- Page 1 CPF370L20 Stirling Mobile Refrigerator Operating Manual 1 Stirling road, north economic development zone, rizhao city, shandong province, China www.chinastirling.com...
-
Page 3: Table Of Contents
1.2. Manual Contents......................1 2. Precautions for Safe Operation..................2 2.1. Warnings........................3 2.2. Cautions........................3 3. Features of the CPF370L20..................... 5 3.1. FPSC and Refrigeration....................5 3.2. Power and Temperature Control................. 5 3.3. Power Adapter and Cord..................... 5 3.4. Thermal Insulation...................... 5 3.5. -
Page 4: Product Intro
The China Stirling CPF370L20 Stirling Mobile Refrigerator uses air flow technique for refrigeration, highly advanced free piston Stirling technology, wide temperature range, precise temperature control of ±0.1 °C, light weight, easy to use, specially designed power control system and built-in backup battery. -
Page 5: Precautions For Safe Operation
Use proper precautions when operating in mobile usage. China Stirling cannot be held responsible for damages or loss of stored product attributed to unintended use. In no case will China Stirling be held liable for loss of stored product resulting from electrical, mechanical or structural failure. As with any... -
Page 6: Warnings
Refrigerator and damage the stored items. Do not put CPF370L20 near to fire, may catch fire which will cause the internal gas to expand or even explode. Do not put store flammable gaseous or liquids. -
Page 7: Cautions
Refrigerator is described later in this operating manual. Warning: Unauthorized modification to the unit, controls or free-piston Stirling engine is prohibited and will void all warranty provisions. Operating Manual: CPF370L20... -
Page 8: Features Of The Cpf370L20
. 3.1. FPSC and Refrigeration The China Stirling CPF370L20 Stirling Mobile Refrigerator use two Cryo S 100 Free Piston Stirling cooler as the refrigeration core. The Cryo S series Stirling engine uses approximately 3 grams of helium gas as a working fluid. Using no coolants for refrigeration purpose, air flow technique is used for refrigeration in freezer. -
Page 9: Graphical User Interface
, 6DOF motion processor collects and analyzes all equipment motion data, opening a new chapter for your precise products transport and storage service. The China Stirling CPF370L20 Stirling Mobile Refrigerator has the following features: Operating Manual: CPF370L20... - Page 10 1．UI Screen UI and control described more in section 5. 2．Door gasket Double Rubber gasket for tight fitting and seal from moisture make it secure. 3．Door Locks Three door lock in a line. Operating Manual: CPF370L20 www.chinastirling.com...
- Page 11 Hard plastic wheels with stop locks. 5．Handles Making it easy to move. 6．Switch and Socket Power switch for machine and DC B-type socket. 7．Exhaust vent Flowing hot air outside the FPSC. 8．Air vent Fresh air intake vent for cooling of FPSC. Operating Manual: CPF370L20 www.chinastirling.com...
-
Page 12: Unpacking And Setup
4. Unpacking and Setup NOTE: Prior to setting up the CPF370L20, inspect the unpacked unit and any included items for shipping damage. Compare all contents to the packing list for completeness. 4.1. Unpacking Remove the Stirling Mobile Refrigerator and all accessories from the box. - Page 13 Use same same procedure as AC system. Cigarette Lighter Cable NOTE: For direct use of DC power input systems must be over 24V and 10 A , consult your automotive specialist if your vehicle lacks 10 A rated 24V outlets. Operating Manual: CPF370L20 www.chinastirling.com...
-
Page 14: Operation
Refrigerator after 30 sec of beep if battery is fully charged. 4) Do the same while using the Refrigerator in the transport truck. 5) If you unplug the Stirling Mobile Refrigerator while it is on, you will hear a sudden noise as the free-piston Stirling engine power is switched from main power supply to battery and will cause the noise. -
Page 15: Ui Operation Guidelines
The applicable model and operation: Current program of the CPF370L20 Refrigerator is applicable to G-pro driver board and 4.5 inch IPS resistive touch screen. Program version number cab be seen on the display screen. - Page 16 Display ambient temperature Machine running time 10. Press to lock or unlock the screen 11. Press to enter the user setting interface 12. Press to enter Wi-Fi configuration interface 13. Press the Power Button to ON/OFF the machine Operating Manual: CPF370L20 www.chinastirling.com...
