. The end control of all line lengths is documented for all paragliders produced by ICARO paragliders. The complete geometry of the lines and the lenghts is shown on the single line... -
Page 8: Risers
Page 8 Risers The Glider has 3 fold risers with separated A-risers A`), accelleration system which will be activated with footbar TrimmSpeedOptimizer, mounted on the rear riser (how the TSO works is described in the annex). The risers are signified. The main break line comes through a return pulley, the handle of the main breakline is mounted on the C- riser. -
Page 9: Flight Tips
Page 9 FLIGHT TIPS Ground Training Before the first flight the CYBER TE must be inflated in the wind on a flat surface. An approved ICARO dealer should carry out the first flight before the wing is handed over to you. -
Page 10: Active Flying
Landing The CYBER TE is very easy to land. Always stand up in the harness in the landing position very early in order to be able to react as fast as possible to sudden events. -
Page 11: Descent Techniques
The CYBER TE will start to turn, speed up and then drop into a spiral. To keep the wing under control you must pull and release the inside brake. Exit slowly. Bring your body weight back to a neutral position and as soon as the wing levels out, apply the brakes gently. -
Page 12: Wingovers
Wingovers are induced by flying alternating turns; each time letting the pendulum effect increase the bank angle. Attention: The CYBER TE is an agile glider, and it is quite easy to get to an excessively high angle of bank in just a few turns. -
Page 13: Asymmetric Collapse
Applying the brakes symmetrically will speed things up. Emergency Steering Should it no longer be possible to steer your CYBER TE, for example due to a broken line, the glider may be steered by gently pulling on either rear riser. We recommend for emergency control in the air to use the stabilo line. -
Page 14: Negative Spin
To exit a spin with your CYBER TE just do “hands up” to release the brakes and the glider will return to normal flight. - Page 15 • The CYBER TE is a very strong paraglider. Flying all the descent or acrobatic manoeuvres will not normally pose a structural problem but aerobatic training does accelerate the ageing process dramatically.
-
Page 16: Repairs
Inspection interval: 200 flight hours or 24 months, depending on what occurs sooner. Without regular certified inspections, your glider will loose its pattern test result and guarantee. It is important to have your CYBER TE inspected by a trained ICARO technician. Below you find the regulations for checks of certified gliders. -
Page 17: Terms Of The Guarantee
Harnesses and Rescue systems: 3 years. What are the conditions of the guarantee? Provided that Fly & more GmbH / ICARO Paragliders accept the fault the guarantee contains all necessary spare parts related to the replacement or repair of defective parts and working time. -
Page 18: Vii. Enviromental Aspects
• Gliders / harnesses and rescue equipment where the required inspection intervals were not met and the verification of the glider was not conducted by a Fly & more Handels GmbH ICARO Paragliders authorized operation / person • Damage which has occurred due to improper treatment (i.e. storage in humidity, heat or direct sunlight) •... -
Page 19: Last But Not Least
Page 19 Last but not Least Team ICARO thank you for your trust in our brand and should you have any questions, ideas or criticisms, please contact us. This paraglider has been developed and produced by modern technology and will give you years of pleasurable and unforgettable flight experiences. -
Page 20: Lineplan
Datas above glider/ harness/ rescue system Type und size of glider/ harness/ rescue Purchasing date Serial number system Dealer/ICARO agency: (Name and address or stamp) Furthermore, I would like to inform Fly & more Handels GmbH / ICARO Paragliders as follows: ------------------------------------- --------------------------------- Date Signature... - Page 21 Adjustment range max. 2,5 cm The original trim of a new CYBER TE is when both adjusting screws are next to each other (distance between ≤ 1mm). The lenghts of the risers can be combined (add correction of wing loading, aging and temperature).
- Page 22 Page 22 Recommended settings for the TSO: Aging adjustment wing adjustment adjustment temperature range in in flight range in cm range in cm loading hours Minimum > 100 + 1,5 + 0,5 + 0,5 take off eight (+/-2 Middle weight + 0,5 –1,0 >...
- Page 23 General Remarks Any other repairs, corrections etc. to the general condition of the paraglider must be evaluated. A copy of the results of each inspection must be sent on to Fly & more Handels GmbH ICARO Paragliders.
- Page 24 The technician must report any unusual faults to Fly & more Handels GmbH ICARO Paragliders within 3 days. Inspection Reference Only an authorised technician who has been trained by Fly & more Handels GmbH ICARO Paragliders is authorised to sign and date the glider type label and sign the manual. Partlist Name Order Nr.
- Page 25 Date: 23.07.2012 Type testing: Test sample: ICARO Cyber TE XS Type testing holder: ICARO Paragliders, Fly & more GmbH Date of type testing declaration: 20.07.2012 LTF NFL II-91/09, Certified standards and procedures: EN 926-2:2005, EN 926-1:2006 Foldinglines for type testing:...
- Page 26 Date: 02.07.2012 Type testing: Test sample: ICARO Cyber TE S Type testing holder: ICARO Paragliders, Fly & more GmbH Date of type testing declaration: 02.07.2012 LTF NFL II-91/09, Certified standards and procedures: EN 926-2:2005, EN 926-1:2006 Foldinglines for type testing:...
- Page 27 Date: 11.04.2012 Type testing: Test sample: ICARO Cyber TE M Type testing holder: ICARO Paragliders, Fly & more GmbH Date of type testing declaration: 11.04.2012 LTF NFL II-91/09, Certified standards and procedures: EN 926-2:2005, EN 926-1:2006 Foldinglines for type testing:...
- Page 28 Date: 02.07.2012 Type testing: Test sample: ICARO Cyber TE L Type testing holder: ICARO Paragliders, Fly & more GmbH Date of type testing declaration: 02.07..2012 LTF NFL II-91/09, Certified standards and procedures: EN 926-2:2005, EN 926-1:2006 Foldinglines for type testing:...
- Page 29 Page 29...
- Page 30 Page 30...
- Page 31 Page 31...
- Page 32 Dispatch protocol/ Delivery content Piece check complete Inner bag Compression band Risers bag Outer rucksack Manual Repair set T- Shirt/ Hipbag Sticker ............Date Signature...
