Poly G10 Series, Poly G40 Series, and Poly G80 Series PC Mounting Kit
See the Regulatory Notices guide for all regulatory and safety guidance prior to configuration.
Avant de procéder à la configuration, veuillez consulter les Avis de réglementation, afin de prendre connaissance des recommandations en matière de sécurité et de réglementation.
Tools Needed:
6 mm
Attach the four mounting screws using the
outer M4 riveting studs.
(4) Mounting Screw
Drill four 6 mm holes in the wall, 200 mm apart, to a depth of
40 mm.
6 mm
× 4
Depth = 40 mm
Slide the PSU into the PSU holder.
200 mm
SETUP SHEET
Mount the plate to the wall using four M4 ×
35 expansion screws, flat washers, and
plastic wall anchors.
(4) M4 x 35 Expansion Screw
(4) Flat Washer
(4) Plastic Wall Anchor
support.polycom.com/video
3725-30775-001B
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Poly G10 Series
Summary of Contents for Poly G10 Series
- Page 1 SETUP SHEET Poly G10 Series, Poly G40 Series, and Poly G80 Series PC Mounting Kit See the Regulatory Notices guide for all regulatory and safety guidance prior to configuration. Avant de procéder à la configuration, veuillez consulter les Avis de réglementation, afin de prendre connaissance des recommandations en matière de sécurité et de réglementation.
- Page 2 Attach the PSU to the plate by inserting the top two screws into the Attach two thumb screws at the bottom of the PSU holder. Wrap the cable two keyholes and sliding to the left to lock in place. wrap around the power cable. (2) M3.5 ×...
- Page 3 Attach the cover to the wall plate by inserting the four bolts into the top of the four corner keyhole slots and sliding them down to lock in place. © 2020 Plantronics, Inc. All rights reserved. Poly, the propeller design, and the Poly logo are trademarks of Plantronics, Inc. The Bluetooth trademark is owned by Bluetooth SIG,...