- Page 17 1. Scan QR code 2. Pay attention to the public number 3.Follow the page prompts after scan 3) Wi-Fi configuration 4) OTA upgrade 5) Program version number 4. Wi-Fi configuration operation instructions This interface consists of 4 parts: Operating Manual: CPF370L20 www.chinastirling.com...
- Page 18 7．Unpacking times display, showing the current number of times the box has been opened during work; 8．DC voltage, DC current, AC current, power, machine boost command, current temperature and set temperature, T3 hot end temperature, T2 ambient temperature, T4 cold end temperature; Operating Manual: CPF370L20 www.chinastirling.com...
- Page 19 11. Alarm current: When the machine is running, the AC current reaches the set point the alarm be ON and machine will stops. 12. Hot-end threshold: limit the operating power of the machine when hot forging reaches this temperature. Operating Manual: CPF370L20 www.chinastirling.com...
-
Page 20: Error / Alarms And Troubleshooting
Cold end Fan 2 not Check the fan 2 high temperature is wired wiring Fan 2 does not temperature more than 55℃ turn in heating Contact after-sales Fan 2 mode to return to the damaged factory for Operating Manual: CPF370L20 www.chinastirling.com... - Page 21 Fuse open Fuse blown Fuse blown Replace fuse Battery Battery Replace power powered depletion supply or battery Insufficient DC voltage less power Power than 18V Check or replace supply Power supply supply the power supply error Operating Manual: CPF370L20 www.chinastirling.com...
-
Page 22: Maintenance & Service
When changing the goods or in the event of excess frost accumulation inside the freezer, turn OFF and empty the Stirling Mobile Refrigerator and clean it with soft dry clothes. Avoid using any sharp objects to remove the frost, Refrigerator body and insulation can be damaged with sharp objects. -
Page 23: Troubleshooting
10cm on the top for airflow. Avoid directly putting objects higher than the ambient temperature into the refrigerator. Reduce the frequency and duration of door opening as much as possible to keep the temperature maintained. Operating Manual: CPF370L20 www.chinastirling.com... -
Page 24: Specifications
8. Specifications 8.1. Stirling Mobile Refrigerator Specifications The technical specification for Stirling mobile refrigerator is given below in detail: 110V - 240V (±10%) at either 50 or 60 Hz or 24-30V Input Power DC from mobile source 170 watts (1.5 amps @120VAC, 0.8 amps @220VAC） ,... -
Page 25: Stirling Mobile Refrigerator Dimensions
8.2. Stirling Mobile Refrigerator Dimensions Dimensions of China Stirling mobile refrigerator are shown in the pictures below, all the dimensions are in mm (millimeter). Major internal parts of the unit is also clearly mentioned in the pictures from top view. -
Page 26: Stirling Mobile Refrigerator Performance Curve
Top View 8.3. Stirling Mobile Refrigerator Performance Curve Refrigerator performance test graph is given below. Refrigerator reach -20 ℃ from ambient 25℃ in 12 hours when Refrigerator is in empty condition. Operating Manual: CPF370L20 www.chinastirling.com... -
Page 27: Warranty
China Stirling will not be responsible for charges incurred for service calls made by a third party prior to authorization by China Stirling. China Stirling retains the right to replace any product in lieu of servicing it in the field. - Page 29 山东省日照市北经济开发区斯特林路1号 1 Stirling road, North Economic Development Zone, Rizhao city, Shandong province, China +86 15000777883, +86 17763336212 www.chinastirling.com Specifications subject to change without notice. Refer to www.chinastirling.com for the latest specifications.
