Parameter Query/Setting
• Hold down the [Mode]+ [▲] buttons for 5 seconds to automatically enter the
parameter query interface when the "Time Area-Hour" icon flashes and displays
the "Parameter Code" and "Temperature Area" displays the current "Parameter
Value" matching the "Parameter Code".
• When the "Parameter Code" flashes, press the [▲] or [▼] buttons to switch the
"Parameter Code".
Parameter
Area Display
Code
01 Time Area-
Hour
02 Time Area-
Hour
Time Area-
03
Hour
Time Area-
04
Hour
Time Area-
05
Hour
06 Time Area-
Hour
07 Time Area-
Hour
E1 Time Area-
Hour
E2 Time Area-
Hour
E3 Time Area-
Hour
E4 Time Area-
Hour
E5 Time Area-
Hour
Parameter Setting
• Hold down the [Mode]+ [▼] buttons for 5 seconds to automatically enter the
parameter query interface. When the "Time Area-Hour" icon flashes and displays
the "Parameter Code" and "Temperature Area" displays the current "Parameter
Value" matching the "Parameter Code".
 When the parameter code flashes, press the [▲] or [▼] key to switch the
"Parameter Code". Press the [Mode] button to stop the "Parameter Code" from
flashing and enter the "Parameter Value" changing interface when the "Parameter
Value" flashes.
Parameter Name
Indoor ambient
temperature
Aperture of expansion
valve of the indoor unit
Temperature at the inlet of
evaporator of the indoor unit
Temperature in the middle of
evaporator of the indoor unit
Temperature at the outlet of
evaporator of the indoor unit
Engineering number of the
indoor unit
IP address of the
indoor unit
Historical Error 1
Historical Error 2
Historical Error 3
Historical Error 4
Historical Error 5
Query the Current
Parameter
Value Area Display
to
Query
Current Temperature
value Area
Current Temperature
value Area
Current Temperature
value Area
Current Temperature
value Area
Current Temperature
value Area
Current Temperature
value Area
Current Temperature
value Area
Err+** Temperature
Area
Err+** Temperature
Area
Err+** Temperature
Area
Err+** Temperature
Area
Err+** Temperature
Area
Query
Range
-30~150
0~500
-30~150
-30~150
-30~150
/
/
